Electrostatic Discharge Sensitive (ESDS)
This unit contains ESDS devices. We recommend the following precautions when repairing,
replacing or transporting ESDS devices:
• Perform work at an electrically grounded work station.
• Wear wrist straps that connect to the station or heel straps that connect to conductive
floor mats.
• Avoid touching the leads or contacts of ESDS devices or PC boards even if properly
grounded. Handle boards by the edges only.
• Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert
unprotected devices into materials such as plastic, polystyrene foam, clear plastic bags,
bubble wrap or plastic trays.
1. This part is not normally available from Customer Service. Approval from the Field Service
Manager is required before ordering.
2. The individual parts located on the PCBs are listed in the Electrical Part List.
This part is critical for safety purposes. Failure to use a substitute replacement with the
3.
same safety characteristics as the recommended replacement part might create shock, fire
and/or other hazards.
4. This part is referenced for informational purposes only. It is not stocked as a repair part. Refer
to the next higher assembly for a replacement part.
Description
L1 Microphone Accessory Pack,
Includes all items below
Audix OM3 Cardioid Dynamic Vocal Microphone
20' XLR Microphone Cable
Carton, L1 Microphone Accessory Pack, RSC,
10.50x8.50x5.75"
Cable, Audio, Dual, RCA
Cable, Input, 3.5mm, 6ft, Black
Description
L1 Compact Power Stand, 120V (US)
L1 Compact Power Stand, 220V (China)
L1 Compact Power Stand, 100V (Japan)
L1 Compact Power Stand, 230V (Euro)
L1 Compact Power Stand, 240V (UK)
Device Handling

Part List Notes

L1 Compact Accessory Pack

L1 Compact System Versions
®
Bose
Part Number
322711-0000
318884-0000
318885-0000
318886-0000
185931-01
271994-001
5
Vendor Part
Number
-
OM3
CBL-20
N/A
N/A
N/A
®
Bose Part Number
318882-1100
318882-2100
318882-3100
318882-4100
318882-5100
