Console Adapter Input and Output Connections
Figure 3
Warning
The 4-pin connector is keyed and should only be installed in one orientation.
Figure 3
Console Port to Access Point - Cable and Adapter
Note
Cisco Aironet Series Console Adapter Cable AIR-CONSADPT= Guide
6
shows the console cable to access point assembly.
1
Standard blue console cable
2
RJ-45 port of console adapter
3
4-pin connector on console adapter
4
Console port on Cisco Aironet device
The console port may be found in different locations on different products. Refer to the
documentation for your Cisco Aironet device to locate its console port.
