LOXONE Touch Pure Air Series Quick Start Manual

Advertisement

Quick Links

Technical Specifications
Power Supply
CR2450
Safety Protection
IP40
Capacitive Touch
5 Touch points
Ambient Temperature
-20...60°C / -4...140°F
Temperature Detection Range
-40...125°C / -40...257°F
+/- 0.5°C /0.9°F
Humidity Detection Range
0...100% r.H. +/- 2%
(non condensing)
Radio Frequency
868MHz (SRD Band Europe),
915MHz (ISM Band Region 2)
max. Power 3.16mW
Dimensions
90x90x11mm /
3.54x3.54x0.43" (LxWxH)
Maintenance & Cleaning
This device is free of main-
tenance and may only be
cleaned with a dry cloth.
Information
Contains FCC ID: COR-ZWIR4512AC1
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received,
including interference that may cause undesired operation
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Touch
Pure
Air
Part No: 100206 (White)
Part No: 100208 (Anthracite)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Touch Pure Air Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LOXONE Touch Pure Air Series

  • Page 1 Pure 3.54x3.54x0.43” (LxWxH) Maintenance & Cleaning This device is free of main- tenance and may only be cleaned with a dry cloth. Loxone Electronics GmbH Information Smart Home 1 Contains FCC ID: COR-ZWIR4512AC1 4154 Kollerschlag Part No: 100206 (White) This device complies with part 15 of the FCC Rules.
  • Page 2 About the product The Loxone Touch Pure has five touch zones, which can be configured according to your needs. The large central touch zone is ideal for controlling lighting, whilst the corner zones are handy for controlling music and blinds, for example.
