  • Page 1 DMX2CC 6ch/12ch Setup Manual © e:cue lighting control An OSRAM Company www.ecue.com Rev. 20101201...

  • Page 2: Table Of Contents

    DMX2CC 6ch/12ch Table of Contents Device Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Key Features ................4 Applications ................5 Delivery content .
  • Page 3 DMX2CC 6ch/12ch Firmware update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Update with a PC ..............25 Updating DMX2CC master to slave ..........26 Master/slave update FAQ ............28...

  • Page 4: Device Overview

    DMX2CC 6ch/12ch Device Overview DMX2CC dimmers can control high-power LED fixtures by a DMX signal using linear current dimming. They are designed for use with both high-power 1W and 3W LED fixtures. The two versions 6CH and 12CH provide control over 6 or 12 individual channels, which allows control of 2 or 4 high-power RGB triplets, respectively.

  • Page 5: Applications

    DMX2CC 6ch/12ch • Auto Load Detection - Allows connection of 1 to 12 serial LEDs per channel • Wrong wiring, open/short protection for each output with indication on LCD checked on startup • TP - Thermal Protection of LEDs on each output (on supported LED luminaries) •...
  • Page 6 DMX2CC 6ch/12ch Safety instructions Any usage other than described in this manual is not permitted, can damage the device and lead to associated risks such as short- circuit, fire or electric shock. If not otherwise noted, no part of the product may be modified or rebuilt. DMX2CC 6CH / 12CH ports must not be hot plugged.

  • Page 7: Delivery Content

    DMX2CC 6ch/12ch Delivery content • DMX2CC 6ch or 12ch • 2 x pluggable terminal block connectors (for DMX2CC 6ch) • 4 x pluggable terminal block connectors (for DMX2CC 12ch) • This setup manual Firmware level This setup manual refers to firmware version 1.7. See Firmware update on page 25 how to upgrade the firmware.

  • Page 8: Hardware Installation

    DMX2CC 6ch/12ch Hardware installation Mounting The DMX2CC driver is designed to snap onto a standard DIN rail for installation in a wall mount enclosure. LED-wiring connections are made using pluggable screw terminals, the DC Power In connections are made using the captive screws and the RJ-45 DMX512 input/output positioned along the top, clearly accessible from the front for easy installation and servicing.

  • Page 9: Connectors And Wiring

    DMX2CC 6ch/12ch Connectors and wiring...

  • Page 10: Led Wirings Test

    DMX2CC 6ch/12ch LED Wirings Test The DMX2CC has a unique algorithm for detecting load type and wrong LED connections. It can detect if the LED’s (+) and (-) lines are having a short circuit between them or mixed connection with a neighbour channel inside the terminal plug.

  • Page 11: Psu Selection Guidelines

    DMX2CC 6ch/12ch PSU Selection Guidelines Please follow the PSU selection guidelines below in order to select the correct power supply. Use at least 15 AWG (1.5mm ) for DC power-in connection. It is highly recommended to connect all four terminals of the power-in captive screw terminal. Maintain correct polarity when connecting the power supply.

  • Page 12: Cable Type And Length Limitations

    DMX2CC 6ch/12ch Cable type and length limitations At driving current 350 mA AWG COPPER Diameter mm Ohms Max amps for Voltage max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs per km power trans- drop 100m 150m...
  • Page 13 DMX2CC 6ch/12ch max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs 100m 150m 200m 250m 300m 400m 500m max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs max. LEDs 100m 150m 200m 300m 400m 500m...

  • Page 14: Led Output Wiring

    DMX2CC 6ch/12ch LED output wiring Please refer to the previous cable type/length limitations tables for the selection of the correct cable type. The DMX2CC driver features the TP - Fixture Thermal Protection which protects the LED fixture from overheating while maintaining light output.

  • Page 15: Dmx Wiring

    DMX2CC 6ch/12ch DMX wiring Pin assignment DMX IN DMX Out Signal Signal Data - Data + N.C. +16 VDC/0.3 A N.C. N.C. N.C. N.C. N.C. N.C. N.C. The onboard 16 VDC can be used to supply power to a DMX controller from the DMX IN RJ-45 connector. The DMX2CC has an active DMX signal repeater which eliminates the need of DMX splitter/repeaters when daisy chaining DMX2CCs.

  • Page 16: Power-Up Sequence

    DMX2CC 6ch/12ch Power-up sequence After applying power to the Unit, it will perform a quick self test for correct Output LED wiring and a proper voltage from the DC Power Supply. Each of these tests is followed by corresponding messages on the LCD screen. Power supply test After power-up the following message is displayed on the LCD screen: V1.2-DX...
  • Page 17 DMX2CC 6ch/12ch...

  • Page 18: Menu Navigation

    DMX2CC 6ch/12ch Menu navigation Press ▲ and ▼ to navigate through the options/change DMX-512 setting Preset Press ↲ to enter sub menu/confirm changes Press ESC to go back to the previous menu/discard ▲ ▼ ↵ changes DMX mode This is the mode for standard DMX control. DMX: 1 This mode is for standard DMX512 signal control.

