  • Page 1 Thin Client Operating Manual FUJITSU Thin Client FUTRO S5010 FUTRO S7010...
  • Page 2 Thank you for buying an innovative product from Fujitsu. Latest information about our products, useful tips, updates etc. is available on our website: "http://www.fujitsu.com/fts/" You can find driver updates at: "http://support.ts.fujitsu.com/download" Should you have any technical questions, please contact: •...
  • Page 4 Published by / Contact address in the EU Fujitsu Technology Solutions GmbH Mies-van-der-Rohe-Straße 8 80807 Munich, Germany "http://www.fujitsu.com/fts/" Copyright © Fujitsu Technology Solutions GmbH 2019. All rights reserved. Publication Date 12/2019 Order No.: A26361-K1080-Z329-1-7619, edition 1...
  • Page 5 FUJITSU Thin Client FUTRO S5010 FUTRO S7010 Operating Manual Your FUTRO... Ports and Operating Elements Important notes Getting started Operation System expansions and repairs Technical data Index...
  • Page 6 Information on the product description meets the design specifications of Fujitsu and is provided for comparison purposes. Several factors may cause the actual results to differ. Technical data is subject to change without prior notification. Fujitsu rejects any responsibility with regard to technical or editorial mistakes or omissions.
  • Page 7: Table Of Contents

    ............... . 29 Fujitsu...
  • Page 8 FUJITSU Thin Client FUTRO S5010 / S7010 ........
  • Page 9: Your Futro

    The operating system is installed on a flash memory. Validity of the Reference Manual This Reference Manual is valid for the following system: • FUJITSU Thin Client FUTRO S5010 • FUJITSU Thin Client FUTRO S7010 Notational conventions Pay particular attention to text marked with this symbol. Failure to observe these warnings could pose a risk to health, damage the device or lead to loss of data.
  • Page 10: Ports And Operating Elements

    Front view Onswitch Offswitch Headphoneport Microphone jack USB, 1 = ON/OFF switch 3 = Headphone port 2 = USB 3.1 Gen1 ports (USB Type-A) 4 = Microphone jack Fujitsu...
  • Page 11: Rear View

    6 = RJ45 socket (Local Area Network) optional) with double screw security 7 = Audio output (Line out) Device with Power-over-Ethernet 8 = DisplayPort module: No port 9 = DC input jack (DC IN) 3 = USB 2.0 ports (USB Type-A) Fujitsu...
  • Page 12: Security Functions

    You can use the security lock device (positioned at the side) and the Kensington Lock cable (steel cable, accessory) to protect your device against theft. Please consult the manual for your security lock. When using the Security Lock device, opening of the casing is also prevented. Fujitsu...
  • Page 13: Securing Usb Covers (Optional)

    Please note that USB covers, once fitted, cannot be removed again! Ensure that you fit the USB covers the right way round. ► Insert the USB covers in the USB ports on the front of the device and push the USB covers in firmly. Fujitsu...
  • Page 14 ► Insert the USB covers in the USB ports on the rear side of the device and push the USB covers in firmly. In the BIOS Setup, under Advanced - USB Port Security, you can also deactivate the USB ports, in order to limit the use of USB devices. Fujitsu...
  • Page 15: Important Notes

    Make sure that the rated current of the mains adapter is not higher than that of the power system to which you connect the mains adapter. ON/OFF switches do not disconnect the device from the mains voltage. To completely disconnect the mains voltage, remove the power plug from the power socket. Fujitsu...
  • Page 16: Module

    Ensure that no liquid enters the system. The surface can be cleaned with a dry cloth. If particularly dirty, use a cloth that has been moistened in mild domestic detergent and then carefully wrung out. Use disinfectant wipes to clean the keyboard and the mouse. Fujitsu...
  • Page 17: Energy Saving, Disposal And Recycling

    Energysaving Recycling You can find information on these subjects in the "Environment and Energy Information" manual or on our website ("http://www.fujitsu.com/fts/about/fts/environment-care/"). Information on "Ecodesign directive": Regulation 1275/2008, based on the EU Eco-design Directive (2009/125/EU), defines requirements for the power consumption of electrical and electronic domestic and office devices in stand-by and off mode.
  • Page 18: Getting Started

    If the device is to be built-in, adequate ventilation must be assured. Fit the base feet for horizontal or vertical operation (see "Vertical operating position", Page 15 "Horizontal operating position", Page 17). Fujitsu...
  • Page 19: Vertical Operating Position

    ► Place the feet on the casing (1). In doing so, make sure that the 4 clips (2) on the feet are aligned above the corresponding holes in the casing. ► To secure the feet, press the clips in the direction of the arrow (2) until they are felt to engage in the holes. Fujitsu...
  • Page 20 M2.5x5 mm. These are not included in the delivery scope. ► Secure the feet with the screws (3). ► Stand the device on the feet. ► If necessary, reconnect any cables that were previously disconnected. Fujitsu...
  • Page 21: Horizontal Operating Position

