Parts List - Linear Technology DC1601B Demo Manual

PARTS LIST

Demo Board 1601B-A
ITEM QTY REFERENCE
Required Circuit Components:
1 1 DC1601 (COMMON BOM)
2 1 R4
3 1 R5
4 1 R22
5 2 U1, U3
Additional Demo Board Circuit Components:
1 0 CIN11, CIN12, CIN15, CIN16
(OPT)
2 0 CO17, CO18, CO25, CO26
(OPT)
3 0 C8, C10 (OPT)
4 0 L3, L4 (OPT)
5 0 R14 TO R21 (OPT)
6 0 RS5 TO RS8 (OPT)
7 0 U4, U5 (OPT)
Demo Board 1601B-B
ITEM QTY REFERENCE
Required Circuit Components:
1 1 DC1601 (COMMON BOM)
2 2 CIN11, CIN12
3 2 CO17, CO18
4 1 C8
5 1 L3
6 1 R5
7 4 R14 TO R17
8 1 R22
9 2 RS5, RS6
10 3 U1, U3, U4
Additional Demo Board Circuit Components:
1 0 CIN15, CIN16 (OPT)
2 0 CO25, CO26 (OPT)
3 0 C10 (OPT)
4 0 L4 (OPT)
5 0 R4, R18 TO R21 (OPT)
6 0 RS7, RS8 (OPT)
7 0 U5 (OPT)
PART DESCRIPTION
RES, CHIP , 0Ω, 0603
RES, CHIP , 154k, 1/16W, 1%, 0603
RES, CHIP , 3.57k, 1/16W, 1%, 0603
IC, LTM4607EV#PBF , 15mm × 9mm × 2.3mm
CAP , 1206
CAP , 1812
CAP , 0603
IND IRON POWER SMT FIXED, 3.3μH
RES, CHIP , 0603
RES, CHIP , 1206
IC, LTM4607EV#PBF , 15mm × 9mm × 2.3mm
PART DESCRIPTION
CAP , X7R, 4.7μF , 50V, 10%, 1206
CAP , X5R, 22μF , 16V, 20%, 1812
CAP , NPO, 22pF , 50V, 5%, 0603
IND IRON POWER SMT FIXED, 3.3μH
RES, CHIP , 205k, 1/16W, 1%, 0603
RES, CHIP , 0Ω, 0603
RES, CHIP , 2.37k, 1/16W, 1%, 0603
RES, CHIP , 0.015Ω 1/2W, 1%, 1206
I.C., LTM4607EV#PBF , 15mm × 9mm × 2.3mm
CAP , 1206
CAP , 1812
CAP , 0603
IND IRON POWER SMT FIXED, 3.3μH
RES, CHIP , 0603
RES, CHIP , 1206
IC, LTM4607EV#PBF , 15mm × 9mm × 2.3mm
DEMO MANUAL DC1601B
MANUFACTURER/PART NUMBER
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603154KFKEA
VISHAY, CRCW06033K57FKEA
LINEAR TECHNOLOGY, LTM4607EV#PBF
LINEAR TECHNOLOGY, LTM4607EV#PBF
MANUFACTURER/PART NUMBER
MURATA, GRM31CR71H475K
TDK, C4532X7R1C226M
AVX, 06035A220JAT2A
TOKO, FDA1254-3R3M=P3
VISHAY, CRCW0603205KFKEA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW06032K37FKEA
VISHAY, WSL1206R0150FEA
LINEAR TECHNOLOGY, LTM4607EV#PBF
LINEAR TECH., LTM4607EV#PBF
dc1601bf
7
