  • Page 1 VoIP-telephones Operating instructions FHF B 9710-6 03/13...
  • Page 2 Note ...

  • Page 3: Table Of Contents

    Table of Contents About this Manual ............. 15 Tips for Reading ............15 Overview of the Chapters ......... 16 VoIP Telephones ResistTel IP2 / IP152 and ExResistTel IP2 / IP154..........17 Keypad............... 17 Display............... 19 Types ................. 22...
  • Page 4 Mounting and Installing..........41...
  • Page 5 Commissioning ............75 Operating Manual............76 Operating Basics ............76 Operating Modes ............79 Call Functions ............81...
  • Page 6 Main Menu ............... 101 Menu Call Lists ............102 Menu Directories ............. 108 Menu Messages ............115...
  • Page 7 Menu User Setup ............. 118 Menu Phone Setup ..........125 3.10 Menu User List............130...
  • Page 8 3.11 Menu Administration..........164 Administration............173 General ..............173 Global Menu <Name of Logged in Administrator>. 175 Main Menu General ..........175...
  • Page 9 Main Menu ETH0 ............. 193 Main Menu IP4 ............197 Main Menu IP6 ............219...
  • Page 10 Main Menu Phone............ 225...
  • Page 11 Main Menu Device ........... 286 Main Menu Services ..........298 4.10 Main Menu Maintenance ......... 323...
  • Page 12 4.11 Special Configuration ..........354...

  • Page 14: Table Of Contents

    4.12 Resetting of the Configuration in Case of Emergency ................. 374 Appendix ..............376 Safety Instructions..........376 Menu Structure of the VoIP Telephones....377 Declarations and Approvals ........384 Abbreviations ............391 Overview ..............399 Tables ..............399 Figures..............399 Index ...............

  • Page 15: About This Manual

    About this Manual ResistTel IP2 / IP152 ExResistTel IP2 / IP154 1.1 Tips for Reading Note  Caution...

  • Page 16: Overview Of The Chapters

    1.2 Overview of the Chapters Note  User Name Password Note ...

  • Page 17: Keypad

    VoIP Telephones ResistTel IP2 / IP152 ExResistTel IP2 / IP154 2.1 Keypad 2.1.1 Assignment Figure 1: Keypad of the VoIP-Telephones...
  • Page 18 2.1.2 Description Symbol Description and Key Functions...

  • Page 19: Display

    Symbol Description and Key Functions Table 1: Keys and Function Elements 2.2 Display 2.2.1 Default Display Torsten 06.04.10 14:40 Figure 2: Default Display (Idle State)
  • Page 20 Torsten 06.04.10 14:40 0:12 Figure 3: Default Display (Busy State)
  • Page 21 Position Symbol Description 06.04.10 14:00 0:12 Table 2: Contents of the Default Display...

