Figure 11 illustrates the Loopback and Test
Commands Screen, which provides the user with the
ability to invoke or terminate all available HDSL2
loopbacks. Each HDSL2 circuit component can be
looped toward the network or customer from this
screen. It also provides a self-test option to perform a
self-diagnostic of the H2TU-C and H2TU-R.
CIRCUIT ID:
CIRCUIT ID:
Menu
1. Definitions
2. Reset Data
3. 15 Min Data
4. 24 Hr Data
5. Line Data
6. Path Data
7. H2TUC DSX-1
8. H2TUC LOOP
9. H2TUR LOOP
10. H2TUR DS1

Figure 12. 15-Minute Performance History Line Data Screen

61222026L7-5B
Press ESC to return to previous menu
Loopback and Test Commands
______
|H2TUC |
<---| |
| |
NET | |<--------->|
| |
--->| |
DSX-1 |______|
1. Run Self Tests
2. H2TU-C Loopup Network
3. H2TU-C Loopup Customer
4. H2TU-R Loopup Network
5. H2TU-R Loopup Customer
Selection:

Figure 11. Loopback and Test Commands Screen

Press ESC to return to previous menu
15 Minute H2TUC DSX-1 Performance Data
ES-L
000
00:00 ---
23:45 ---
23:30 ---
23:15 ---
23:00 ---
22:45 ---
22:30 ---
22:15 ---
22:00 ---
21:45 ---
21:30 ---
21:15 ---
Selection:
Section 61222026L7-5, Issue 2
The Performance History Screens, illustrated in
Figure 12 and Figure 13 display the historical
HDSL2 and T1 performance data in several different
registers.
______
|H2TUR |
| |--->
| |
| CUST
| |
| |<---
|______| DS1
SES-L UAS-L CV-L
000 000 00000
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
--- --- -----
___
-7->| C |
| |<-8---9->|
<---|___|
01/01/00 00:38:20
01/01/00 00:08:46
___
| R |---->
|
|___|<-10-
11
