Gainwise TH601W Settings Manual

Hide thumbs Also See for TH601W:
Table of Contents

Advertisement

Quick Links

Download this manual
Warning:
Before you use the device, make sure device is worked in below environment, or it can't work properly.
Support
Need good smartphone
signal
Router 2.4GHz WiFi.
Router Upload
bandwidth≥512KBit/s
Introduction
喇叭
Install the APP
Special Notice: When open the app, you will receive a tip. Please click 'OK' to allow the
notifications, otherwise, you cannot receive any notification.
Gainwise Technology Co., Ltd.
886-6-3127675
10F-4, No.12, Zhonghua Rd., Yongkang Dist., Tainan City 71069, Taiwan
TH601W Setting guide
Don't support
A poor signal may cause long delays or
inability to view
5GHz WiFi.
<512KBit/s or too many computers /
smartphones in the same network. Delay or
can't work.
Scan QR code or search the App 'DIY Smart'from 'Google Play
Store' or 'App Store', and install on mobile phone.
Solutions
1. User can connect device to 5
smartphones to in case 1-2 smartphones
are in poor signal area, other
smartphones can still ring and view.
2. User better to connect smartphone to
WiFi when there is WiFi available.
Change to use 2.4GHz WiFi.
1. Reduce the computers/smartphones
quantity connected in the same network.
2. Change to use a bigger bandwidth
network.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TH601W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gainwise TH601W

Summary of Contents for Gainwise TH601W

  • Page 1 TH601W Setting guide Warning: Before you use the device, make sure device is worked in below environment, or it can't work properly. Support Don’t support Solutions 1. User can connect device to 5 smartphones to in case 1-2 smartphones are in poor signal area, other...
  • Page 2 TH601W Setting guide Register Account (Register your phone number & Register via email) Register your phone number Region: Please select your region Enter your phone number：Enter your mobile number Enter verification code：Click "Get Verification Code", please go to SMS to view verification code and enter Enter password：Enter the password you want to set (password is 8-30 characters containing letters &...
  • Page 3 TH601W Setting guide Register via email Enter Email and press "Send Email Verification Code" Enter verification code：Fill in the verification code received by Email (mail may be in spam) Enter password：Enter the password you want to set (password is 8-30 characters containing letters &...

  • Page 4: Add Device

    TH601W Setting guide There are 3 modes for adding devices: "fast networking", "Smartlink", "Wired Connection", the most commonly used is "Smartlink", the following is the setting description 1) Add device ( ”fast networking” “Smartlink” “Wired Connection” (Smartlink) Click “+” add device Click “Add New...

  • Page 5: Special Notice

    TH601W Setting guide (fast networking) Click “Add New Click “+” add Device” Click”fast networking” device After the device is powered on, you can hear the sound of DU DU Select device wifi Confirm WIFI name Enter WIFI password Hear the sound of Device is setting “king”, press the...
  • Page 6 TH601W Setting guide (Wired Connection) Click “Add New Click “+” add Device” device Click “ Wired After the device hears Connection” -DU-DU- sound, connect the network cable and press Next Search and select to find connected Name your new devices...
  • Page 7 TH601W Setting guide 2) Share the device with others Enter the other person's DIY Click "Share" SMART account or phone number and press Share Select the permissions to grant and press "OK" The old device has no authorization page, and the unlock authorization is in “Settings”...
  • Page 8 TH601W Setting guide 3) APP home screen and TF card video playback view Online icon Device name Device share TF card video playback device status Device detailed settings Notification list Mobile screenshots Select "Playback" on the main Device List and videos...
  • Page 9 TH601W Setting guide 5) Video interface explanation Horizontal Date and time Unlock the door Internet speed Resolution HD 1080 * 720 SD 640 * 480 LD 320 * 180 sound Screenshot microphone Screen recording Straight mode Straight Device detailed Device name...
  • Page 10 TH601W Setting guide Device detailed settings Time settings Notice ： The device actively captures network time. If the time is incorrect, please note that the time zone is correct. Picture and sound Video format: select PAL or NTSC Volume：Device speaker volume Video quality：Sharpness of...
  • Page 11 TH601W Setting guide Record settings Notice： All recording modes require a TF memory card. When the memory card is full, the device will overwrite the earliest date recording Record mode Record manually：When you need to record, you need to press the recording switch manually.
  • Page 12 TH601W Setting guide Defense Settings Arm mode Motion detection： After turning on, the lens will notify you when the object moves Alert Sensitivity： Low：issuing alert when moving large objects, such as a human, are detected within 3 meters Middle：issuing alert when moving large objects, such as a human, are detected within 5 meters High：issuing alert when moving large objects, such as a human, are detected within 5 meters...
  • Page 13 TH601W Setting guide RTSP setting Turn on RTSP: After RTSP is enable, you can access the device through the NVR, PC monitoring software CMS or other ONVIF-connected applications (need be on the same LAN) RTSP password: Security password to be...

  • Page 14: Reset The Device

    TH601W Setting guide 7) Reset the device 8) Delete device Press and hold the device picture, then click the "Unbind" button, then click the "Confirm" button to delete the device. 9) How to install the wall Note: WiFi antenna should be installed inside the house for better signal.
  • Page 15 TH601W Setting guide Step 1：Drill a hole for the wires to go through the wall, use the hexagonal screw driver in the box to remove the rain cover screw at the bottom of the device. Remove the rain cover sticker and stick the ring cover on the wall.

  • Page 16: Tamper Alarm

    TH601W Setting guide 10) Tamper Alarm When the thief opens the device, it will have siren alarm, and your phone will receive alarm too. (The tamper alarm will be last for 1 min.) 11) FAQ Q1. Why I can't receive push notification ring on my phone? 1.
  • Page 17 Q4. Why Video and voice delay when I mount the TH601W on the villa fencing or far outside？ A: the distance and thickness of blocks exceed the transmitting ability of the antenna. Q5. Why I hear a shrill sound, too small sound or can't hear sound from the TH601W on my Android phone？...

  • Page 18: Model Specification

    TH601W Setting guide 12) Model Specification 1/4” Color CMOS Sensor Image Sensor Compression H.264 HD：1280*720；S D：640*360；LD：320*180 Resolution Memory Built-in 8G memory card up to 128G memory card Lens Fixed 2.5mm 122° 0Lux(IR ON) / 0.5Lux(Normal) Sensitivity IR LED 4 × Φ4 Night vision distance Max.
