MOBILE ICE CREAM FREEZERS
and DIPPING CABINETS
MODELS: MXDC4_MXDC8_MXDC12_MXF31F_MXF52F_MXF71F
INSTALLATION, MAINTENANCE & OPERATING MANUAL
Thank you for choosing our equipment for your operational requirements. Follow these instructions carefully.
If properly used and maintained, you can expect to enjoy years of reliable, efficient and top quality use.
Note: Product line is subject to ongoing, continuous upgrades and improvements. The specifications
defining each model are subject to change without notice.
Keep this manual for training and as a reference guide when service or maintenance is required.
Keep a copy of your Bill of Sale.
This will establish your appliance's warranty period and the date this coverage started.
For AUTHORIZED PARTS or TECHNICAL SERVICE, please contact:
1-877-368-2797 or Service@MaxxHelp.com
Maxximum Food Service • 3355 Enterprise Avenue, Suite 160, Weston, FL 33331 USA
Phone: (954) 202-7419 • Website: MaxximumFoodService.com
Advertisement
Table of Contents
Related Manuals for Maxx Cold MXDC-4
Summary of Contents for Maxx Cold MXDC-4
- Page 1 2018-02-07 PRINTED in USA MOBILE ICE CREAM FREEZERS and DIPPING CABINETS MODELS: MXDC4_MXDC8_MXDC12_MXF31F_MXF52F_MXF71F INSTALLATION, MAINTENANCE & OPERATING MANUAL Thank you for choosing our equipment for your operational requirements. Follow these instructions carefully. If properly used and maintained, you can expect to enjoy years of reliable, efficient and top quality use. Note: Product line is subject to ongoing, continuous upgrades and improvements.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TECHNICAL SERVICE CONTACT INFORMAITON COVER SAFETY PRECAUTIONS PROPER DISPOSAL of the FREEZER REPLACEMENT PARTS HOW TO CONNECT ELECTRICITY TRANSPORTATION and INSTALLATION DIAGRAM of FREEZER TEMPERATURE DISPLAY THE FUNCTION of the CONTROL PANEL DEFROST FUNCTION (If Ice Builds Up on Interior Walls) NORMAL OCCURENCES FOOD STORAGE TECHNICAL DATA... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS When using electrical appliances, basic safety precautions should be followed, including the following: • Equipment must be properly installed and located in accordance with the Installation Instructions. • Do not allow children to climb, stand, crawl inside or hang on to the equipment. •... -
Page 4: How To Connect Electricity
WARNING HOW TO CONNECT ELECTRICITY DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE GROUND PRONG FROM THE POWER CORD. FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE PROPERLY GROUNDED. • The power cord from this appliance is equipped with a grounding plug which minimizes the possibility of electric shock hazard. -
Page 5: Diagram Of Freezer
food (ice cream tubs, etc.) and the environmental temperature/required conditions for the stored product to maintain its quality. 6. Before putting product into the freezer please adjust the temperature control to its lowest set point and let it run until the temperature of inner cabinet decreases to 0°F (-18°C.) Once the unit reaches 0°F (-18°C), set the unit to your devised set point and load product. -
Page 6: The Function Of The Control Panel
CAPACITY OVERALL DIMENSION MODEL AMPS WEIGHT POWER CuFt (L) Inches (mm) Lbs (kg) MXDC-4 115/120V/60Hz/1-ph 6.0 (170) 165 (74) 31.5 x 27.2 x 50.4 (800 x 691 x1280) 115/120V/60Hz/1-ph MXDC-8 11.5 (326) 235 (107) 51.7 x 27.2 x 50.4 (1313 x 691 x 1280) -
Page 7: Troubleshooting
TROUBLESHOOTING: ISSUE REASON SOLUTION Temperature control is on the highest point Adjust the temperature Unfreezing Plug and outlet not connected well Securely connect the plug to the outlet Blown fuse or tripped breaker Change the fuse / Reset the breaker Temperature control is on the lowest point Adjust temperature control Too much product stored in the cabinet... -
Page 8: Dipping Cabinet Canopy Parts Diagram
THE CLEANING OF THE CONDENSER IS NOT COVERED BY THE WARRANTY! HOW TO CLEAN THE CONDENSER: 1. Disconnect the electrical power to the unit. 2. Remove the louvered grill. 3. Vacuum or brush the dirt, lint, or debris from the finned condenser coil. 4. -
Page 9: Canopy Installation (12 Steps)
CANOPY INSTALLATION: 1. POWER OFF THE FREEZER. REMOVE FOOD INSIDE. 2. CHECK and PREPARE PARTS and TOOLS • Open the carton box, take out foam package and dispose appropriately. Recycle when possible. • Check parts and quantities as listed in Parts Diagram above. •... - Page 10 5. INSTALL THE FIXED STRIPS Place the sub-assembly on the top frame of the freezer and close to the inside edge. Drill the hole and secure the LEFT side of the FRONT Fixed Strip with Screw 4.2X13. Drill the hole and secure the LEFT and RIGHT Fixed Strips with Screw 3.5X14.
- Page 11 8. INSTALL FRONT GLASS • Insert the FRONT glass into the corresponding slot of the front fixed strip. • Keep the Front Glass in an UPRIGHT position. 9. INSTALL LEFT and RIGHT GLASS • Insert the LEFT side glass into the slot of the LEFT side fixed strip. •...
-
Page 12: Ice Cream Handling Instructions For Dipping Cabinet
11. INSTALL UPPER MID GLASS • As Shown in the Figure, Loosen the bolt from the glass clamp. • Place the upper mid glass between the jaws of the clip. • Tighten the bold and cap nut. 12. PREPARE the DIPPING CABINET •... -
Page 13: Warranty Information
LIMITED WARRANTY For Warranty details, please refer to: www.MaxximumFoodService.com or 1-877-368-2797 or Service@MaxxHelp.com A warranty card should have been included with your appliance. However, if the warranty card is missing with your product, please send the following information to: Warranty & Reference Data Sheet: (make a return copy standard post card size) Maxximum Food Service WARRANTY CARD... -
Page 14: Technical Specifications
NOTES... - Page 15 NOTES...
- Page 16 Maxximum Food Service • 3355 Enterprise Avenue, Suite 160, Weston, FL 33331 USA Phone: (954) 202-7419 • Website: MaxximumFoodService.com...
