DEMO MANUAL DC1601B
PARTS LIST
Demo Board 1601B-C
ITEM QTY REFERENCE
Required Circuit Components:
1 1 DC1601 (COMMON BOM)
2 4 CIN11, CIN12, CIN15,
CIN16
3 4 CO17, CO18, CO25, CO26
4 2 C8, C10
5 2 L3, L4
6 9 R4, R14 TO R21
7 1 R5
8 1 R22
9 4 RS5 TO RS8
10 4 U1, U3, U4, U5
8
PART DESCRIPTION
CAP , X7R, 4.7μF , 10%, 50V, 1206
CAP , X5R, 22μF , 16V, 20%, 1812
CAP , NPO, 22pF , 50V, 5%, 0603
IND IRON POWER SMT FIXED, 3.3μH
RES, CHIP , 0Ω, 0603
RES, CHIP , 154k, 1/16W, 1%, 0603
RES, CHIP , 1.78k, 1/16W, 1%, 0603
RES, CHIP , 0.015Ω 1/2W, 1%, 1206
IC, LTM4607EV#PBF , 15mm × 9mm × 2.3mm
MANUFACTURER/PART NUMBER
MURATA, GRM31CR71H475K
TDK, C4532X7R1C226M
AVX, 06035A220JAT2A
TOKO, FDA1254-3R3M=P3
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603154KFKEA
VISHAY, CRCW06031K78FKEA
VISHAY, WSL1206R0150FEA
LINEAR TECHNOLOGY, LTM4607EV#PBF
dc1601bf