  • Page 22: Types

    2.2.2 Menu and Listing Display display name Figure 4: Menu and Listing Display of the VoIP Telephone Position Symbol Description Table 3: Contents of the Menu and Listing Display 2.3 Types • •...
  • Page 23 2.3.1 Weatherproof Types • • • • • • − − − − − −...
  • Page 24 2.3.1.1 Default Version one LAN Connection with a Cable Screw Cap • • Box contents 2.3.1.2 Version one LAN Connection with a Female Housing Connection • • • Box contents...
  • Page 25 2.3.1.3 Version one Switch LAN Module with two LAN Connections with Cable Screw Cap • • Box contents 2.3.1.4 Version one Switch LAN Module with two LAN Connections with Cable Screw Cap • • •...
  • Page 26 Box contents...
  • Page 27 2.3.1.5 Example Pictures Figure 5: VoIP Telephone ResistTel IP2 / IP152 with armed Court and 5 Cable Screw Caps...
  • Page 28 Figure 6: VoIP Telephone ResistTel IP2 / IP152 with armed Court, 2 LAN female Housing Connections and 3 Cable Screw Caps...
  • Page 29 2.3.2 Explosion Proof Types 2.3.2.1 Description • • • • Note ...
  • Page 30 2.3.2.2 Construction 2.3.2.2.1 Housing 2.3.2.2.2 Configuration Plug Connector 2.3.2.2.3 Intrinsically Safe Keypad Connection...
  • Page 31 2.3.2.3 Electrical Characteristic Parameter 2.3.2.3.1 Power Supply DC (not intrinsically safe) 2.3.2.3.2 Power Supply PoE according to IEEE 802.3 af (not intrinsically safe) Note ...
  • Page 32 2.3.2.3.3 LAN Interface 10/100 BASE-TX according to IEEE 802.3 (not intrinsically safe) 2.3.2.3.4 Potential-free Relay Contacts (not intrinsically safe) • •...
  • Page 33 • • 2.3.2.3.5 Cable Shield • • • • • •...
  • Page 34 Caution 2.3.2.3.6 Configuration Plug Connector 2.3.2.3.7 Intrinsically Safe Headset 2.3.2.3.8 Internal and External Earth and Potential Equalisation Connecting Bolt PA 2.3.2.3.9 Voltaic Isolation...
  • Page 35 2.3.2.3.10 Voltaic Isolation of the Relay Contacts 2.3.2.4 Warning and Safety Instructions The following warning and security instructions must be respected: • • • • • • • • • •...
  • Page 36 • • • • Caution •...
  • Page 37 Such unfavourable ambient conditions are: • • • •...
  • Page 38 2.3.2.5 Requirements 2.3.2.6 Explosion Proof Type Versions • • • • • • 2.3.2.6.1 Default Version one LAN Connection with a Cable Screw Cap • •...
  • Page 39 Box contents...
  • Page 40 2.3.2.7 Example Pictures Figure 7: VoIP Telephone ExResistTel IP2 / IP154 with armed Court and 5 Cable Screw Caps...
  • Page 41 2.4 Mounting and Installing 2.4.1 Mounting, general...
  • Page 42 Figure 8: Drilling Diagram Wall Mounting...
  • Page 43 Figure 9: Set View...
  • Page 44 Figure 10: Inside View of Telephone upper Part...
  • Page 45 2.4.1.1 Weatherproof Telephone, lower Part Figure 11: Inside View of Telephone lower Part ResistTel IP2 / IP152...
  • Page 46 2.4.1.2 Explosion proof Telephone, lower Part Figure 12: Inside View of Telephone lower Part ExResistTel IP2 / IP154...
  • Page 47 2.4.1.2.1 Cable Screw Caps of the Explosion Proof Telephone 2.4.1.3 Sling Holder 2.4.1.4 Receiver...
  • Page 48 2.4.2 Installation 2.4.2.1 Wiring of an Ethernet Cable Table 4: Wiring of an Ethernet Cable...
  • Page 49 2.4.2.2 Connecting RJ45 plug or RJ45 plug socket Table 5: RJ45 Pin Description 2.4.2.3 Power over Ethernet 2.4.2.3.1 Available Power Classes Table 6: PoE Power Classes...
  • Page 50 2.4.2.3.2 General Characteristics • • • • • 2.4.2.4 Installation of the Weatherproof Telephones Figure 13: Connection Diagram weatherproof VoIP Telephone with Single LAN Module...
  • Page 51 Figure 14: Connection Diagram weather proof VoIP Telephone with Switch LAN Module Table 7: Plug in Connectors and Terminals of the ResistTel IP2 / IP152...
  • Page 52 2.4.2.4.1 LAN-Connections 2.4.2.4.1.1 Default Version one LAN Connection with a Cable Screw Cap 2.4.2.4.1.2 Version one LAN Connection with a Female Housing Connection Caution...
  • Page 53 2.4.2.4.1.3 Version with Switch LAN Module with two LAN Connections with Cable Screw Caps 2.4.2.4.1.4 Version with Switch LAN Module with two LAN Connections with two Female Housing Connections...
  • Page 54 2.4.2.4.2 External Power Supply Connection 2.4.2.4.3 Relay Connection • • • • Figure 15: Connection Diagram Relay Module ResistTel IP2 / IP152...
  • Page 55 Figure 16: Connection Configuration Relay weatherproof Telephone (Exposition: Relay not active) Table 8: Plug in Connectors and Terminals of the Relay Module of the Telephone ResistTel IP2 / IP152 • • •...
  • Page 56 2.4.2.4.4 Other Terminals, Voltaic Separated Inputs Table 9: Terminals of the voltaic separated Inputs Caution...
  • Page 57 2.4.2.4.5 Headset Weatherproof Telephones Figure 17: Headset Type 5570-1 (MT53H79B-69, Order Number: 11264304)
  • Page 58 Figure 18: Headset Dimensions Type 5570-1 (MT53H79B-69, Order Number: 11264304) 2.4.2.4.5.1 Note 2.4.2.4.5.2 Application 2.4.2.4.5.3 Packing Contents −...
  • Page 59 − − − 2.4.2.4.5.4 Mounting and Connection...
  • Page 60 Figure 19: Outside View of Telephone lower Part ResistTel IP2 / IP152 Table 10: Connection of the Headset at the VoIP Telephone ResistTel IP2 / IP152 2.4.2.4.5.5 Commissioning and Operation...
  • Page 61 2.4.2.4.5.6 Maintenance 2.4.2.4.5.7 Disposal 2.4.2.4.5.8 User Information...
  • Page 62 2.4.2.5 Installation of the Explosion Proof Telephones Figure 20: Plug Connectors and Data Links of the Explosion Proof VoIP Telephone ExResistTel IP2 / IP154 Figure 21: Terminals of the Explosion Proof VoIP Telephone ExResistTel IP2 / IP154...
  • Page 63 Table 11: Plug in Connectors and Terminals of the ExResistTel IP2 / IP154 2.4.2.5.1 Connection Potential Equalisation 2.4.2.5.2 Ethernet Connection Table 12: Ethernet Connection of the ExResistTel IP2 / IP154...
  • Page 64 2.4.2.5.3 External Power Supply Connection 2.4.2.5.4 Relay Connection 18 / 21 20 / 23 Figure 22: Terminal Assignment Relays of the Explosion proof VoIP Telephone ExResistTel IP2 / IP154 (Exposition: Relay not active) Table 13: Terminals of the Relays of the Explosion proof VoIP Telephone ExResistTel IP2 / IP154...
  • Page 65 2.4.2.5.5 Examples for Connection 2.4.2.5.5.1 Example for Connection 1 • • Figure 23: Example for Connection 1...
  • Page 66 2.4.2.5.5.2 Example for Connection 2 • • Figure 24: Example for Connection 2...
  • Page 67 2.4.2.5.5.3 Example for Connection 3 • • • Figure 25: Example for Connection 3...
  • Page 68 2.4.2.5.5.4 Example for Connection 4 • • • Figure 26: Example for Connection 4...
  • Page 69 2.4.2.5.5.5 Example for Connection 5 • • • • • Figure 27: Example for Connection 5...
  • Page 70 2.4.2.5.6 Headset for the Explosion Proof Telephone Figure 28: Headset Type 5570 (MT53H79B-56, Nemko 02 ATEX 059 X, Order Number: 11286104)
  • Page 71 Figure 29: Headset Dimensions Type 5570 (MT53H79B-56, Nemko 02 ATEX 059 X, Order Number: 11286104) 2.4.2.5.6.1 Note 2.4.2.5.6.2 Application 2.4.2.5.6.3 Packing Contents −...
  • Page 72 − − − 2.4.2.5.6.4 Mounting and Connection Note ...
  • Page 73 Figure 30: Outside View of the lower Part of the Explosion Proof VoIP Telephone ExResistTel IP2 / IP154 Table 14: Connection of the Headset at the Explosion Proof VoIP Telephone ExResistTel IP2 / IP154 2.4.2.5.6.5 Commissioning and Operation...
  • Page 74 2.4.2.5.6.6 Maintenance 2.4.2.5.6.7 Disposal 2.4.2.5.6.8 User Information...

