DEMO MANUAL DC2028A

pArts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 U6
2 3 C12, C18, C19
Additional Demo Board Circuit Components
3 8 C1, C2, C3, C4, C28, C29, C30,
C31
4 9 C5, C6, C7, C8, C21, C22, C23,
C24, C41
5 1 C9, C45
6 11 C10, C20, C37, C38, C39, C40,
C46, C50, C51, C52, C53
7 2 C11, C49
8 9 C13, C33, C34, C35, C36, C54,
C55, C56, C57
9 1 C14
10 7 C15, C16, C17, C25, C26, C27,
C42
11 1 C32
12 2 C43, C47
13 1 C44
14 1 C48
15 1 D1
16 8 L1, L2, L3, L4, L6, L7, L8, L9
17 1 L5
18 9 LED3, P1, P2, P3, P4, P5, P6, P7,
P8
19 2 LED1, LED2
20 9 Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8,
Q9
21 17 R1, R2, R3, R4, R37, R38, R39,
R40, R45, R46, R47, R48, R68,
R80, R81, R82, R83
22 1 R5
23 1 R6
24 1 R7
25 1 R8
26 9 R9, R10, R11, R12, R16, R26,
R27, R28, R29
27 12 R14, R18, R19, R22, R23, R30,
R35, R36, R57, R58, R60, R88
28 2 R15, R71
29 1 R17
30 2 R20, R25
31 1 R21
32 2 R24, R59
18
PART DESCRIPTION
IC 8-CH PWR SYSTEM MANAGER 64-QFN
CAP CER 0.1µF 16V 10% X7R 0603
CAP CER 220pF 50V 10% NPO 0603
CAP CER 10µF 10V 10% X5R 1210
CAP CER 10µF 25V 20% X5R 1206
CAP CER 0.1µF 16V 10% X7R 0603
CAP CER 68pF 50V 5% NPO 0603
CAP CER 22µF 10V 10% X5R 1210
CAP CER 47pF 50V 5% NPO 0603
CAP CER 1µF 16V 10% X7R 0603
CAP TANT 47µF 16V 20% 2917
CAP CER 4.7µF 16V 10% X5R 0603
CAP CER 10000pF 25V 10% X7R 0603
CAP CER 4.7pF 50V NPO 0603
DUAL DIODE SCHOTTKY 30V CC SOT-323-3
INDUCTOR SHLD POWER 4.7µH SMD
INDUCTOR POWER 2.2µH 2.85A SMD
LED GREEN SS TYPE BRIGHT SMD
LED RED HI BRT SS TYPE LO CUR SM
MOSFET N-CH 30V 900MA SOT323-3
RES 100kΩ 1/10W 1% 0603 SMD
RES 200kΩ 1/10W 1% 0603 SMD
RES 115kΩ 1/10W 1% 0603 SMD
RES 80.6kΩ 1/10W 1% 0603 SMD
RES 66.5kΩ 1/10W 1% 0603 SMD
RES 3.01kΩ 1/10W 1% 0603 SMD
RES 10.0kΩ 1/10W 1% 0603 SMD
RES 73.2kΩ 1/10W 1% 0603 SMD
RES 46.4kΩ 1/10W 1% 0603 SMD
RES 249Ω 1/10W 1% 0603 SMD
RES 1.00kΩ 1/10W 1% 0603 SMD
RES ARRAY 10kΩ 4 RES 1206
MANUFACTURER/PART NUMBER
Linear Technology: LTC2977CUP
NIC: NMC0603X7R104K16TRPF
NIC: NMC0603NPO221J50TRPF
AVX: 1210ZD106KAT2A
Taiyo Yuden: TMK316BJ106ML-T
NIC: NMC0603X7R104K16TRPF
AVX: 06035A680JAT2A
Kemet: C1210C226K8PACTU
AVX: 06035A470JAT2A
Taiyo Yuden: EMK107B7105KA-T
Kemet: T520D476M016ATE035
TDK: C1608X5R1C475K
TDK: C1608X7R1H103K
Murata: GRM1885C1H4R7CZ01D
Diodes/Zetex: SBR0330CW-7
Abracon Corporation: ASPI-0315FS-4R7M-T2
Vishay: IHLP1616BZER2R2M01
Panasonic - SSG: LNJ337W83RA
Panasonic - SSG: LNJ208R8ARA
Vishay/Siliconix: SI1308EDL-T1-GE3
Vishay: CRCW0603100KFKEA
Vishay: CRCW0603200KJNEA
Vishay: CRCW0603115KFKEA
Vishay: CRCW060380K6FKEA
Vishay: CRCW060366K5FKEA
NIC: NRC06F3011TRF
Vishay: CRCW060310K0FKEA
Vishay: CRCW060373K2FKEA
NIC: NRC06F4642TRF
NIC: NRC06F2490TRF
NIC: NRC06F1001TRF
Vishay Dale: CRA06S08310K0JTA
