LUMENWERX PRIMO LED Installation Instructions

PRIMO LED
NOTE: Wire dimming conductors as Class 1
1
SINGLE FIXTURE
2"
19 1/8"
22 1/4"
Make sure the power to the fixure is turned off.
4
D
F
G
Place fixture into place using the brackets (D) from
step 3 . Screw fixture into place using provided
washers (F) and nuts (G).
www.lumenwerx.com (T) 514-225-4304 (F) 514-931-4862 © All rights are reserved to LumenWerx ULC.
SURFACE MOUNT - INSTALLATION INSTRUCTIONS
2
C
B
Insert the fixture (A) into the surface mounting
kit (B). Place the 4 corner brackets (C) into place.
Secure in place using provided screws.
5
Connect the driver's power cables (H) to the
ceilling's power feed (E) inside the fixture.
LumenWerx ULC. reserves the right to change or modify product specifications without notification
3
A
Screw brackets (D) to ceilling using diagram from
step
the ceilling.
6
E
H
Screw safety cables (I) to the lens and push lens
assembly (J) into fixture.
Power can be safely turned on.
FILE NAME:PRIMO-SURFACE-MOUNT-INST
