- Page 1 Age: 14+ INSTRUCTION MANUAL VR AUTOFLIGHT Thank you for purchasing the VR DRONE AUTOFLIGHT! To use it correctly and to ensure your own safety, please read the instruction manual carefully before you start using it and keep it for future reference.
-
Page 2: Table Of Contents
INDEX Important notice Precautions and warnings Box contents Functions of the transmitter Drone parts How to place the batteries in the transmitter How to place the battery and propellers in the drone This Precautions and How to charge the drone battery Alth Synchronisation and start-up Flight controls... -
Page 3: Important Notice
Do not expose others to danger. For more information visit: www.seguridadaerea.gob.es BOX CONTENT Box Content: 1 x VR Autoflight 1 x VR Drone Glasses 4 x Spare propellers 1 x 2,4Ghz transmitter 1 x AC/DC adapter 1 x Charger... -
Page 4: Functions Of The Transmitter
PARTES DE LA EMISORA FUNCTIONS OF THE TRANSMITTER 1: Emergency stop when both buttons pressed 2: Speed 3: Throttle stick/ rotation 4: Power Trim 5: Rotation Trim 6: Automatic Departure and Landing 7: Return Home 8: Headless 9: Smartphone holder 10: Acrobatic mode 11: ON / OFF 12: Direction Stick... -
Page 5: Drone Parts
DRONE PARTS 1: Screwdriver hole (propellers sustitution) 2: Propeller type indicator 3: Light 4: Motor 5: Camera 6: Protectors 7: Protectors holder 8: Propellers 9: Battery charge indicator 10: Battery 11: ON/OFF Button MicroSD slot Rechinable camera... -
Page 6: How To Place The Batteries In The Transmitter
INSTALACIÓN DE LAS PILAS EN LA EMISORA HOW TO PLACE THE BATTERIES IN THE TRANSMITTER 4 x AA | 1,5V 1. Observe correct polarity when inserting the Use the screwdriver to open the batteries. cover. Insert 4 “AA” batteries in 2. -
Page 7: Precautions And How To Charge The Drone Battery
CÓMO CARGAR LA BATERÍA CHARGE OF THE BATTERY OF THE DRONE When the drone lights flash, the battery is about to run out. 1. Land the drone and press the OFF button twice to turn off the drone. 2. Be sure to let the drone rest for at least 20 minutes to cool off the battery. Use the power adapter and charger supplied. -
Page 8: Synchronisation And Start-Up
DRONE SYNCHRONIZATION AND DEPARTURE AJUSTES DEL SOPORTE EN LA EMISORA PUESTA EN MARCHA 1. Turn on the VR DRONE AUTOFLIGHT You will find the ON button at the top of the drone, pressed the button and leave the drone blinking on a flat surface. -
Page 9: Flight Controls
MOVEMENTS CONTROL UP AND DOWN FORWARD AND BACKWARD Move up the power lever (left) to the drone Move the steering control lever up or go up. down: The drone will move forwards or backwards. Lowers the power lever (left) to the drone down. -
Page 10: Flight Speeds
CONTROL DE MOVIMIENTOS MODO VUELO 2 FLIGHT SPEEDS How to change speeds When you press the button, the drone will change its speed and offer greater power. So the drone will move faster and be more sensitive to the slightest of movements we make with the control sticks. -
Page 11: Videos And Photos With Your Vr Drone Autoflight
TRIMMING OF FORWARD AND BAC- TRIMMING OF LATERAL KWARD DISPLACEMENT When the drone advances and recedes When the drone tends to move to the sides incorrectly, you can correct the flight by incorrectly, you can correct the flight course pressing the forward or reverse trimming by pressing the left or right movement button, as appropriate. -
Page 12: Headless
HEADLESS MODE While the drone is operating in the normal way, without headless, the pilot must master which is the front and rear of the drone, as well as the side, so that, during the flight provides the correct order of movements. In this flight mode when the drone face you it is to know that the controls are reversed. -
Page 13: Return Home
RETURN HOME Press the “return home” button, the transmitter will beep and the drone will return in a straight line in the opposite direction to the one it had at the beginning of the flight. You can move the lever to the right to correct the course if the drone is off course. Press the “home” button again or move the lever to the right, the station will beep again and the drone will end the return. -
Page 14: Smartphone Use
SMARTPHONE USE Activate the Wi-Fi of your mobile device (smartphone not included) and look for “JUGUE- TRONICA_VR” establish connection and open the application “VR DRONE AUTOFLIGHT” (download by QR at the end of this manual). Accept that the APP accesses the Wi-Fi. In the first screen you will see three buttons, The interrogation opens a help screen. -
Page 15: Tips To Learn To Fly
TIPS TO LEARN TO FLY EXERCISE 1- HOW TO KEEP THE DRONE HOVERING UP IN THE AIR Synchronize the station with the drone and get ready to take it off. Start the engines and give them power with the left lever with a continuous touch. The drone should rise and stay at a height thanks to its visual positioning feature. - Page 16 TIPS TO LEARN TO FLY EXERCISE 3 - HOW TO ROTATE The rotation is the most complicated movement when it coms to flying drones. When rotating the drone, it is normal to get confused with the directions, since if the drone is facing front, the controls of the transmitter correspond to what you can see (if we turn to the right, the drone moves to the right).
-
Page 17: Online Content
ONLINE CONTENT SCAN THE QR CODE TO DOWNLOAD THE APP , to xis, ntal juguetronica.com/extras/vr- drone-autoflight Requires iOS 6.0 or higher. Compatible with d it iPhone, iPad and iPod touch. Requires Android 2.0 and above. hts” ally eft. TROUBLESHOOTING ards... - Page 18 JUGUETRÓNICA, SL - NIF: B83788414 Thank you for purchasing this product. URL: juguetronica.com/extras/vr-drone-autoflight Tienda y Servicio Post-venta en: C/ Alberto Aguilera, 1 - 28015 Madrid - España Garantía y Servicio Técnico Nacional.
