Global 90 CF, Global 70XT CF
'Concise installation Guide'
Instructions for installation
Please retain this document carefully
u k
u k

Advertisement

loading
Need help?

Need help?

Do you have a question about the Global 90 CF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dru Global 90 CF

  • Page 1 Global 90 CF, Global 70XT CF ‘Concise installation Guide’ Instructions for installation Please retain this document carefully...
  • Page 2: Table Of Contents

    c o n c i s e i n s ta l l at i o n Contents What do you need for installation? Steps to take: Disclaimer: Main parts The six installation possibilities Gas technical installation...
  • Page 3: What Do You Need For Installation

    This guide does not replace the Installation Manual and should be read in conjunction with the installation ma- nual • The Installation Manual gives additional safety warnings and tips. • DRU or its agent/importer does not accept any responsibility for installation errors...
  • Page 4: Main Parts

    c o n c i s e i n s ta l l at i o n Main parts Frame Bèta Convection box Frame Alpha Gas control box Built-in plaster trim Burner Spoiler on topside Combustion chamber Debris shield Flue spigot...
  • Page 5: The Six Installation Possibilities

    c o n c i s e i n s ta l l at i o n The six installation possibilities I Class 1 chimney, linerless with frame Dimentions gap (mm) (see for opening battybox installation instructions) Min. 1 Position convection box and fix to the wall 2 Mount debris shield 3 Gastechnical installation, then mount frame II Class 1 chimney, linerless and frameless...
  • Page 6 c o n c i s e i n s ta l l at i o n III Class 1 chimney, with flex flue liner and frame Min. Dimentions gap (mm) (see for opening battybox installation instructions) 1 Position convection box and fix to the wall 2 Mount flex flue liner 3 Gastechnical installation, then mount frame IV Class 1 chimney, with flex flue liner and frameless.
  • Page 7 c o n c i s e i n s ta l l at i o n V False chimney breast, flue pipe 100 and frame. Dimentions gap (mm) (see for opening battybox installation instructions) Min. 1 Position convection box and fix to the wall 2 Mount flue pipe 3 Gastechnical installation, then make false chimney breast 4 Mount frame...
  • Page 8: Gas Technical Installation

    c o n c i s e i n s ta l l at i o n Gas technical installation In case of frameless first mount the 4 profiles of Profile with spoiler on top. The studs the plaster trim should be in the center of the hole! Gas supply pipe under bottom of gas control box.
  • Page 9 Mount gas control box to convection box Connect the flexible gas pipe to the gas suply with an elbow Connect the receiver to the gas control (Global 70XT CF) Connect the reciever to gas control (Global 90 CF) Place burner in convection box...
  • Page 10 c o n c i s e i n s ta l l at i o n Fix burner with screws Fix burner with screws (which were removed before) Place debris shield Use the flat topped screws (linerless application only) (Linerless application only) Use the inner holes Pull through flex flue liner (flue liner only)
  • Page 11 c o n c i s e i n s ta l l at i o n Mount flex flue line in flue spigot (flue liner only Place flue spigot in top of convection box (in case of flue liner no debris shield) Mount flue spigot with 2 screws Slide combustion chamber into convection box Fix with two screws (left and right)
  • Page 12 c o n c i s e i n s ta l l at i o n Put vermiculite tray in place Pay attention to slide in right position and place window (see instruction manual) Bèta frame only: use the drilling jig Bèta frame only: drill 4 holes and mount brackets to mark 4x drill spots (see included installation sheet) on the drilled holes (see included installation sheet)
  • Page 13 c o n c i s e i n s ta l l at i o n Notities / Notes / Notizen ........................................... . .
  • Page 14 c o n c i s e i n s ta l l at i o n Notities / Notes / Notizen ........................................... . .
  • Page 15 c o n c i s e i n s ta l l at i o n Notities / Notes / Notizen ........................................... . .
  • Page 16 DRu Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven...
