DEVELOPER BOARD AND SCHEMATICS
Jumper
JP90
J6
J23
J8, J9, J10, J13
S1
S3
S4
Installing the Device and Antennas
To install a device on the board:
1.
With the radio side down, slide the device into the J23 connector.
2.
Press down until the device snaps into the X3 connector clips.
3.
Optional. Snap cables onto the device's antenna connectors and attach the antennas to the cables. Refer
to the device's mechanical drawing for connector details.
Installing a SIM Card
To install a SIM card:
Install the SIM card into the SIM card holder on the radio.
Making Other Board Connections
Other connections you may need:
If your application needs a power supply, connect the power supply lead to the power connector on the
developer board.
If you need to connect the debug cable for your application, connect the D89 male connector of the RS-232
cable to the D89 debug jumper next to the power switch.
Attaching Power Supply Blades
Power Supply and Blades
If your device shipped with a power cord, attach the blades for your region.
34
Description
Not used by PCIe device.This jumper, when installed, connects power to OCG-E
device. (When using Developer Kit with OCG-E devices).
Not used by PCIe device.
Socket for installing PCIe device.
Oscilloscope probe ground connections
Not used by PCIe device.
Reset button for PCIe device.
Button for on/off of PCIe.
®
MultiConnect
PCIe MTPCIE-H5/MTPCIE-BW Developer Guide
