CDX-36150 Recorder - Getting Started Guide v1.1

3.1 Powering on

Connect a battery or DC power source to the CDX-36150. Activate the power on the C700 to start the
system. The LED status ring on the top of the CDX-36150 is red when the input voltage is below the
minimum requirement.
Press the centre of the LED status ring to change the brightness between high, medium, low, and off.
6

4 Loading and unloading a Capture Drive from the CDX-36150

MEDIA ACCESS DOOR OPEN WITH
INSERTED CAPTURE DRIVE 1TB
The media access door of the CDX-36150 is located on the top. Slide the release catch next to the door
to open.
Insert the Capture Drive into the CDX-36150. The base of the Capture Drive should be oriented towards
the front of the CDX-36150. Push the Capture Drive from the top to fully mate the connectors. Close
the door and the Capture Drive will be loaded automatically.

5 Formatting a Capture Drive

To format the Codex Capture Drive, navigate in the camera menu:
{MENU}/{EVF} [Recording/Media Setup] > [Initialize Media] > [!|C02 Capture Drive]
Press both [FORMAT] buttons simultaneously. Select [OK] and then press SET.
WARNING: ONLY DELETE MEDIA THAT HAS BEEN SECURELY BACKED UP. THERE IS NO
UNDO FUNCTION AVAILABLE AFTER FORMATTING.
RELEASE CATCH
