Variables of the Character type are displayed as single ASCII characters.
4.5

Tools

Terminal Window
In the Tools pulldown menu a simple terminal program can be started.
Received characters are directly shown in the terminal window. Characters can be send in two
different ways. On the one hand the user can click into the terminal window and directly type the
characters from the keyboard, on the other hand the text can be entered in to the ASCII input line
and send with the Send button. Instead of ASCII the characters can be defined as integer values in
the Integer input line. Is send C/R selected, a Carriage Return (13) is sent at the end of the line.
Enable Preserve Input to prevent that the input lines are cleared after pressing the Send button. The
Parameter button opens the Terminal settings dialog from the IDE settings.
