LUMENWERX CANYON Installation Instructions

CANYON
NOTE: Wire dimming conductors as Class 1
1
SINGLE FIXTURE
Unscrew and remove wall bracket (A) from
fixture bracket (B).
4
B
F
A
Insert fixture bracket (B) into wall bracket (A) and
secure in place with supplied screws (F). Do not
overtighten.
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC.
WALL MOUNT - INSTALLATION INSTRUCTIONS
2
E
B
C
A
Pass the electrical wires throught the wall bracket
(A) and junction cover (C) and make electrical
connection between fixture (D) and junction box
(E).
5
CONTINUOUS SYSTEM
Unscrew and remove wall bracket (A) from
fixture bracket (B). Put it in a safe place.
LumenWerx ULC. reserves the right to change or modify product specifications without notification
3 E
A
C
D
Screw back the junction cover (C) on the junction
box (E) and then screw the wall bracket (A) to the
wall using anchors.
6
B
A
Unscrew and remove the top cap (G). Place it in a
safe place.
FILE NAME:CANYON-WALL-MOUNT-INST
W W W . L U M E N W E R X . C O M
A
G
November 10, 2019 Page: 1 / 4
