Summary of Contents for Gewiss JOINON EASY GW68116
- Page 1 JOINON EASY ELECTRICAL VEHICLE CHARGING UNIT JOINON EASY HOME AND PARKING User and installation manual...
-
Page 2: Table Of Contents
Electrical vehicle charging unit JOINON EASY HOME and PARKING CONTENTS INFORMATION ABOUT THIS MANUAL 1.1. Field of application 1.2. Manual audience 1.3. Symbols DEVICE DESCRIPTION 2.1. Fulfilment of regulations 2.2. EMC requirements 2.3. Degree of protection 2.4. Degree of pollution 2.5. - Page 3 OPERATION 8.1. Status indicators 8.2. Charging process 8.2.1. JOINON EASY HOME 8.2.2. JOINON EASY PARKING DEVICE DISCONNECTION 9.1. Device disconnection process PREVENTIVE MAINTENANCE 10.1. Residual current devices 10.2. Earth connection TROUBLESHOOTING 11.1. Alarms WASTE DISPOSAL USB CONFIGURATION 13.1. Configurable parameters 13.2.
-
Page 4: Information About This Manual
Electrical vehicle charging unit JOINON EASY HOME and PARKING INFORMATION ABOUT THIS MANUAL This manual describes the electrical vehicle charging station JOINON EASY HOME and PARKING and provides the information necessary for correctly perform the activities related to delivery, installation, start-up, maintenance and operation. -
Page 5: Fulfilment Of Regulations
REGULATORY ASPECTS FULFILMENT OF REGULATIONS CE marking The CE marking is indispensable in order to sell any product in the European Union, without prejudice to the standards or laws of the individual countries. The charging stations have a CE marking as they comply with the following directives: •... -
Page 6: Safety
Electrical vehicle charging unit JOINON EASY HOME and PARKING SAFETY This section describes the safety warnings and the personal protective equipment. 3.1. SAFETY CONDITIONS General warnings The operations described in this manual may only be performed by duly qualified personnel. When this manual refers to qualified personnel, this means personnel complying with all the standards, directive and laws concerning safety, as applicable to the installation and operation of this device. -
Page 7: Personal Protective Equipment (Ppe)
Potential hazards for people In order to protect your own safety, observe the following warnings. HAZARD: crushing and injury of limbs. Always follow the instructions supplied in the manual for device handling and positioning. The weight of the device can cause injuries if not handled correctly. Potential hazards for the device In order to protect the device, observe the following warnings. -
Page 8: Device Delivery And Storage
Keep the device packaged until installation. 4.2. DEVICE IDENTIFICATION The serial number of the device identifies it in an unequivocal manner. In any communication with Gewiss, refer- ence must be made to this number. The device serial number is also indicated on the plate that specifies the device features. -
Page 9: Device Handling
• Avoiding striking or dropping the mechanical stations as this could deteriorate the mechanical properties. • Avoiding, as far as possible, the vibrations that could cause subsequent abnormal operation. If a fault is discovered, contact Gewiss immediately. Packaging disposal The packaging can be sent to an authorised non-hazardous waste agent. -
Page 10: Support And Fastening Surface
Electrical vehicle charging unit JOINON EASY HOME and PARKING Remember that it could occasionally produce a small amount of condensation as a result of temperature changes. Therefore, in addition to the protection it has, the charging stations must be monitored when they are used in areas where it is probable that not all the previously indicated conditions will be satisfied. -
Page 11: Device Installation And Connection
DEVICE INSTALLATION AND CONNECTION Before proceeding with device installation, remove the packaging, paying particular attention to not damage the casing. Make sure there is no condensation inside the packaging. Otherwise, install the device only when it is completely dry. All the installation operations must be carried out in compliance with the directive in force. All operations that involve moving large weights must be done by two people. - Page 12 Electrical vehicle charging unit JOINON EASY HOME and PARKING • Fastening with plastic brackets GW 44 621 (not provided) • Fastening with pole support brackets GW 46 552 (not provided) 2. After installing the product on the wall, install the support for the hose. It can be installed in the lower part of the device or next to one of the sides.
-
Page 13: Connection Of The Device Power Supply
7.2.2. CONNECTION OF THE DEVICE POWER SUPPLY Protection devices The circuit breaker and residual current protections required by the standard must be installed upstream of the charging station. These protections are recommended based on the product type. Type of protection devices Recommended products Miniature circuit 20A C CHARACTERISTIC 2P... - Page 14 Electrical vehicle charging unit JOINON EASY HOME and PARKING Connection procedure 1. Open the casing as shown in the figure. 2. Drill the back-mounting box using a multi-diameter drill (not supplied) at the top or the bottom as required. GW 52 401 GW 52 401 3.