  • Page 75: Commissioning

    2.4.2.5.6.9 Technical Data of the Ex-Headset MT53H79B-56 2.5 Commissioning...

  • Page 76: Operating Manual

    Operating Manual 3.1 Operating Basics Key assignment in menu: The function … … is performed by … Key assignment in edit field: The function … … is performed by … character mode initial condition...
  • Page 77 3.1.1 Adjusting the Volume Martin vol. 06.04.10 14:40 0:22 Figure 31: Adjusting the Volume • • • • 3.1.2 Adjusting the Ring Tone Volume...
  • Page 78 Torsten Martin vol. 06.04.10 14:40 0:22 Figure 32: Adjusting the Ringer Volume 3.1.3 Do not Disturb Torsten 06.01.10 14:40 Figure 33: Do not Disturb 3.1.4 Different Types of Call Numbers...

  • Page 79: Operating Modes

    3.1.5 Input of Characters and Special Characters possible characters and special characters ÷ Table 15: Input of Characters and Special Characters 3.2 Operating Modes...
  • Page 80 3.2.1 Changeover from Handset Mode to Handset Mode with Open Listening 3.2.2 Changeover from Handset Mode with Open Listening to Handset Mode 3.2.3 Changeover from Handset Mode (with or without Open Listening) to Hands Free Mode 3.2.4 Changeover from Handset Mode (with or without Open Listening) to Headset Mode 3.2.5 Changeover from Hands Free Mode to Handset Mode...

