DEMO MANUAL DC1601B
PARTS LIST
ITEM QTY REFERENCE
Common Required Circuit Components:
1 2 CIN1, CIN6
2 4 CIN2, CIN3, CIN7, CIN8
3 4 CO1, CO4, CO9, CO10
4 4 CO2, CO3, CO11, CO12
5 1 CSS1
6 1 C4
7 2 C3, C6
8 2 L1, L2
9 4 RS1 TO RS4
10 1 R1
11 4 R10 TO R13
12 4 R6, R7, R8, R9
13 1 U2
Common Additional Demo Board Circuit Components:
1 0 C1, C2, C5, C7, C9 TO C17
2 CFF1, CP1 TO CP4 (OPT)
3 0 CO7, CO15, CO23, CO31, CIN9,
4 CIN4, CIN5, CIN13, CIN17 (OPT)
5 0 CIN10, CIN14 (OPT)
6 0 CO28 (OPT)
7 0 RUVLO1, R3, (OPT)
8 0 CO19, CO20, CO27 (OPT)
9 0 CO5, CO13, CO21, CO29 (OPT)
10 1 D1
11 1 R2
12 1 R23
Common Hardware:
1 1 JP1
2 2 JP2, JP3
3 3 JP1, JP2, JP3
4 8 TP1, TP3, TP6, TP8 TO TP12
5 8 TP2, TP4, TP5, TP7(X2)
6 4 TP2, TP4, TP5, TP7
7 4 TP2, TP4, TP5, TP7
8 4 TP2, TP4, TP5, TP7
9 4 STAND OFF
6
PART DESCRIPTION
CAP , ALUM, 100μF , 20%, 50V
CAP , X5R, 4.7μF , 10%, 50V, 1206
CAP , X5R, 22μF , 25V, 20%, 1812
CAP , OS-CON, 180μF , 16V, E9
CAP , X7R, 0.01μF , 25V, 10%, 0603
CAP , X5R, 0.1μF , 25V, 10%, 0603
CAP , COG, 22pF , 25V, 10%, 0603
IND IRON POWER SMT FIXED, 3.3μH
RES, CHIP , 0.015Ω 1/2W, 1%, 1206
RES, CHIP , 100k, 1/16W, 5%, 0603
RES, CHIP , 0Ω, 0603
RES, CHIP , 100Ω, 1/16W, 1%, 0603
IC, LTC6902CMS
CAP , 0603
CAP , 1206
CAP , ALUM, SIZE 8mm × 12.5mm
CAP , OS-CON, 180μF , 16V, E9
RES, CHIP , 0603
CAP , OS-CON, F8
CAP , D3L
ZENER DIODE, 4.7V
RES, CHIP , 5.1k, 1/16W, 5%, 0805
RES, CHIP , 0, 1206
2mm SINGLE ROW HEADER, 3-PIN
2mm SINGLE ROW HEADER, 4-PIN
SHUNT
TESTPOINT, TURRET, 0.095"
STUD, TESTPIN
NUT, BRASS 10-32
RING, LUG #10
WASHER, TIN PLATED BRASS
STAND-OFF , NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
SUNCON, 50ME100WX+TS
TAIYO YUDEN, UMK316BJ475KL-T
TDK, C4532X5R1E226M
SANYO, 16SEPC180MX+T
AVX, 06033C103KAT4A
AVX, 06033D104KAT4A
AVX, 06033A220KAT4A
TOKO, FDA1254-3R3M=P3
VISHAY, WSL1206R0150FEA
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603100RFKEA
LINEAR TECHNOLOGY, LTC6902CMS#PBF
SANYO, 16SEPC180MX
CENTRAL SEMI, CMDZ5230B-7-F
VISHAY, CRCW08055K10JNEA
VISHAY, CRCW12060000Z0EA
SAMTEC, TMM-103-02-L-S
SAMTEC, TMM-104-02-L-S
SAMTEC, 2SN-BK-G
MILL-MAX, 2501-2-00-80-00-00-07-0
PEM KFH-032-10
ANY #10-32
KEYSTONE #10
ANY #10
KEYSTONE, 8833 (SNAP ON)
