  • Page 1 Radar Speed Measurement Snapshot System (GUI Version) User’s Manual Version 1.0.0...
  • Page 2 Welcome Thank you for purchasing our product! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference!
  • Page 3 Important Safeguards and Warnings Please read the following safeguards and warnings carefully before using the product in order to avoid damages losses and body injuries. Note: Please transport, use and store the product under appropriate temperature and humidity.  Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric ...

  • Page 4: Table Of Contents

    Table of Contents System Introduction....................1 Overview ....................1 Technical Specifications ................1 Features ....................2 Main Function .................... 3 Installation ......................5 Structure ....................... 6 System Structure..................6 Appearance ....................6 Panel and Ports ..................9 3.3.1 Right Panel ..................9 3.3.2 Front Panel ..................
  • Page 5 4.6.6 System Information................43 Traffic Flow ....................44 Log......................46 User Management ..................48 Installation and Maintenance................. 50 Device Installation ..................50 5.1.1 Installation ..................50 5.1.2 Camera Debugging ................50 5.1.3 Radar Debug..................50 Device Maintenance ................. 50 5.2.1 Before Using Touch Screen ..............50 5.2.2 Use of Lithium Batteries and Maintenance Instructions......

  • Page 6: System Introduction

    It is easy to use and very convenient to install. It can be widely used in many areas. This series product also integrated the Dahua’s technical advantages in the security area. It is a perfect product integrating the security area and the intelligent transportation system together.

  • Page 7: Features

    It is free of the PC virus and OS vulnerability. The HWS800A series product adopts the Dahua’s technical advantages in the security area and intelligent traffic system (ITS) area. The host software circuit adopts the mature platform Dahua has already used in the ITS area.

  • Page 8: Main Function

     HWS800A series product integrates the high definition camera, host, LCD, touch panel, power, speed measurement radar, special image storage disk and etc together.  The compact construction and integrated design allows it to be used in either stationary or mobile environments.
  • Page 9 Function Description Dynamically real- Provide dynamically real-time preview function. Support display the time preview lane real-time monitor information via the LCD or Web. function Application platform supports the vehicle information search. Various Data search user right levels supported. Fuzzy search and data backup also supported.

  • Page 10: Installation

    2 Installation HWS800A Radar recommend the best location for the road from the edge of 1 to 3 m, and the angle between the radar and the roads default 22 ° , angle error ≤ ± 1 °; Radar forward undulating road surface must be flat and there is no turning no ;...

  • Page 11: Structure

    3 Structure 3.1 System Structure HWS800A speed measurement system includes power, embedded interactive snapshot host, radar, LCD screen and touch screen. The host is core of the system and it is mainly responsible for snapshot, flashlight sync, camera control, radar speed measuring and receiving this value, image storage, network transmission, USB downloading and GUI display.
  • Page 12 Figure 3- 2 HWS800A radar speed measurement 2...
  • Page 13 Figure 3- 3 HWS800A radar speed measurement 3...

  • Page 14: Panel And Ports

    3.3 Panel and Ports 3.3.1 Right Panel...
  • Page 15 Figure 3- 4 Please refer to the following sheet for detailed information. Line Color Description Orange Flashlight +(F+) Flashlight -(F-) Grey Flashlight +（F2+） Green Flashlight -（F2-） Strobe light + (S+) Black Strobe light - (S-) Purple Brown Blue Yellow Power switch DC19V power input port...

  • Page 16: Front Panel

    3.3.2 Front Panel Figure 3- 5 Please refer to the following sheet for detailed information. Icon Description Color Function Flashing: System is working properly. System running Green On: System has abnormity. indication light Off: system has stopped working. Flashing: Lithium battery is Lithium battery recharging now,.
  • Page 17 Figure 3- 6 Please refer to the following sheet for detailed information. Port Name Lithium battery Network, USB port, DC 12V power output and etc.

  • Page 18: Operation

    4 Operation 4.1 Boot up and Shut down Before your operation, please make sure all cable connections are right and the Lithium battery has inserted in the slot. 4.1.1 Boot up Push the power button in the side panel, you can see the red power indication light becomes on. The system is booting up now.
  • Page 19 Figure 4- 1 If it is your first time to use the system, please select the user name from the dropdown list and then input the corresponding password in the soft keyboard. You can create your own account to Figure 4- 2 login for the next time.

  • Page 20: Main Interface

    Figure 4- 2 4.2.2 Main Interface Figure 4- 3 The system main interface is shown as below. See It includes nine items: Flow Statistics, Road Monitoring, Log Management, Image Backup, Speed Snapshot, Image Queries, User Management, Sys Config and System Info. Please click the corresponding item in the touch panel to go to the second menu.