  • Page 81: Call Functions

    3.2.6 Changeover from Hands Free Mode to Headset Mode 3.2.7 Changeover from Headset Mode to Headset Mode with Open Listening 3.2.8 Changeover from Headset Mode with Open Listening to Headset Mode 3.2.9 Changeover from Headset Mode (with or without Open Listening) to Handset Mode 3.2.10 Other Changeover of the Operating Mode 3.3 Call Functions...
  • Page 82 Torsten Martin 06.01.10 14:40 0:22 Figure 34: Answering a Call Answering or rejecting calls: • • • 3.3.2 Terminating a Call • • • • 3.3.3 Making Calls...
  • Page 83 3.3.3.1 Single Dialling Torsten 0211654321 Please dial 06.01.10 14:40 0:00 Figure 35: Direct Dialling • • • • • • • 3.3.3.2 Block Dialling...
  • Page 84 3.3.3.2.1 Menu Parameter Input Indirect Dialling Send Message....Dial – Show own No.... Dial – Hide own No.... Dial – No Diversion... Dial as User....Dial to – Always....+ Indirect dialling Figure 36: Menu Parameter Input Indirect Dialling (1. Part) Dial to –...
  • Page 85 • • • • • • •...
  • Page 86 • 3.3.3.3 Dialling during existing Connections 3.3.4 Redialling 01 06.02.10 11:30 Martin 73 02 06.02.10 11:30 Thomas 70 03 06.03.10 11:29 Peter 36 < Calls (outbound) Figure 38: List of Recently Dialled Numbers and Sent Messages Dialling numbers from the redial list •...
  • Page 87 • 3.3.5 Call Back 01 06.02.10 11:30 Martin 73 02 06.02.10 11:30 Thomas 70 03 06.03.10 11:29 Peter 36 > Calls (inbound) Figure 39: List of the Last Incoming Calls and Received Messages Dialling numbers from the calling list • •...
  • Page 88 • • 3.3.6 Muting Torsten Thomas 06.01.10 14:40 0:22 Figure 40: Muting...
  • Page 89 3.3.7 Making second Call Torsten Peter Torsten Please dial 06.01.10 14:40 0:22 Figure 41: Holding a Call...
  • Page 90 3.3.8 Switching Torsten Peter Torsten Thomas 06.01.10 14:40 0:22 Figure 42: Switching 3.3.9 Transferring a Call Torsten Peter Torsten Thomas 06.01.10 14:40 0:22 Figure 43: Transferring a Call...
  • Page 91 3.3.10 Transferring a Call directly Torsten Peter Transfer Figure 44: Transferring a Call Directly...
  • Page 92 3.3.11 Initiating a Conference Torsten anonym Torsten Peter 3party 06.01.10 14:40 0:22 Figure 45: Conference...
  • Page 93 Note •  • • 3.3.12 Return Call if engaged Peter Recall Redial Intrude Send Message < Recall Figure 46: Recall...
  • Page 94 Note Return Call if engaged  Do not Disturb Call Diversion 3.3.13 Automatic Redialling...
  • Page 95 Peter Recall Redial Intrude Send Message < Recall Figure 47: Redial Note  3.3.14 Intrusion Peter Recall Redial Intrude Send Message < Recall Figure 48: Intrude...
  • Page 96 3.3.15 Send Message Peter Recall Redial Intrude Send Message < Recall Figure 49: Send Message For:72 << Message Figure 50: Message 3.3.16 Management of the Waiting List 3.3.16.1 Operating Mode 1...
  • Page 97 Anna-Maria ----- hold call Torsten Anna-Maria ----- active call Thomas ----- waiting calls 1 Call pending Martin -- choosen waiting call 06.01.10 14:40 0:22 Figure 51: Operating Mode 1 Key sequence Effect 3.3.16.2 Operating Mode 2 Anna-Maria -- active call Torsten 2 Calls pending Thomas...
  • Page 98 Caution Anna-Maria ---- hold call Torsten Anna-Maria ---- active call Thomas ---- waiting call 1 Call pending Martin ---- choosen waiting call 06.01.10 14:40 0:22 Anna-Maria ---- active call Thomas 2 Calls pending Thomas ---- choosen waiting call Figure 53: Compare of the Operation Modes Key sequence Effect...
  • Page 99 3.3.17 Call Counter Torsten 06.01.10 14:40 Figure 54: Call Counter 3.3.18 Message Counter Torsten 06.01.10 14:40 Figure 55: Message Counter 3.3.19 Recall Counter...
  • Page 100 Torsten 06.01.10 14:40 Figure 56: Recall Counter 3.3.20 Answering Waiting Calls Note ...
  • Page 101 Torsten Thomas 1 Call waiting Martin 06.01.10 14:40 0:22 Figure 57: Call Waiting Answering or terminating waiting calls: Note  3.4 Main Menu Call Lists....Directories....Messages...... User setup....Phone Setup....User List..... Main Menu Figure 58: Main Menu (1. Part)
  • Page 102 Administration....Main Menu Figure 59: Main Menu (2. Part) 3.5 Menu Call Lists Call Lists Calls (combined)....Calls (inbound)....Calls (outbound)....Active Recalls....< Call Lists Figure 60: Menu Call Lists calls (combined) calls (inbound) calls (outbound) 3.5.1 Calls (combined) Call Lists...
  • Page 103 >01 23.01.10 11:20 Peter 36 >02 23.01.10 11:20 Peter 36 <03 23.01.10 11:20 Peter 36 ) Calls (combined) Figure 61: Menu Calls combined • • • • • • • • •...
  • Page 104 3.5.2 Call List (inbound) Menu > Call Lists > Calls (inbound) 01 23.01.10 11:20 Peter 36 02 06.01.10 14:40 Peter 36 03 23.01.10 11:20 Peter 36 ) Calls (inbound) Figure 62: Menu Call List inbound Call List (inbound) • • •...
