DOREL ASIA
STORAGE CRIB
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
DA1412 (WHITE & GREY)
DA1412W (WHITE)
DA1412: 0-65857-16943-0
DA1412W: 0-65857-16944-7
THIS INSTRUCTION BOOKLET
IMPORTANT
CONTAINS
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
_____________________________________
_______ / _______ / _______
NEED HELP!
CALL US FOR ASSISTAN
E-Mail: das@dorel.com
1-800-295-1980
DO NOT RETURN PROD
E-MAIL:DAS@DOREL.C
Model No:
UPC CODE:
NOTE:
SAFETY
Lot number:
(TAKEN FROM CARTON)
Date of purchase:
Tel #: 1-800-295-1980
Fax #: 514-353-7819

Advertisement

loading
Need help?

Need help?

Do you have a question about the DA1412 and is the answer not in the manual?

Questions and answers

Related Manuals for Baby Relax DA1412

Summary of Contents for Baby Relax DA1412

  • Page 1 DOREL ASIA Model No: DA1412 (WHITE & GREY) DA1412W (WHITE) UPC CODE: STORAGE CRIB DA1412: 0-65857-16943-0 DA1412W: 0-65857-16944-7 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
  • Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.

  • Page 3: Care And Cleaning

    NOTES * Ensure all parts and components are present before beginning assembly. * Read all instructions before use of the storage. KEEP INSTRUCTIONS FOR FUTURE USE. * Assemble on a soft, smooth surface to prevent damage to product finish. * DO NOT use power tools. * DO NOT use the unit if it is damaged or broken.

  • Page 4: Hardware List

    STORAGE CRIB DA1412 / DA1412W HARDWARE LIST Ø1/4" x 40 mm 12 x 15 x 8 mm T. BOLT CURVED NUT 32 PCS 12 PCS Ø8 x 30 mm Ø1/4" x 12 mm WOOD DOWEL MATTRESS SUPPORT BOLT 34 PCS...

  • Page 5: Parts List

    STORAGE CRIB DA1412 / DA1412W PARTS LIST RIGHT SIDE PANEL LEFT SIDE PANEL CRIB BOTTOM PANEL FRONT/BACK PANEL 1 PC 1 PC 2 PCS 2 PCS LEFT FRONT POST RIGHT FRONT POST LEFT BACK POST RIGHT BACK POST 1 PC...
  • Page 6 STORAGE CRIB DA1412 / DA1412W CRIB ASSEMBLY INSTRUCTION NOTE: When inserting bolts, turn clockwise until tight. Then loosen 1/2 - 3/4 of a turn. After crib is completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
  • Page 7 STORAGE CRIB DA1412 / DA1412W STEP 1 Insert wood dowel (3) into front/back panel (D) as shown. Attach bottom rail (Q) to front/back panel (D) with bolts (1). Use Allen Key (5) to tighten bolts(1). Repeat this step to assemble the other front/back panel (D) and bottom rail (Q).
  • Page 8 STORAGE CRIB DA1412 / DA1412W STEP 2 Insert wood dowels (3) to bottom rail (Q). Attach the front posts (E & F) and back posts (G & H) to the front/back panels (D) and bottom rails (Q) using bolts (1) and curved nuts (2) as shown below.
  • Page 9 STORAGE CRIB DA1412 / DA1412W STEP 3 Insert wood dowels (3) into right back post (H) as shown. Attach right side panel (A) to right back post (H) using bolts (1). Use Allen Key (5) to tighten all bolts (1).
  • Page 10 STORAGE CRIB DA1412 / DA1412W STEP 4 Insert wood dowel (3) into right back post (H) as shown. Slide in crib bottom panel (C) under right side panel (A). Secure crib bottom panel (C) to right back post (H) using bolt (1) and curved nut (2) as shown.
  • Page 11 STORAGE CRIB DA1412 / DA1412W STEP 5 Attach left side panel (B) to left back post (G) with bolts (1) and curved nuts (2). Insert wood dowel (3) into left back post (G). Slide in crib bottom panel (C) under left side panel (B).
  • Page 12 STORAGE CRIB DA1412 / DA1412W STEP 6 Attach mattress support (R) to right side panel (A) and left side panel (B) with mattress support bolts (4). Use Allen Key (5) to tighten all bolts. INCORRECT- Raised edge should face down -this...
  • Page 13 STORAGE CRIB DA1412 / DA1412W STEP 7 Insert three wood dowels (3) into right side panel (A) and one wood dowel (3) in left side panel (B) as shown below. Attach the assembled front panel (D & Q) to side panels (A & B) using bolts (1) and curved nuts (2).
  • Page 14 STORAGE CRIB DA1412 / DA1412W STEP 8 Insert wood dowel (3) and cam bolts (6) into bottom panel (N) as shown below. Insert cam locks (7) into storage rail (P). Attach storage rail (P) to bottom panel (N) and secure them together by rotating cam locks (7) 1/2 clockwise using a Phillips head screwdriver (not included).
  • Page 15 STORAGE CRIB DA1412 / DA1412W STEP 9 Insert wood dowels (3) and cam bolts (6) into left panel (J). Insert cam locks (7) into the assembled bottom panel (N) and storage rail (P). Attach assembled bottom panel (N & P) to left panel (J) and secure them together by rotating cam locks (7) 1/2 clockwise using a Phillips head screwdriver (not included).
  • Page 16 STORAGE CRIB DA1412 / DA1412W STEP 10 Insert wood dowels (3) and cam bolts (6) into left panel (J) as shown below. Insert cam locks (7) into middle panel (M), storage rail (O) and middle panel (L). Attach middle panel (M), storage rail (O) and middle panel (L) to left panel (J) and secure them together by rotating cam locks (7) 1/2 clockwise using a Phillips head screwdriver (not included).
  • Page 17 STORAGE CRIB DA1412 / DA1412W STEP 11 Insert wood dowels (3) and cam bolts (6) into right panel (K) as shown below. Insert cam locks (7) into bottom panel (N), middle panel (M), storage rail (O) and middle panel (L) as shown below.
  • Page 18 STORAGE CRIB DA1412 / DA1412W STEP 12 Insert cam locks (7) into side panels (J & K). Insert wood dowels (3) and cam bolts (6) into top panel (I). Attach top panel (I) to the assembled unit and secure it by rotating cam locks (7) 1/2 clockwise...
  • Page 19 STORAGE CRIB DA1412 / DA1412W STEP 13 Attach the storage unit to left side panel (B) using bolts (1). Use Allen Key (5) to tighten all bolts (1).
  • Page 20 STORAGE CRIB DA1412 / DA1412W NOTE: DO NOT throw away this instruction manual. Use the crib pouch attached to the mattress support to store this manual for future use. WARNINGS: * CAUTION- ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM BY 131CM) WITH A THICKNESS NOT EXCEEDING 6 INCHES (15CM).
  • Page 21 STORAGE CRIB DA1412 / DA1412W CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury.
  • Page 22 MODEL #: DA1412 / DA1412W Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com...
