- Page 1 LUCCI AIRFUSION QUEST II CEILING FAN • INSTALLATION • OPERATION • MAINTENANCE • WARRANTY INFORMATION CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. V1.1- publication on 07.2016...
-
Page 2: Safety Precautions
Airfusion QUEST II Installation Instructions THANK YOU FOR PURCHASING Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and save all instructions before using the product. SAFETY PRECAUTIONS In Europe: This appliance can be used by children aged from 8 years and above and persons with... - Page 3 Airfusion QUEST II Installation Instructions for an all-pole disconnection incorporated in the fixed wiring in accordance with the wiring rules. Example: If a fan is connected to a circuit that can be isolated via an all-pole safety switch at the switchboard, then this is considered to be an all-pole disconnection to the ceiling fan electrical circuit, meeting the requirements of clause 7.12.2 of AS/NZS 60335.1.
-
Page 4: Before Installation
Airfusion QUEST II Installation Instructions BEFORE INSTALLATION Unpack your ceiling fan and carefully identify the parts. Please refer to Fig 1. Canopy screw x 4 Mounting bracket x 1 Screw for mounting bracket x 2 Motor screws x 9 5,8. Blade holder screw set x 13... -
Page 5: Installing The Mounting Bracket
Airfusion QUEST II Installation Instructions INSTALLING THE MOUNTING BRACKET • The ceiling fan must be installed in a location so that the blades are a minimum 300mm spacing from the tip of the blade to the nearest objects or walls. -
Page 6: Hanging The Fan
Airfusion QUEST II Installation Instructions HANGING THE FAN Lift the fan assembly onto the mounting bracket. Ensure the registration slot (A) of the hanger ball is positioned on the stopper (B) of the mounting bracket (C) to prevent the fan from rotating when in operation. - Page 7 Airfusion QUEST II Installation Instructions LIGHT KIT INSTALLATION (For models with fan light kit only) Fig. 6 Fig. 7 Remove the decorative cover from the shaft. Pull the L and N wire out from the shaft. Insert wires through the light connector (1).
-
Page 8: Electrical Wiring Diagram
Airfusion QUEST II Installation Instructions ELECTRICAL WIRING DIAGRAM WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A LICENSED ELECTRICIAN. NOTE: AN ADDITIONAL ALL POLE DISCONNECTION MUST BE INCORPORATED IN THE FIXED WIRING IN ACCORDANCE WITH THE WIRING RULES. - Page 9 Airfusion QUEST II Installation Instructions USE WITH REMOTE WIRING DIAGRAM: (REMOTE sold seperately) 1/ Remote without plugs Fig. 9 2/ Remote with plugs Fig. 10 9 | P a g e...
-
Page 10: Finishing The Installation
Airfusion QUEST II Installation Instructions FINISHING THE INSTALLATION • After completing the electrical connection at the mounting bracket terminal block, connect the ceiling fan wiring via the quick connector plug. • Cover the mounting bracket with the canopy. Ensure all electrical wiring is tucked inside the canopy and that the wires are not damaged during this step. -
Page 11: After Installation
Airfusion QUEST II Installation Instructions Fig. 13 Reverse Switch AFTER INSTALLATION WOBBLE: NOTE: CEILING FANS TEND TO MOVE DURING OPERATION DUE TO THE FACT THAT THEY ARE MOUNTED ON A RUBBER GROMMET. IF THE FAN WAS MOUNTED RIGIDLY TO THE CEILING IT WILL CAUSE EXCESSIVE VIBRATION. -
Page 12: Technical Information
Airfusion QUEST II Installation Instructions • The motor has a permanently lubricated ball bearing so there is no need to oil. NOTE: Always turn off the power at the mains switch before attempting to clean your fan. TECHNICAL INFORMATION FAN models... - Page 13 THIS WARRANTY IS VALID IN AUSTRALIA ONLY In the event of service being required, please call the Lucci Fan Warranty Hotline on 1800 602 243 between 9am & 5pm (EST) Monday to Friday. Please make sure you have all the ceiling fan details filled out at the end of the manual before making the call.
- Page 14 Airfusion QUEST II Installation Instructions CEILING FAN WARRANTY INFORMATION LUCCI WARRANTY HOTLINE- 1800 602 243 Complete and retain this form for your personal records and warranty purposes. NAME………………………………………………………………………………… ADDRESS…………………………………………………………………………… ……………………………………………………POSTCODE…………………… MODEL NUMBER…………………………………………………………………… (PO# + DATECODE Sticker here) PO NUMBER or DATECODE ………………………………………………………...