  • Page 105 3.5.3 Call List (outbound) Menu > Call Lists > Calls (outbound) 01 23.01.10 11:20 Peter 36 02 23.01.10 11:20 Peter 36 03 23.01.10 11:20 Peter 36 ) Calls (outbound) Figure 63: Menu Call List outbound Call List (outbound) • • •...
  • Page 106 3.5.4 Active Recalls Menu > Call Lists > Active Recalls 01 23.01.03 11:20..... Peter 36 01 23.01.03 11:20..... Klaus 37 01 23.01.03 11:20..... Inge 39 ) Active Recalls Figure 64: Menu Call Lists Active Recalls 3.5.5 Call List Edit Information....Save no.
  • Page 107 • • 3.5.5.1 Information (Call) From:Meier 105 For:Schulze 106 Duration:0:23:45 Information Figure 66: Menu Information (Call) 3.5.5.2 Information (transferred Call)
  • Page 108 From:Meier 105 For:Schulze 106 Via: Müller 107 Duration:0:23:45 Information Figure 67: Menu Information (transferred Call) 3.6 Menu Directories Directories Directory Input....Search (local)....Search (external)..... Search (PBX)....Search (combined)..... ) Directories Figure 68: Menu Directories...
  • Page 109 3.6.1 Saving new Entries Directories Directory Input Subscriber Number: Name Setup......) Directory Input Figure 69: Menu Directory Input Subscriber: Number: Name: Either...
  • Page 110 3.6.2 Searching for Entries Böhme, Claus....Cezanne, Heinz....Loch, Wolfgang....Römer, Bernhard....Indirect dialling Figure 70: Indirect Dialling Display of the Directory 3.6.3 Searching for Entries selectively Menu > Directories Search (local) Search (external) Search (PBX) Search (combined)
  • Page 111 ) Search (local) Figure 71: Search 3.6.4 Editing Entries Editing the call number and name Subscriber Madonna Number:125 Name :Madonna Setup......Delete......7 Directory Input Figure 72: Menu Directory Input Subscriber...
  • Page 112 Number Name Delete 3.6.4.1 Setup Setup Ringing Ringing Tone....Registration....5 Setup Figure 73: Menu Setup...
  • Page 113 3.6.4.1.1 Ringing Tone Ringing Tone Start......Melody: Default Vol: Spd: Ring Melody Figure 74: Menu Ring Melody...
  • Page 114 3.6.4.1.2 Registration Registration FHF4 104 +* Registration Figure 75: Menu Registration 3.6.5 Multiple Registration Join user setup Phone/User-1 Phone/User-6...
  • Page 115 Changing user 3.7 Menu Messages New Message....Messages(incoming).... Messages(outgoing).... < Messages Figure 76: Menu Messages 3.7.1 New Message For: + Message Figure 77: Menu New Message...
  • Page 116 Figure 78: Ok Operation failed Figure 79: Operation failed 3.7.2 Messages (incoming) >01 06.02.10 11:30 Martin 73 >01 06.02.10 11:22 Peter 72 + Messages(incoming) Figure 80: Menu Messages (incoming) 3.7.3 Messages (outgoing) <01 06.02.10 11:30 Martin 73 <01 06.02.10 11:22 Peter 72 + Messages(outgoing) Figure 81: Menu Messages (outgoing)
  • Page 117 3.7.4 Message It is raining now. Action......5 Message Figure 82: Menu Message 3.7.5 Action Number:501 Indirect dialling..... Reply Message....Delete Entry....Delete List....7 Action Figure 83: Menu Action 3.7.6 Incoming Message From:501 It is raining now. < Message Figure 84: Incoming Message...
  • Page 118 3.8 Menu User Setup Call Diversion....Presence...... Do not Disturb....Call waiting: On-def. Number Present.: < User Setup Figure 85: Menu User Setup • Call waiting Off: • Call waiting On-def.: • Call waiting On-once: • Call waiting On-mute: Setting Call waiting: User Setup Call waiting...
  • Page 119 Setting the Number Presentation: User Setup Number Present. 3.8.1 Call Diversion call diversion Note ...
  • Page 120 Note  • Unconditional Note  • Busy: • No reply Note  Note ...
  • Page 121 Setup call diversion, switching on and off User Setup Call Diversion Unconditional: Busy: No reply: + Call Diversion Figure 86: Menu Call Diversion Unconditional Busy No reply...
  • Page 122 3.8.2 Presence Presence Setup presence, switching on and off User Setup Presence Activity: Note + Presence Figure 87: Menu Presence 3.8.3 Do not Disturb Do not disturb • Do not disturb Off:...
  • Page 123 Do not disturb On • o Action Ringing off: o Action Ring once: o Action Silence: o Action Busy: o Action Out of Office: Setup do not disturb, switching on and off User Setup Do not disturb...
  • Page 124 Do not disturb: Action: Silence For: Any Call + Do not disturb Figure 88: Menu Do not Disturb Do not disturb: Action: Silence For: Any Call Out of Office Msg..... + Do not disturb Figure 89: Menu Do not Disturb (out of Office) Do not disturb Action...
  • Page 125 3.9 Menu Phone Setup Headset: Direct Dial....Lock Phone....Change PIN....LCD Contrast: LCD Light: < Phone Setup Figure 90: Menu Phone Setup (1. Part) Keypad Light: < Phone Setup Figure 91: Menu Phone Setup (2. Part) 3.9.1 Headset Setup headset, switching on and off Phone Setup Headset 3.9.2...
