LUMENWERX VIA 3 Installation Instructions

VIA 3-4-5
SURFACE MOUNT - INSTALLATION INSTRUCTIONS
IMPORTANT: Installation instructions are shown with Via 4 and applies to all Via 3-4-5
Reflector must be reinstalled with the
screw and plastic washer that was
originally supplied. If not, it can result
in an electrical failure
Make sure to reconnect the wires to
the LED boards correctly
(+) terminal
Screw
Plastic Washer
(-) terminal
3
C
Remove the cartridges (C).
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC.
1
SINGLE FIXTURE
Remove the lens (A) with the included lens tool.
4
D
+
Locate junction box (D) and mounting points (E) in
the ceiling. Refer to dimensions supplied in client
drawings.
LumenWerx ULC. reserves the right to change or modify product specifications without notification
NOTE: Wire dimming conductors as Class 1
A
E
+
*
FILE NAME:VIA3-4-5-SURFACE-MOUNT-INST
W W W . L U M E N W E R X . C O M
2
B
Disconnect LED molex connector (B) by taking a
pointed object and pressing on the two tabs on the
top.
5
F
G
Make electrical connections between main power
(F) and fixture (G). Number of wires may vary.
November 15, 2019
B
Page: 1 / 4
