iNetVu 7000 Series Quick Start Manual

Hide thumbs Also See for 7000 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Hughes Ka and the iNetVu® 7000 Series Controller
HN 9600/9800
Ka broadband satellite Routers with single IFL
cable
HN 9200/9260
Dual Ka/Ku Band
HN 9400/9460
Dual Ka/Ku-band broadband satellite Router
1-877-iNetVu6
www.c-comsat.com
Revision 3.1
January 18, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iNetVu 7000 Series

Summary of Contents for iNetVu 7000 Series

  • Page 1 Hughes Ka and the iNetVu® 7000 Series Controller HN 9600/9800 Ka broadband satellite Routers with single IFL cable HN 9200/9260 Dual Ka/Ku Band HN 9400/9460 Dual Ka/Ku-band broadband satellite Router 1-877-iNetVu6 www.c-comsat.com Revision 3.1 January 18, 2018...
  • Page 2 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA This page is intentionally left blank.

  • Page 3: Safety And Warning Information

    For your safety and protection the following important safety information should be reviewed before installation, configuration and use of the iNetVu Satellite Platform System and Modem equipment. It is also recommended to read the manual in its entirety prior to setup and operation.

  • Page 4: System Overview

    DSL do not exist. It provides two-way, high-speed data communications over satellite. iNetVu™ empowers mobile users with the ability to stop anywhere there is Satellite coverage and access Internet at broadband speeds. The iNetVu™ Mobile application consists of the iNetVu™ Mobile software 7000 software (for the 7000 Series Controller) iNetVu™...

  • Page 5: Pre-Configuration Check List

    INETVU® MOBILE SYSTEM QUICK START – HUGHES KA Pre-Configuration Check List The following items should be completed/known prior to configuring the iNetVu® Mobile System. Contact the Network Operation Center (NOC) or ISP if any of the following items are unknown or if you are unfamiliar with them.
  • Page 6 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA ➢ Set computer IP to 192.168.0.2(only for this verification step otherwise pc IP should be set to 192.168.0.3) to access modem system control center. See section 1.3 for more details on how to set pc IP. Difference between modem IP and PC IP should be A.B.C.D+1.
  • Page 7 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA System Wiring with Hughes (HN_KA) Service USB Interface Connection – System Wiring with Splitter iNetVu® Mobile Platform Motor Control Cable Sensor Cable RG6 Coaxial Cable Network Cable Power Cable GPS /Glonass Antenna...
  • Page 8 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA Network Interface Connection – Hughes (HN_KA) System Wiring iNetVu® Mobile Platform Motor Control Cable GPS/Glonass Sensor Cable Antenna RG6 Coaxial Cable Network Cable SENSOR MOTOR CONTROL Power Cable USB Cable HN 9200/9400...
  • Page 9 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA Network Interface Connection – (HN_KA) 9600/9800 System Wiring iNetVu® Mobile Platform Motor Control Cable Sensor Cable GPS/Glonass RG6 Coaxial Cable Antenna Network Cable SENSOR MOTOR CONTROL Power Cable USB Cable HN 9600/9800...
  • Page 10 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA USB Interface Connection – (HN_KA) 9600/9800 System Wiring iNetVu® Mobile Platform Motor Control Cable Sensor Cable RG6 Coaxial Cable Network Cable Power Cable GPS /Glonass Antenna USB Cable HN 9600/9800 *Ground protection...
  • Page 11 The 7000 Controller may be configured via the Software Application / Web Interface / LCD interface. Only one is necessary for complete configuration. iNetVu® Software Application (preferred method) First time user should use the iNetVu Wizard which is imbedded into the iNetVu software for guidance in configuring your system. ▪...

  • Page 12: Tips And Recommendations

    Platform type. This value can be overridden to a more desirable range. Override Compass can be selected without selecting Full Search but this does not hold true for the vice-versa. Refer to Controller User Manual for more information on using the iNetVu Controller and options associated with your system.
  • Page 13 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA 1.11 Software Setup and Initial Configuration Procedure with Hughes 9200/9260/9400/9460/9600&9800 Series Modems 1. If you are using the network interface to communicate with the 7000 Controller, set the PC/Notebook to the same network as the 7000 Controller.
  • Page 14 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA 5. Set the 7000 Controller to the same network as the PC and VSAT Modem. *Note: The controller IP should be set in the controller through the LCD interface prior to entering it into the software tool for proper PC to Controller Communication through network interface.

  • Page 15: Software Installation And Configuration

    3. Install both the FTDI USB Driver and USB Driver. Exit the Wizard when complete. 4. Now connect the Controller to the PC using the provided USB cable. 5. Ensure the software is running as Administrator. 6. You can now run the iNetVu Mobile 7000 software from the shortcut on your desktop.

  • Page 16: Inetvu Setup Wizard

    INETVU® MOBILE SYSTEM QUICK START – HUGHES KA 1.13 iNetVu Setup Wizard 1. The first screen you will see is the new iNetVu Setup Wizard. You can choose to continue using the wizard or click NO to proceed to the iNetVu Mobile 7000 software.
  • Page 17 3. Follow the on-screen instructions to update the controller firmware. Once complete the wizard will resume. 4. You may wish to continue through the wizard to complete the controller configuration or verify the settings. You can switch to the iNetVu software at any time by right clicking and selecting Controls.
  • Page 18 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA 5. Configure the Platform Type, Version and Serial No. If no changes are needed press “Next” to continue. Platform Type: Antenna Model Version: Antenna Version Serial No: Antenna Serial Number It is important that this information be correct or will result in undesired antenna behavior.
  • Page 19 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA 6. Complete the Service Information section, set to HN_KA as the Service Type. Select the Interface method you wish to use and configure accordingly. Mouse over each selection for a detailed description. After changes have been made please click “Next” to continue.
  • Page 20 INETVU® MOBILE SYSTEM QUICK START – HUGHES KA 7. Complete the Satellite Parameters, DVB Settings and Search Method. Mouse over each selection for a detailed description. Click Finish when complete. No changes are needed. Please click Finish to complete the setup.
  • Page 21 8. Once completed you will be able to save changes by selecting Yes, or select No to return to the previous screen to make additional changes. 9. Congratulations you have configured your iNetVu Controller. You can now find satellite by pressing the FIND SAT button from the front panel or by launching the iNetvu Software.
  • Page 22 BEAM. This must be done by manually by the installer. See New Gen Mobile Platform Installation Manual for more information. ® ® *For more detailed information on the iNetVu 7000 Series Controller Software, refer to the iNetVu 7000 Series Controller Manual.