  • Page 126 Do not disturb Direct dial: Number: Delay (seconds): + Direct dial Figure 92: Menu Direct dial Direct dial Number Delay Note ...
  • Page 127 3.9.3 Lock Phone Setup lock phone, switching on and off Phone Setup Lock Phone Please enter PIN PIN: < Authentication Figure 93: Menu Authentication PIN invalid Figure 94: Menu PIN Invalid...
  • Page 128 Attention no emergency calls possible! < Figure 95: Menu Authentication PIN Valid 3.9.4 Change PIN Phone Setup Change PIN Cur PIN: New PIN: New PIN: < Change PIN Figure 96: Menu Change PIN...
  • Page 129 Changes activated Figure 97: Menu Changes Activated 3.9.5 LCD Contrast Phone Setup LCD Contrast 3.9.6 LCD Light Phone Setup LCD Light...
  • Page 130 3.9.7 Keypad Light Phone Setup Keypad Light 3.10 Menu User List 1 FHF4 104 +* 2 FHF204 204 - < User List Figure 98: Menu User List • • • •...
  • Page 131 Preferences....Ring Melody....Function Keys....+ FHF4 104 Figure 99: Menu <active user 1> Activate...... Preferences....Ring Melody....Function Keys....+ FHF4 104 Figure 100: Menu <inactive user 1> Preferences....Ring Melody....Function Keys....Registration....+ FHF4 104 Figure 101: Menu <active user 2 - 6> Activate......
  • Page 132 Activate Activate Figure 103: Menu OK 3.10.2 Preferences User List Preferences...
  • Page 133 Language: English Date: Default 5 Preferences Figure 104: Menu Preferences Select language Language • • • • • • • • • • • • • • •...
  • Page 134 • Select format of date Date • • • 12. In order to store your personal settings, press the key twice and answer Yes to the confirmation question. Settings changed! Save Changes? No......Yes......+ Decision Figure 105: Menu Decision Save Changes 3.10.3 Ring Melody User List Ring Melody...
  • Page 135 Ring Melody (int)..... Start......Melody: Default Vol: Speed: 5 Ring Melody Figure 106: Menu Ring Melody 3.10.4 Registration Setup Unregister....Delete......5 Registration Figure 107: Menu User List Registration Unregister Setup Register...... Delete......5 Registration Figure 108: Menu User List Registration Register 3.10.4.1 Setup...
  • Page 136 3.10.4.2 Register 3.10.4.3 Unregister 3.10.4.4 Delete delete? No......Yes......Decision Figure 109: Menu Decision Delete User deleted Figure 110: User Deleted 3.10.5 Function Keys...
  • Page 137 1 ......2 ......3 ......4 ......5 ......6 ......5 Function Keys Figure 111: Function Keys ResistTel IP2 / IP152 (1. Part) 7 ......8 ......9 ......10 ......11 ......12 ......5 Function Keys Figure 112: Function Keys ResistTel IP2 / IP152 (2.
  • Page 138 1 ......2 ......3 ......4 ......5 ......6 ......5 Function Keys Figure 115: Function Keys ExResistTel IP2 / IP154 (1. Part) 7 ......8 ......9 ......10 ......5 Function Keys Figure 116: Function Keys ExResistTel IP2 / IP154 (2. Part) 3.10.5.1 Function Keys General •...
  • Page 139 • 3.10.5.2 Function Key Undefined Type: Undefined Function Keys Figure 117: Function Key (Type Undefined) 3.10.5.3 Function Key Destination Number Type: Destination No. Text: Icon: Number: Announcement: Prepare: Function Keys Figure 118: Function Key (Type Destination No.)
  • Page 140 3.10.5.4 Function Key Partner Type: Partner Text: Icon: Number: Intrude: Display Number....Function Keys Figure 119: Function Key (Type Partner, 1. Part) Presence: Function Keys Figure 120: Function Key (Type Partner, 2. Part) calling: connected: Display Number Figure 121: Display Number (calling, connected)
  • Page 141 Caution Note ...
  • Page 142 • • • 3.10.5.5 Function Key Park Type: Park Text: Icon: Number: Position: Display Number....Function Keys Figure 122: Function Keys (Type Park) calling: Display Number Figure 123: Display Number (calling)
  • Page 143 3.10.5.6 Function Key Pickup Type: Pickup State: Text: Icon: Display Number....Function Keys Figure 124: Function Keys (Type Pickup, State 1) Type: Pickup State: Text: Icon: LED: Display Number....Function Keys Figure 125: Function Keys (Type Pickup, State 2)
  • Page 144 3.10.5.7 Function Key Message Waiting Indicator Type: State: Text: Icon: Number: Append Own Nr.: Function Keys Figure 126: Function Keys (Type MWI, State 1, 1. Part) Global: Function Keys Figure 127: Function Keys (Type MWI, State 1, 2. Part) Type: State: Text: Icon:...
  • Page 145 3.10.5.8 Function Key Call Forwarding Type: Call Forwarding State: Text: Icon: Call Diversion....Function Keys Figure 130: Function Keys (Type Call Forwarding, State 0) Unconditional: Busy: No Replay Call Diversion Figure 131: Call Diversion Type: Call Forwarding State: Text: Icon: LED: Call Diversion....
  • Page 146 Type: Call Forwarding State: Text: Icon: LED: Function Keys Figure 133: Function Keys (Type Call Forwarding, State 4) 3.10.5.9 Function Key Call Group Type: Call Group State: Text: Icon: Name: Function Keys Figure 134: Function Keys (Type Call Group, State 1) Type: Call Group State:...
