- Page 5 Insert wooden dowel (A) into part (1,2,6). Attach door stopper (G) to part (3) using screw (H) with screwdriver.
- Page 6 Attach cam bolt (B) to part (3) with screwdriver. Attach part (1,2) to part (4) using screw (E) with screwdriver.
- Page 7 Insert part (6) into part (4). Slide back panel (5) into grooves as per diagram.
- Page 8 Attach part (3) to part (1,2), then insert and secure cam lock (C) to part (1,2) to lock it. Attach plastic wedge (J) to part (5) using screw (K) with screwdriver.
- Page 9 Attach part (8) to part (4) using bolt (T) with hex key (U). Place sticker (D) over holes as per diagram.
- Page 10 Insert shelf support pin (F) into part (1,2). Place shelf (7) on top of support pin (F).
- Page 11 Attach handle (R) to part (9,10) using handle bolt (S) with screwdriver. Attach door (9) and hinge (L) to part (1) using screw (M) with screwdriver.
- Page 12 Attach door (10) and hinge (L) to part (2) using screw (M) with screwdriver. Attach velcro strap (N) to part (3) using screw (H) with screwdriver.
- Page 13 Place unit in desired location and mark the wall for anchor location. Insert plug (Q) into wall as per diagram. Secure product to wall with screw (P) and velcro strap (N) to plug (Q) with screwdriver.
