Bose L1 PRO32 + SUB2 Preliminary Technical Data

PRELIMINARY TECHNICAL DATA
L1 PRO32 + SUB2
P R O F E S S I O N A L
PORTABLE LINE ARRAY SYSTEM
L1 Mix App
(Grilles removed)
Mobile device not included
and not to scale
Product Overview
The L1 Pro32 is our most advanced Bose L1 portable line array ever. It delivers the supreme clarity and output of a 32-driver
articulated line array and 180-degree horizontal sound coverage, giving you an unrivaled portable PA system for medium-
to-large-sized venues and events like weddings, clubs, and festivals. The L1 Pro32 combines with either the Bose Sub1 or
Sub2 subwoofer to create a powerful, modular solution that's easy to pack, carry, and set up. A built-in multi-channel mixer
offers EQ, reverb, and phantom power, plus Bluetooth® streaming and access to the full library of ToneMatch presets — and
the intuitive L1 Mix app places wireless control in your hands from your smartphone.
For DJs, singer-songwriters, bands — and your audience — the L1 Pro32 offers a truly superior experience. It gives you the
power to sound your best and simply perform.
Key Features
Provide a truly superior audio experience with the most advanced L1 portable line array ever, ideal for medium-to-large-
sized venues and events like weddings, clubs, and festivals
Deliver premium full-range sound with consistent tonal balance for singer-songwriters, mobile DJs, bands, and more
Maintain supreme vocal and instrument clarity with a straight-shape extended-frequency line array featuring 32
articulated 2" neodymium drivers and wide 180-degree horizontal coverage
Bring bass without the bulk via Bose Sub1 or Sub2 modular subwoofers, featuring RaceTrack drivers that take up less
space, freeing up room in your vehicle and on the stage
Go from vehicle to venue easily with a modular high-output system that's lighter and easier to pack, carry, and set up
Select between optimized system EQ presets for live music, recorded music, and more
Connect various audio sources easily via built-in mixer with two combo XLR-1/4" phantom-powered inputs, 1/4" and 1/8"
(3.5 mm) aux input, plus Bluetooth streaming — and access system EQ and ToneMatch presets, volume, tone, and reverb
via illuminated controls
Add even more instruments and other audio sources via dedicated ToneMatch port; one cable provides both power and
digital audio between system and a Bose T4S or T8S mixer (optional)
Take wireless control with the L1 Mix app on your smartphone to adjust settings instantly from your phone, roam the
room and fine-tune, and access the ToneMatch library of custom EQ presets
Stream high-quality Bluetooth audio from compatible devices
PRO.BOSE.COM/L1 1
OF 9