  • Page 147 3.10.5.10 Function Key Directory Type: Directory Text: Icon: Searching: Combined Function Keys Figure 136: Function Keys (Type Directory) • • • • 3.10.5.11 Function Key Register Type: Register State: Text: Icon: Reg.ID: Activate Reg.: Function Keys Figure 137: Function Keys (Type Register, State 1)
  • Page 148 Type: Register State: Text: Icon: LED: Reg.ID: Function Keys Figure 138: Function Keys (Type Register, State 2, 1. Part) Activate Reg.: Function Keys Figure 139: Function Keys (Type Register, State 2, 2. Part) 3.10.5.12 Function Key Activate Type: Activate Text: Icon: Reg.ID: Disable act.
  • Page 149 3.10.5.13 Function Key Ringing off Type: Ringing off State: Text: Icon: Do not disturb....Function Keys Figure 141: Function Keys (Type Ringing off, State 1) Type: Ringing off State: Text: Icon: LED: Do not disturb....Function Keys Figure 142: Function Keys (Type Ringing off, State 2)
  • Page 150 • • • • • • 3.10.5.14 Function Key Call Waiting Type: Call waiting State: Text: Icon: Function Keys Figure 143: Function Keys (Type Call Waiting, State 1) Type: Call waiting State: Text: Icon: LED: Function Keys Figure 144: Function Keys (Type Call Waiting, State 2)
  • Page 151 • • • 3.10.5.15 Function Key Number Presentation Type: Number Present. State: Text: Icon: Function Keys Figure 145: Function Keys (Type Number Presentation, State 1) Type: Number Present. State: Text: Icon: LED: Function Keys Figure 146: Function Keys (Type Number Presentation, State 2)
  • Page 152 3.10.5.16 Function Key Transfer Type: Transfer Text: Icon: Function Keys Figure 147: Function Keys (Type Transfer) 3.10.5.17 Function Key Redirect Type: Redirect Text: Icon: Number: Function Keys Figure 148: Function Keys (Type Redirect)
  • Page 153 3.10.5.18 Function Key Phone Lock Type: Phone Lock State: Text: Icon: Function Keys Figure 149: Function Keys (Type Phone Lock, State 1) Type: Phone Lock State: Text: Icon: LED: Function Keys Figure 150: Function Keys (Type Phone Lock, State 2) 3.10.5.19 Function Key Headset Type: Headset...
  • Page 154 Type: Headset State: Text: Icon: LED: Function Keys Figure 152: Function Keys (Type Headset, State 2) • • 3.10.5.20 Function Key Hotdesk Type: Hotdesk State: Text: Icon: Function Keys Figure 153: Function Keys (Type Hotdesk, State 1) Type: Hotdesk State: Text: Icon: LED:...
  • Page 155 3.10.5.21 Function Key Create Registration Type: Create Reg. State: Text: Icon: Registration....Function Keys Figure 155: Function Keys (Type Create Registration, State 1) Type: Create Reg. State: Text: Icon: LED: Registration....Function Keys Figure 156: Function Keys (Type Create Registration, State 2) Protocol: H323 Name:...
  • Page 156 Note  Gatekeeper ID Gatekeeper IP Address VoIP Gatekeeper Figure 158: Function Keys (Type Create Registration, VoIP Gatekeeper (Protocol H323))
  • Page 157 Gatekeeper ID Proxy VoIP Gatekeeper Figure 159: Function Keys (Type Create Registration, VoIP Gatekeeper (Protocol SIP/TSIP/SIPS)) Note ...
  • Page 158 3.10.5.22 Function Key Delete Registration Type: Delete Reg. Text: Icon: Function Keys Figure 160: Function Keys (Type Delete Registration) 3.10.5.23 Function Key Switch User Type: Switch User Text: Icon: Registration....Function Keys Figure 161: Function Keys (Type Switch User) Protocol: H323 Name: Number:...
  • Page 159 3.10.5.24 Function Key Recording Type: Recording State: Text: Icon: Function Keys Figure 163: Function Keys (Type Recording, State 1) Type: Recording State: Text: Icon: LED: Function Keys Figure 164: Function Keys (Type Recording, State 2)
  • Page 160 3.10.5.25 Function Key Boolean Object Type: Bool Obj. State: Text: Icon: LED: Number: Function Keys Figure 165: Function Keys (Type Boolean Object, State 1 - 4, 1. Part) Toggle Function Keys Figure 166: Function Keys (Type Boolean Object, State 1 - 4, 2. Part) •...
  • Page 161 3.10.5.26 Function Key Presence Type: Presence State: Text: Icon: Function Keys Figure 167: Function Keys (Type Presence, State 1) Type: Presence State: Text: Icon: LED: Function Keys Figure 168: Function Keys (Type Presence, State 2) 3.10.5.27 Function Key Prepare Override Type: Prep.
  • Page 162 Typ: Prep. override State: Text: Icon: LED: Function Keys Figure 170: Function Keys (Type Prepare Override, State 2)
  • Page 163 3.10.5.28 Function Key Toggle Type: Toggle State: Text: Icon: Function Keys Figure 171: Function Keys (Type Toggle, State 1) Type: Toggle State: Text: Icon: LED: Function Keys Figure 172: Function Keys (Type Toggle, State 2) 3.10.5.29 Function Key Message Type: Message Text: Icon:...