-
Page 15: Operation
OPERATION The main function of the charging station is to supply electricity to charge an electric vehicle that is available to everyone or only to specific users. This section provides a detailed description of the function of the charging station. The charging stations JOINON EASY HOME and EASY PARKING can load different configurations via USB. - Page 16 Electrical vehicle charging unit JOINON EASY HOME and PARKING 8.2. CHARGING PROCESS 8.2.1. JOINON EASY HOME While charging, it is not possible to remove the plug because it is locked by the charging station. In order to remove the plug, first stop the charging. Charging types The charging station has two charging modes: nominal (I) and limited (II).
-
Page 17: Joinon Easy Parking
End of the charging process To end the charging cycle, move the lever of the selector to position 0 (central position). The front LEDs flash yellow while waiting for the user to disconnect the connector from the vehicle. Loss of supply (immediate charge and deferred charge) If there is an interruption in the electric power supply, the charging station will remain inactive until the supply is restored. -
Page 18: Preventive Maintenance
Electrical vehicle charging unit JOINON EASY HOME and PARKING DISCONNECTION OF THE MAINS SUPPLY This section describes the procedure for disconnecting the mains network from the device. If you want to work inside the device (qualified personnel only), first operate the circuit breaker located in the enclosure that protects the electronic board and then the protection located upstream of the power supply line. - Page 19 2. POWER SUPPLY INTERRUPTED Description This error can depend on: • Mains supply failure. The station will restart when the supply is restored. • The station protections tripped. Solution If the error continues after restoring the mains supply, make sure the voltage is present in the charging station connection socket-outlet.
-
Page 20: Waste Disposal
Electrical vehicle charging unit JOINON EASY HOME and PARKING WASTE DISPOSAL These charging stations use components that are harmful to the environment (electrical boards, batteries, etc.). At the end of its useful life, the device must be delivered to an authorised collection centre for the correct disposal of the hazardous waste. -
Page 21: Usb Configuration
• Deferred charge programming. • Firmware update. 13.2 FILE DOWNLOAD AND STORAGE To download the necessary files, follow the instructions provided below. If necessary, contact the GEWISS tele- phone support service. Creating the USB memory root In order to configure the charging station and/or download the operating data, it is necessary to create a memory root in the USB memory as indicated in the following image. -
Page 22: Folder System
The “user.ini” file contains the variables that the user can configure. Not all parameters can be configured for all models, but they are included for reasons of compatibility. If a “user.ini” file is present in the /gewiss/config/ folder when the USB is connected to the station, the new con- figuration will be loaded. - Page 23 nominal_current Current setpoint sent to the vehicle when the device is used in nominal charge mode. The default setting is nominal current, which is indicated on the specifications data plate of the charging station. It must a be whole, positive value. The lower limit is 6 Amperes according to regulations and the upper limit is equal to the current on the spec- ifications data plate.
-
Page 24: Firmware
This folder contains a copy for the user of the current station status configuration files. The copied files are: • user.ini • date.ini This makes it possible to check the configuration, current date and time of the device as well as to check that the data loaded from the configuration files in /gewiss/config/ were updated correctly. -
Page 25: Deferred Charging In Joinon Easy Home
DEFERRED CHARGING IN JOINON EASY HOME Most modern electrical vehicles have the option of programming or deferring the vehicle charge. It is recommended to use this function if it is available. For vehicles that do not have programmed or deferred charging, it is possible to configure deferred charging in this charging point with the maximum level of versatility and flexibility possible. - Page 26 Electrical vehicle charging unit JOINON EASY HOME and PARKING Charging will start when the vehicle sends the charging start signal, both for immediate and deferred charging. or selector in position II, programmed interval charge mode. The current setpoint is deferred_current. The station permits charging when the starting time is reached and finishes at the programmed end time.
- Page 27 ACCESS AND DATA LOADING The procedure for accessing the USB connector available in the charging stations is described below. Open the enclosure door to access the device's USB socket-outlet and insert the USB memory in the relative connector. The charging station must be powered to load the data. If the parameters were loaded successfully, the station signal will flash white for a few seconds.
- Page 28 Punto di contatto indicato in adempimento ai fini delle Direttive e Regolamenti UE applicabili: Contact details according to the relevant European Directives and Regulations: GEWISS Via Volta,1 IT-24069 CENATE SOTTO - tel. +39 035 946 111 – qualitymarks@gewiss.com +39 035 946 111 sat@gewiss.com...
