2.2 Lamp or fuse replacement.
ATTENTION: always unplug the microscope before replacing the lamp
or the fuse. Be very careful not to touch the new lamp with your fingers:
handle it using paper or clean tissue. Dirty lamps must be cleaned with
ethyl alcohol.
Unscrew the rubber feet, located under the microscope's base, and take away the
protective panel.
Having replaced the detective lamp or fuse, replace the protective panel and screw the
rubber feet back on again.
2.3 Limit stop adjustment.
If focussing on the specimen at 400x magnification and the objective touches or
breaks the slide, please adjust the limit stop using the special screw (6 - ref. fig. 1).
OPTIONAL ACCESSORIES
MECHANICAL SLIDE CARRIER
Mechanical system that adjusts the x-y movement of the specimen.
Installation:
• Unscrew the spring slide holder (5 - ref. fig. 1) screws and take them away.
• Insert the mechanical slide carrier using the locating pins in it's underside.
which mate directly into apertures in the standard stage.
• Tighten the locking screw.

STANDARD ACCESSORIES

• 220V - 20W lamp.
• 500mA 220V fuses (10 pcs.).
• Dust cover.
GUARANTEE
This instrument is guaranteed for 2 years from purchase date against component
failures and/or manufacturing defects. Please return the Guarantee Certificate, stamped
by your distributor, to our nearest branch office.
During the guarantee period, failures will be repaired at our branches free of charge,
except for carriage costs.
This guarantee is void if the instrument is put to any use other than that for which it
is intended, if it is damaged due to the negligence of the user,
or sustains accidental damage of any nature.
We reserve the right to introduce technical changes to the instruments without notice,
according to the evolution of the rules and the technology.
