Summary of Contents for IKA MICROSTAR digital

  • Page 1 MICROSTAR digital...
  • Page 2: Device Setup

    Device setup /// MICROSTAR digital /// What you should watch out for Operator panel and display Chuck Extension arm Power socket USB interface Attention! ( Stirring shaft cap...
  • Page 3: Safety Instructions

    Safety instructions /// Explication of warning symbols /// General information › Read the operating instructions in full before starting up and follow the safety instructions. › Keep the operating instructions in a place where it can be accessed by everyone. ›...
  • Page 4: Working With The Device

    Danger! ( Danger! ( Users must make sure that the standby key of the IKA device can be accessed › Do not use the device in explosive atmospheres, it is not EX-protected. immediately, directly and without risk at any time. If installation or positioning ›...
  • Page 5 /// Accessories › Imbalance of the output shaft, the chuck and in particular the stirring › Protect the device and accessories from bumping and impacting. tools can lead to uncontrolled resonant vibrational behavior of the device › Check the device and accessories beforehand for damage each time and the whole assembly.
  • Page 6: Scope Of Delivery

    (post office, railway network or logistics company). with various stirring tools. › Stand device (chuck points down) Scope of Delivery › MICROSTAR digital overhead stirrer Range of use (indoor use only) › power supply (with exchangeable adapters) › Laboratories ›...
  • Page 7: Useful Information

    Useful information /// Stirrer Power supply unit (with exchangeable adapters) The stirring device is suitable for continuous operation. The motor current is limited electronically. The device has an anti-stall and anti-overload system. If a fault occurs, a safety circuit immediately switches off the motor Europe permanently.
  • Page 8: Operator Panel And Display

    Please see section “Safety instructions“! The clamping chuck and output shaft permit clamping IKA recommend stirrer Device switches on / enters standby tools (see section “Permitted IKA Stirrer tools“). The output shaft is designed Standby key (no disconnection from the power supply network).
  • Page 9 Assembly /// Assembling the extension arm to the overhead /// Assembling the overhead stirrer to the stand stirrer Cross sleeve Screw bolt Extension arm Stirrer Stand Extension arm Check that the stirrer is held in position firmly prior to each use and also at regular Hexagonal socket screw intervals.
  • Page 10 Commissioning /// Assembling the stirring shaft protector /// Start-up Secure the device to a stable stand with a cross sleeve. Stirrer The stirring vessel must always be securely fixed for safety reasons. You must also ensure that the mounting device (stand) is set up in such a way that it is not liable to topple and does not start to move during the stirring procedure.
  • Page 11: Spare Parts Order

    For repair, please request the “Decontamination Certificate” form IKA or use the download printout of it from IKA website: www.ika.com. Use only cleaning agents which have been approved by IKA to clean IKA devices. If you require servicing, return the device in its original packaging. Storage pack- aging is not sufficient.
  • Page 12: Error Codes

    /// Regulations If an error occurs, the fault is shown by an error code on the screen. In accordance with IKA warranty conditions, the warranty period is 24 months. Proceed as follows in such cases: For claims under the warranty please contact your local dealer. You may also ›...
  • Page 13: Permitted Ika Stirrer Tools

    › R 1330 max. speed (rpm) ≤ 1000 Max. output power at stirring shaft 15.7 W IP code according to EN 60529 IP 54 See more permitted stirrer tools on www.ika.com. Contamination level Protection at overload motor current limitation Ambient temperature 5 ...
  • Page 14 Power supply 100 ... 240 VAC Input 50 / 60 Hz 24 VDC Output 36 W LPS (Limited Power Source) Protection class II (double insulated )
