INSTALLATION GUIDE
COMPONENTS
I
J
L
K
H
G H
A
Stake (2 identical components)
B
Main pole holder
C
Pivot
D
Pivot base
E
Removable front cover
F
Pressure plate
G
Tapping block
D
C
F
E
Important
(plastic or wood)
- 3 -
B
Assemblies including 15 mm yellow
flange nuts (integrated washer
nuts), you will not have flat washers
in your kit.
L
H
Tapping block Holder
(plastic or wood)
I
Handle bolts
J
Bolts
K
15 or 17 mm nuts
L
Flat washers
flange nuts (integrated washer nuts),
you will not have flat washers in your kit.
