Linear Technology DC1601B Demo Manual page 5

QUICK START PROCEDURE
V
OUT
50mV/DIV
I
OUT
STEP 5A/DIV
V = 9V, V = 12V
IN OUT
I DC = 5A, I STEP = 5A
OUT OUT
f = 300kHz
SW
Figure 4a. Measured Load Step Response (DC1601B-A)
V
OUT
20mV/DIV
I
OUT
STEP 5A/DIV
V = 12V, V = 12V
IN OUT
I DC = 7.5A, I STEP = 7.5A
OUT OUT
f = 300kHz
SW
Figure 4b. Measured Load Step Response (DC1601B-B)
V
OUT
200mV/DIV
I
OUT
STEP 10A/DIV
V = 32V, V = 12V
IN OUT
I DC = 10A, I STEP = 10A
OUT OUT
f = 300kHz
SW
Figure 4c. Measured Load Step Response (DC1601B-C)
DEMO MANUAL DC1601B
V
OUT
20mV/DIV
DC1601b F04a
V = 9V, V
IN
I = 10A
OUT
f = 300kHz
SW
Figure 5a. Measured Output Voltage Ripple (DC1601B-A)
V
OUT
20mV/DIV
DC1601b F04b
V = 12V, V
IN
I = 15A
OUT
f = 300kHz
SW
Figure 5b. Measured Output Voltage Ripple (DC1601B-B)
V
OUT
20mV/DIV
DC1601b F04c
V = 32V, V
IN
I = 20A
OUT
f = 300kHz
SW
Figure 5c. Measured Output Voltage Ripple (DC1601B-C)
= 12V
OUT
= 12V
OUT
= 12V
OUT
DC1601b F05a
DC1601b F05b
DC1601b F05c
dc1601bf
5
