2.5 NOZZLE CHANGING
To change the nozzle, first remove the front cover then remove and replace the nozzle using a 12mm ring
spanner. Always use a new copper sealing washer and ensure that an angled nozzle is seated in the
correct orientation. The Smoke Screen is delivered with a single-hole straight nozzle and the following are
also available – 2-hole horizontal, 3-hole horizontal, 1-hole 30° angle down and 2-hole 30° angle down.
WARNING
Be aware of high
voltage in the block
area. The electrical
supply should be
switched off before
working in the heater
block compartment.
CAUTION
11
This operation is usually
carried out during
installation. If the Smoke
Screen has been in
service the nozzles will
be extremely hot and
will cause injury if
touched. Therefore, the
Smoke Screen should
be switched off and time
should be allowed for
the nozzles to cool.
