Valeo Thermo H 160 Workshop Manual page 30

Thermo H
1
9
8
HLP
7
6
5
Fig. 609 Small distribution board removal for devices Thermo H DC/DC 7,0/7,0 kW
X - not connected
X - Anschluss nicht belegt
1
9
8
HLP
7
6
5
Fig. 610 Small distribution board removal for devices Thermo H AC 14,0 kW
(heater ident. no. acc to model plate 11123469B, 11124196B und 11124197A)
2
3
4
(heater ident. no. acc to model plate 11124146 und 11124147)
2
3
4
Connecting HLP / Anschluss HLP
HLP
1
4
7
3
5
8
11123481_
Contactor /
Schütz AC
Connecting HLP / Anschluss HLP
HLP
6 Wiring diagrams
DC
orange cable blue cable
(oranges (blaues
Kabel) Kabel)
DC2 DC3
DC8 DC12
DC4 DC7
DC22 DC23
DC24 DC20
DC17 DC14
AC
orange cable blue cable
(oranges (blaues
Kabel) Kabel)
1 T3 N1
4 T2 N7
7 T1 N3
2 T3 N5
6 T2 N4
9 T1 N2
609