  • Page 19: Status Menu

    DMX2CC 6ch/12ch Status menu From this menu you can check the system status of the DMX2CC 6/12 driver. • PSU voltage – Power Supply Unit voltage • Driver Temperature – Shows the temperature of the internal PCB of the driver (approx. value and only accurate for temperatures > 40 °C) •...

  • Page 20: Dmx Setup

    DMX2CC 6ch/12ch DMX setup Setup of DMX addressing. Address In this menu, you can change the DMX address of the unit Autoaddre and enable / disable the auto-addressing function. Address: • Press ▲ and ▼ to change the DMX address of the unit (hold ▲...

  • Page 21: Number Of Channels

    DMX2CC 6ch/12ch To adjust the contrast: • Press ▲ and ▼ to change the contrast level. • Press ↲ to save & exit. • Press ESC to exit without saving. Number of channels You can limit the maximum number of control channels from 1 to 12 (DMX2CC6: 1 - 6, DMX2CC12: 1 - 12).

  • Page 22: Output Status Menu

    DMX2CC 6ch/12ch • Press ▲ and ▼ to change the highlighted digit. • Press ↲ to save & exit. • Press ESC to exit without saving. Available options are: • Current rating: Press ▲ and ▼ to change the current rating of the unit (hold ▲...

  • Page 23: Channel Statistics

    DMX2CC 6ch/12ch If no LEDs are connected to this output Unplugged is displayed. CHxx:OK indicates that LEDs are connected to this channel. CH1:OK CHxx: Unplugged indicates that no LEDs are connected to CH2:OK that channel. Press ▲ and ▼ to scroll between the tree channels of the selected the outputs. Two bottom statistics are thermal feedbacks (only available on supporting fixtures with thermal sensors on-board) from the fixture connected to the output.
  • Page 24 DMX2CC 6ch/12ch is stabilized within the allowed limitations. If the environment temperature declines, the unit will raise the level of the current passing through the fixture. The changes of current will not affect the color of the light; but only its intensity. It should be noted that the light intensity depends very much on the temperature of the LED.

  • Page 25: Firmware Update

    DMX2CC 6ch/12ch Firmware update Update with a PC A firmware update can be made with a PC and a RS-232 to RS-485 or a USB to RS-485 standard adapter plus a firmware update application. Connect the RS-485 cable to the RJ45 DMX IN of the DMX2CC (see previous chapter for DMX pin-out schema).

  • Page 26: Updating Dmx2Cc Master To Slave

    DMX2CC 6ch/12ch • Load the firmware update .bin file by pressing Open button. • Press the Connect button to get the application into slave search mode. • Power up the Slave Unit. • Select the Update Firmware option in the Admin Maintenance menu on the DMX2CC.
  • Page 27 DMX2CC 6ch/12ch • Connect the DMX IN of the Master Unit to the DMX IN of the Slave Unit. Use a standard pin-to-pin CAT5 cable (refer to the DMX512 Data wiring section): • Power up the master DMX2CC. • Select the Send Firmware option On the master unit in the Admin Maintenance menu.

  • Page 28: Master/Slave Update Faq

    DMX2CC 6ch/12ch Master/slave update FAQ Question Answer I disconnected the DMX cable during On the master unit press the ↲ the update by mistake! Now the button. Verify that Waiting master unit displays Update FAIL!, Target is displayed: and the slave unit is stuck at the •...
  • Page 29 DMX2CC 6ch/12ch Technical data Specification DMX2CC6 DMX2CC12 Power supply external Power input 24 - 48 VDC Current consumption max. 4.5 A max. 9 A Power consumption max. 180 W max. 360 W Efficiency up to 95% Heat dissipation < 20 W Max.
  • Page 30 DMX2CC 6ch/12ch Specification DMX2CC6 DMX2CC12 Color grades 256 level (each color), in total 16,770,000 colors Fixture protection Open line, short line and wrong interconnection protection Output protection PTC auto-recovery after fault condition is removed Thermal protection Reduces output current to eliminate unit (unit) overheating DMX connection type...

  • Page 31: Dimensions

    DMX2CC 6ch/12ch Dimensions 75,4 mm / 2.97“ 75,4 mm / 2.97“...
  • Page 32 DMX2CC 6ch/12ch 75,4 mm / 2.97“ 75,4 mm / 2.97“...

  • Page 33: Appendix

    DMX2CC 6ch/12ch Appendix Derating curves Ta=25 °C unless stated otherwise, driving current 700 mA 100% LEDs Vf (V) 48V PSU derating curve 100% Ambient temperature (°C)
  • Page 34 DMX2CC 6ch/12ch 24V PSU derating curve 100% Ambient temperature (°C)

  • Page 35: Trouble Shooting

    DMX2CC 6ch/12ch Trouble shooting The following table provides corrective actions for possible trouble situations. Trouble Possible causes Corrections Device does not function DMX2CC 6/12 is not Verify POWER IN receiving power from connections. the external DC power Ensure that the AC supply circuit breaker of the PSU is not tripped.
  • Page 36 DMX2CC 6ch/12ch © 2010 - e:cue control GmbH - An OSRAM Company - Germany - www.ecue.com...