    To protect your device against unauthorised removal of the feet, the feet can also be secured with two screws, each of type M2.5x5 mm. These are not included in the delivery scope. ► Secure the feet with the screws (3). Fujitsu...
  • Page 22 Getting started ► Place the device on the feet. ► If necessary, reconnect any cables that were previously disconnected. Fujitsu...
  • Page 23: Connecting External Devices

    ► Follow the instructions contained in the monitor manual to prepare the monitor for operation (e.g. connecting cables). Monitor, ► Connect the data cable to the required monitor port on your device. ► Plug the monitor power cable into the grounded mains outlet. Fujitsu...
  • Page 24: Connecting A Usb Mouse

    The devices connected to the serial interface require drivers. Your operating system already includes many drivers. If the required drive is missing, install it. The latest drivers are usually available on the Internet or will be supplied on a data carrier. Fujitsu...
  • Page 25: Connecting External Devices To The Usb Ports

    Connect microphone and headphones Microphone Headphones ► Connect the microphone to the microphone port. ► Connect the headphones to the headphones port. Connecting the device to the network (LAN) ► Connect the 10/100/1000 Base T network cable to the RJ45 LAN port. Fujitsu...
  • Page 26: Connecting The Mains Adapter

    ► Connect the mains cable (1) to the mains adapter. ► Connect the mains adapter cable (2) to the DC jack (DC IN) of the device. ► Plug the mains cable (3) into a mains socket. Fujitsu...
  • Page 27: Operation

    Citrix and Microsoft clients as well as the optional VMware client. It has a user-friendly licence model, with the possibility of transferring licences to new devices. Updates for eLux® can be found on the Fujitsu support pages or on the Internet at "www.myelux.com".
  • Page 28: Windows® 10 Iot Enterprise

    The write protect filter is not enabled in the delivery state, to make it easier to adapt the thin client to your requirements. Fujitsu strongly advises that the write protect filter should be enabled during normal operation, because only then is the typical thin client high security of the device guaranteed.
  • Page 29: Scout Enterprise Management Suite® - The Management Solution For Thin Clients

    • Support of Wake-On-LAN and Remote Power On/Off Mirroring of desktops, encrypted and audit-proof • • Extensive diagnostic information For more information on Scout Enterprise, go to "http://www.unicon-software.com/produkte/scout-enterprise/". More information and manuals are available on the Internet at "http://www.unicon-software.com/udocs". Fujitsu...
  • Page 30: Switching Off The Device

    BIOS Setup will be started. Select one of the tabs to access other setting options in BIOS Setup. PXE system boot PXEsystem boot ► Switch the device on with the ON/OFF switch. ► When starting the system, press the key several times. The boot menu is displayed. ► Select the desired boot option. Fujitsu...
  • Page 31: Bios Update

    BIOS Update When should a BIOS update be performed? Fujitsu Technology Solutions makes new BIOS versions available to ensure compatibility with new operating systems, new software or new hardware. In addition, new BIOS functions can be integrated. A BIOS update should also always be performed if there is a problem that cannot be solved using new drivers or new software.
  • Page 32: System Expansions And Repairs

    Servicing Information on system expansions and repairs can be found on the Internet in the "System Expansions and Repairs" manual at "http://www.fujitsu.com/fts/support". Operations that are distinguished in the manual as Only For Service, such as repairs to the device, may only however be performed by authorised service technicians.
  • Page 33: Technical Data

    Technical data Technical data Technicaldata FUJITSU Thin Client FUTRO S5010 / S7010 Electrical data Processor: • S5010: Intel Celeron J4025, Gemini Lake Dual Core 2.0 GHz (max. 2.9 GHz Single Core Burst Freq.) with integrated Intel UHD Graphics 600 •...
  • Page 34 100 - 240 V Max. rated current: 1.85 A Rated frequency: 50 - 60 Hz Only the following adapters with Limited Power Source may be used: S26113-E622-V55 Model ADP-40HH A • • S26113-E623-V55 Model ADP-65JH AB • CP500624-01 Model A12-065N2A A Fujitsu...
  • Page 35 External devices, Preparing for operation 22 connecting 20–21 Property protection 8 Protection, property and data 8 PXE system boot 26 Getting started 14 Recycling 13 Headphone port 6, 19 Retransportation 12 Headphones 19 connecting 21 Horizontal operating position 17 Fujitsu...
  • Page 36 Serial port 7, 19 connecting devices 21 Servicing 28 USB ports 7 Side cover 15 USB, System expansion 28 ports 6 System unit, see Device 12 Vertical operating position 15 Technical data 29 Transportation 12 Universal Serial Bus 19 Fujitsu...
