undersTAnding THe design
Door lock timer
2
1
Input/output connectors
Input/output connectors
1
These cables connect to the DC1V power from the power supply.
2
These cables connect to a DC1V rechargeable backup battery. During a power
failure, the backup battery will power up AdapTec-X.
3
These are the power output ports for AdapTec-X. Refer to the wiring diagram for
details.
4
These are the Wiegand data input ports for the FingerTec terminals. Refer to the
wiring diagram for details.
4
3
LED status indicator
5
