Multitech MultiConnect MTPCIE-H5 Series Developer's Manual page 59

PIN # Name
30 3G_DVI_CL
K
31 3G_DVI_RX I
32 RI
33 3G_DVI_TX O
34 GND
35 GND
36 USB_D-
37 GND
38 USB_D+
39 3.3Vaux
40 GND
41 3.3Vaux
®
MultiConnect PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
I/O Function
I/O 3G Cellular
digital voice
clock
3G Cellular
digital voice
receive
O 3G Cellular UART
RI
3G Cellular
digital voice
transmit
Ground
Ground
I/O 3G USB Negative
Data
Ground
I/O 3G USB Positive
Data
I 3.3Vaux
Ground
I 3.3Vaux
Type Notes
1.8V
1.8V
1.8V
1.8V
3.3V
3.3V
SPECIFICATIONS
MTPCIE- MTPCIE- MTPCIE-
H5-V-BW H5 H5-V
no
function
no
function
no
function
no
function
59
