6 Camera settings

Use of the C700 is fully covered by the camera Operation Manual from Canon
(http://cinemaeos.usa.canon.com/). Refer to this manual for full details. Here we cover an overview of
essential information about recording formats.
The C700 with CDX-36150 can record in the following formats:
Resolution
4096 x 2160 (4K)
4096 x 2160 (4K)
To set the recording format:
MENU->Recording/Media Setup->Main Rec Format->RAW (Capture Drive)
To set the frame rate, from the Home Screen press the 'FPS' button (top left above the screen). If the
desired frame rate is not available, this may require a change to the System Frequency.
To select a non-SMPTE framerate (e.g. 33fps), enable Slow & Fast Motion Recording.

6.1 Recording

With the Capture Drive formatted, press either of the red REC buttons to begin a recording. The lit ring on
top of the CDX-36150 will be red during recording. Press the red REC button again to end the recording.

6.2 Playback

Press the PLAY button to open a list of clips for playback. The lit ring on the top of the CDX-36150 will be
green during playback.
Clips can be played back from either the Capture Drive, CFast 2.0, or SD card media. Select the media to
play back from in the PLAY screen.
Bit Depth
12-bit
10-bit
CDX-36150 Recorder - Getting Started Guide v1.1
Frame Rates
1-60fps
1-120fps
