PART #
DESCRIPTION
1
Meat Tank
2
Set Screw (8mm)
3
Axle Adjusting Knob
4
Axle Adjuster
5
Axle Bushing
6
Tank Cover
7
Axle with Paddles
8
Axle Drive Shaft
9
Drive Shaft Key
10
Axle Drive Shaft Gear
11
Bearing 6904z
12
Drive Shaft
Revised May,2014
#869 25lb. & #868 50lb. TILTING MEAT MIXER
QTY.
PART #
1
13
Gear Box Cover
Phillips Head Screw
2
14
(12mm)
1
15
Handle
1
16
Drive Shaft Bushing
1
17
Nu for Foot
1
18
Rubber Feet
1
19
Gear Box Base
1
20
Grease Seal
1
21
Connect Shaft
1
22
Wing Screw
3
23
Pressing Board 1
1
24
Pressing Board 2
LEM Products, West Chester, OH 45011
www.lemproducts.com
DESCRIPTION
QTY.
1
4
1
1
4
4
1
1
1
2
1
1
1-877-536-7763
PART #
DESCRIPTION
25
O Ring
26
Locking Handle
27
Spring
28
Lock Pin
29
Rotating Stand
30
Bearing 6801z
31
Bearing 6904（PA66）
32
Bearing 6002z
33
Gear
35
Drive Shaft C-Clip
Lock Pin Tilt Guide
36
(not a removable part)
QTY.
1
1
1
1
1
1
1
2
1
1
1