  • Page 21: Road Monitoring

     Date: The image snapshot date.  Time: The image snapshot time. The min unit is ms.  Speed and Speed limit: The vehicle real-time speed when snapshot this image and the speed limit in the snapshot region. The unit is km/h. ...

  • Page 22: Sys Configuration

    The road monitoring interface is shown as below. Here you can view vehicle real-time driving status. When you are debugging the system, you can go to the following figure to view the Figure 4- 5 camera effect. See  Brightness: Please click “-” and “+” button to adjust the brightness. The value ranges from 0 to 100.
  • Page 23  Car size adjust ratio: Adjust vehicle size recognition accuracy, range 1~15, default is 10.  Radar angle: Set measurement meter installation angle. The set angle must match actual condition, otherwise it will cause large error. Recommenced installation angle is: incoming 22°...
  • Page 24 Figure 4- 7 Note: Mounting distance: Set first lane distance from location where the device locates. This shall be based on actual distance. Recommend 150cm. Lane width: Set lane width. Based on actual lanes, and do not fill in extra lanes. For example, is lane quantity is e, then leave 4 and 6 lanes empty.

  • Page 25: Camera Setup

    Figure 4- 8 4.3.2 Camera Setup Figure 4- 9 The camera setting interface is shown as below. See  Frame interval: Time interval to trigger the second snapshot in one group of snapshot.  ANPR no.: Set ANPR snapshot number and enable, 1~2 optional. ...
  • Page 26 Figure 4- 9  Shutter: Only support single shutter for now.  Exposure: Manually input upper limit and lower limit via number keypad, range is 0 ~59880 microseconds, default is 0~800 microseconds.  Gain mode: Set gain mode, may select auto gain or fix gain.
  • Page 27 Figure 4- 10  Flash value: brightness threshold. Flashlight is enabled when lower than this value. Default is 15.  Flash mode: Set flashlight work mode, may select no flash, always and auto.

  • Page 28: Osd

    Figure 4- 11 4.3.3 OSD Figure 4- 12 Figure 4- 13 The OSD setting interface is shown as in  Section: Please select address from dropdown list. You can load, add, modify and delete address. The detailed address can be entered via WEB client, local keyboard. Violation location is shown on more than one page which can be viewed with scroll.
  • Page 29  OSD option: System supports the OSD function. You can check the box below to overlay the corresponding information in the image. The default setup includes thirteen items: time and date, address, plate, speed, direction, speed limit, radar direction, device SN, vehicle type, offence type, valid time and etc.

  • Page 30: Network

    Figure 4- 13 4.3.4 Network Figure 4- 14. The network setting interface is shown as in  Host IP: Here you can set host IP address.  Net mask: Here you can set host subnet mask.  Gateway IP: Here you can set host gateway. ...

  • Page 31: Server

    Figure 4- 14 4.3.5 Server Figure 4- 15 The server setting interface is shown as in  Function: You can check the box here to enable or disable the server connection function.  Server IP: Here you can input server IP address. ...

  • Page 32: Time

    Figure 4- 15 4.3.6 Time Figure 4- 16 The time setting interface is shown as in  Function: You can check the box here to enable or disable the function.  Time server IP: Please input NTP server IP address here. ...

  • Page 33: Ftp

    Figure 4- 16 4.3.7 FTP Figure 4- 17 FTP setting interface is shown as in  Function: You can check the box here to enable or disable the function.  FTP Server IP: Here you can input FTP server IP address. ...

  • Page 34: System

    Figure 4- 17 4.3.8 System Figure 4- 18 The system interface is shown as in  Sys maintenance: It is to set system auto maintenance function and maintenance time. You can select from the dropdown list. The option includes: never/Sunday/Monday/Tuesday/ Wednesday/Thursday/Friday/Saturday/everyday.

  • Page 35: Intelligent

    Figure 4- 18 4.3.9 Intelligent Figure 4- 19 The intelligent interface is shown as in  License plate rec: You can check the box here to enable or disable the plate recognition function. System automatically recognizes the plate number and plate color after snapshot if you enable this function here.

  • Page 36: White/Black List

    Figure 4- 19 4.3.10 White/Black List The trusted/black list interface is shown in Figure 3-18 and Figure 3-19. Input plate no.: Enter plate no. of vehicle to search. Support fuzzy search. Query: Display search result. White/Black list enable: Enable or disable this function. Load white/black list: Support USB import of these lists from USB.
  • Page 37 Figure 4- 20 Figure 4- 21...

