INSTRUCTION MANUAL
VR DRONE FULL HD
Attention:
1. This quadricoptero is suitable for indoor flight and outdoor, even in moderate wind
conditions.
2. It uses the 2.4GHz frequency. This allows a wide range and allows the flight of
several devices in the same place without interference. In addition, pilots can control
the flying forward / backward, turn left / right, fly left / right.
3. Read this manual carefully before using the VR Drone FullHD and it for future
reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Juguetronica JUG0246
Summary of Contents for Juguetronica JUG0246
- Page 1 Age: 14+ INSTRUCTION MANUAL VR DRONE FULL HD Attention: 1. This quadricoptero is suitable for indoor flight and outdoor, even in moderate wind conditions. 2. It uses the 2.4GHz frequency. This allows a wide range and allows the flight of several devices in the same place without interference.
-
Page 2: Table Of Contents
INDEX OF CONTENTS Advices and responsibilities ..................Check before flying ...................... Advices about replacement parts .................. Maintenance of equipment ................... Flight and height restrictions ..................Drone parts and accessories ..................Control functions ......................Control adjustments ..................... Capturing photos and videos ..................Warnings ........................ -
Page 3: Check Before Flying
CHECK BEFORE YOU FLY Use only new original spare parts, or which are in good condition. Make sure, before flying, the control, drone and mobile device has a fully charged battery, and also that the surroundings and the conditions are good for flying. Do not drink alcohol or use drugs if you will pilot the drone. -
Page 4: Control Functions
CONTROL FUCTIONS Speed setting (low / Aerobatics button medium / high) Power lever and Lever forward / ba- turn right / left ckward and left / right Automatic takeoff Set to move forward On / off button Direction adjustment to the right Left turn adjustment Stop emergency... -
Page 5: Warnings
WARNINGS THIS DRONE INTEGRATES GYROSCOPE. CAREFULLY READ THE FOLLOWING INSTRUCTIONS BEFORE YOU START TO FLY. Place the drone on a horizontal surface and press the power button. The LEDs flash slowly. The LEDs shine rapidly during calibration or when the drone is not on a horizontal surface when it will be turned on. -
Page 6: Emergency Stop
EMERGENCY STOP ATTENTION If the drone during flight, collides with an object, or if you need to stop quickly, press the “emergency stop” button. See image on the left. If you are in flight and the engines stop, the drone will fall on the ground, so do not use it if it is not strictly necessary. -
Page 7: Auto Return
AUTO RETURN Auto return Start By pressing the “auto return”, the drone flies back in a straight line to the starting position: the one that started the flight. To exit this mode, press the button again. When this function is ac- tivated, the front lights remains fixed and the rear lights (blue) start flashing quickly. -
Page 8: Battery Change In The Coltrol
BATTERY CHANGE IN THE CONTROL Battery compartment lids The battery compartments are hou- sed in the back of the control (see left image). Remove the covers and insert two alkaline “AAA” batteries in each compartment. Pay special attention to the polarity indicated in each compartment. -
Page 9: Flight Environment
FLIGHT AMBIENT Fly always in good weather conditions. We re- commend choosing sunny days without wind and following advices below: Not fly ever with extreme temperatures, not too cold, not too hot. Do not fly on windy days. The control and the performance of drone are influenced by the wind as the drone shall compensate for wind gusts to remain stable. -
Page 10: Setting Drone
SETTING DRONE When the drone starts flying uncontrollably or perform involuntary displacement, it is because it is out of adjustment. To adjust (to trim) the drone and keep it with stable flight, you must per- form the corresponding adjustment. Below, we detail the different settings available. If the drone tends to turn left, press the right turning adjust- ment button until the drone... -
Page 11: Practice Flight
PRACTICE FLIGHT Practice until have drone control, follow the flight instruction below: Take off the drone and try to keep it as steady as possible at a certain height (remember that must be greater than 30cm to avoid ground effect). This type of flight is called stationary flight. Now turn the drone on itself (image 1) in both directions, avoiding as much as possible that the drone to destabilize. -
Page 12: Precautions
RESOLUTION PROBLEMS (continued) PROBLEM CAUSE SOLUTION Air pressure In- Move the power lever gently, avoi- The drone moves with jumps fluence ding abrupt moves The drone spins The propeller is damaged Change propeller control, although it has been adjusted There are engines that rotate Change the motor correctly more slowly than others... - Page 13 APPLICATION FUNCTIONS (continued) 1. Home | 2. Take photo | 3. Record Video | 4. Gallery | 5. speed (low / medium / high) | 6. height control | 7. G-sensor mode | 8. Show / hide interfa- ce | 9. Show / Hide Settings | 10. Absolute control | 11.
- Page 14 APPLICATION FUNCTIONS (continued) ACCELERATION MODE CONTROL TO THE LEFT (standard mode) Power (up / down): Touch and move up the “lever” of power, indicated at the top capture so the drone start rise and move down to the drone start go down. Direction (forward / backward): Touch and move up the “lever”...
-
Page 15: Display Photos And Videos
APPLICATION FUNCTIONS (continued) DEFINITION OF TRAJECTORY Please indicate on the screen the trajectory you want the drone to perform. DISPLAY PHOTOS AND VIDEOS IN THE APPLICATION When in the drone there is not installed microSD card, images / videos are recorded on the mobile device. -
Page 16: How To Download Files And Videos
JUGUETRÓNICA, SL - NIF: B83788414 Thank you for purchasing this product. All information and updates in: www.juguetronica.com/extras/vr-drone-fullhd Shop: C/ Alberto Aguilera, 1 - 28015 Madrid - Espanha After-sales service: C/ Acuerdo, 36 - 28015 Madrid - Espanha DOMESTIC WARRANTY AND TECHNICAL SUPPORT The cross bin symbol indicates that the products and the batteries must not be dispo- sed of as household waste, since they contain substances harmful to the environment.
