Bluetooth And Wi-Fi Antennas - Multitech MultiConnect MTPCIE-H5 Series Developer's Manual

Category
VSWR
Typical Radiated Gain
Radiation

Bluetooth and Wi-Fi Antennas

Manufacturer:
Manufacturer's Model Number:
Multi-Tech Systems:
Multi-Tech Ordering Information
Model Number
ANWF-1HRA
ANWF-10HRA
ANWF-50HRA
Antenna Specifications
Category
Frequency Range
Impedance
VSWR
Peak Radiated Gain
Radiation
Polarization
Connector
®
MultiConnect PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
Description
2.0:1 max
2 dBi
Omni-directional
Taoglas Antenna Solutions
GW.11.A153
45009740L
Quantity
1
10
50
Description
2.4000 to 2.4835 GHz
50 Ohms
VSWR should not exceed 2.0:1 at any point across the bands of operation
2.3 dBi on azimuth plane
Omni-directional
Linear Vertical
RP-SMA(M)
ANTENNAS, CABLES, GPS
47