  • Page 38: Image Queries

    4.4 Image Queries  Search by time Figure 4- 22 The interface is shown as in There are four time periods: one day/three days/one week/all. It also supports customize setup. Please click the “Custom” button to set. Figure 4- 22 ...
  • Page 39 Figure 4- 23  Search by Blacklist Figure 4- 24 The interface is shown as in There are four time periods: one day/three days/one week/all. It also supports customize setup. Or you can click the “Custom” button to customize.
  • Page 40 Figure 4- 24 In Query interface, you can see the image SN, snapshot time, speed, and vehicle plate and vehicle type. System displays the 8 records in one screen by default. You can use the previous/next button to view more images. ...

  • Page 41: Image Backup

    Figure 4- 25 4.5 Image Backup Figure 4- 26 The image backup includes three modes: Backup by time ( )/backup by speed Figure 4- 27 Figure 4- 28 )/backup by blacklist ( Backup by time and backup by speed are USB backup. During the backup process, you can see the corresponding process bar for your reference.
  • Page 42 Figure 4- 26 Figure 4- 27...

  • Page 43: System Information

    Figure 4- 28 4.6 System Information 4.6.1 Version Information Figure 4- 29 The device status interface is shown as below. See  Software version: Here you can view the software main version including the compile date.  Hardware version: Here you can view the hardware main version. ...

  • Page 44: Device Information

    Figure 4- 30 The device information interface is shown as below. See  Device type: The default type is HWS800A.  Device SN: It is the device serial number when it shipped out of the factory. Please note it is read-only.

  • Page 45: Network Status

    Figure 4- 30 4.6.3 Network Status Click the “Network status” button; you can see an interface shown as in Figure 4- 31 Here you can view network connection information including the user name, IP port and user type. The user type includes: WEB, network upgrade tool and platform software.

  • Page 46: Peripheral Device Information

    Figure 4- 31 4.6.4 Peripheral Device Information Click “Peripheral device information” button, you can see an interface is shown as in Figure 4-  Radar: It is the radar working status of current speed measuring system. It displays as OK when the radar works properly.

  • Page 47: Storage Status

    Figure 4- 32 4.6.5 Storage Status Click “Storage status”, system pops up the following interface. See Figure 4- 33  Storage type: Select display HDD or USB disk info.  Pic remainder space/capacity: Display picture storage total capacity and free space. ...

  • Page 48: System Information

    Figure 4- 33 4.6.6 System Information Figure 4- 34 The system information interface is shown as in  CPU usage: Here you can view current CPU usage status. It is shown as XX.XX%.  Memory usage: Here you can view current memory usage status. It is shown as XX.XX%. ...

  • Page 49: Traffic Flow

    Figure 4- 34 4.7 Traffic Flow Figure The traffic flow statistics has two modes: by time (unit:: second) and by speed range. See 4- 35 Figure 4- 36 . You can refer to the Image search interface for detailed information. ...
  • Page 50 Figure 4- 35 Figure 4- 36 Figure 4- 37 The traffic flow statistics result is shown as in . It displays in column diagram.

  • Page 51: Log

    System supports export via the USB device. You can insert the flash disk to the USB port and then click the “Export” button to export current statistics results in txt file. Figure 4- 37 4.8 Log Figure 4- 38 System supports two log search modes: search by time period ( ) and search by Figure 4- 39 user name (...
  • Page 52 Figure 4- 38 Figure 4- 39 Figure 4- 40 The log search results interface is shown as in...

  • Page 53: User Management

    The searched results displayed in a sheet. There are total four columns: SN, time, details, and user name. There are 16 items in one screen. You can use the “Previous” and “Next” button to view more logs. Important Clear function here is to delete all logs in the system. Before the operation, please make sure you really want to remove all logs! Figure 4- 40 4.9 User Management...
  • Page 54 Figure 4- 41...

  • Page 55: Installation And Maintenance

    5 Installation and Maintenance 5.1 Device Installation 5.1.1 Installation Take the device out of the box.   Insert the Lithium battery. Put the device on the tripod and adjust to the proper height.  Push the power button to boot up the device. ...

  • Page 56: Before Using Radar

     Ambient temperature higher than 60 ℃ Do not use lithium batteries; when the ambient temperature around 0 ℃, use 2/3 electricity shortage, when the ambient temperature around -10 ℃, using a drained 1/3; for lithium batteries at temperatures between 0 ℃ ~ 45 ℃. ...