  • Page 164: Menu Administration

    3.10.5.30 Function Key Spare Type: Spare Text: Icon: Function Keys Figure 174: Function Keys (Type Spare) 3.11 Menu Administration Information....IP Settings....Registration....Reset Configuration... < Administration Figure 175: Menu Administration User Name: Password: < Authentication Figure 176: Menu Authentication...
  • Page 165 Information....< Administration Figure 177: Menu Administration (Hide Configuration at Phone) Information....IP Settings....Registration....Reset Configuration... Tuning < Administration Figure 178: Menu Administration (Tuning active) 3.11.1 Information Administration Information IP 192.168.0.251 Ser 00-50-c2-6a-50-02 8.00 hotfix 1 IP152[80500.04] Bootcode[8050004] HW[101] + Information Figure 179: Menu Information...
  • Page 166 3.11.2 IP Settings IP Settings Administration IP Settings DHCP Mode: Client IP Addresses....VLAN......+ IP Settings Figure 180: Menu IP Settings Menu Item Possible settings DHCP Mode IP-Addresses VLAN Table 16: IP-Properties Menu IP Settings...
  • Page 167 3.11.2.1 IP Addresses Interface IP Address IP Address Mask Default IP Gateway 5 IP Addresses Figure 181: Menu IP Addresses 3.11.2.2 VLAN VLAN Header: 5 VLAN Figure 182: Menu VLAN Header Off VLAN Header: VLAN Identifier: Prio. RTP Data : Prio.
  • Page 168 Protocol: H323 Name: Number: Passw.: VoIP Gatekeeper....Options....... + Registration Figure 184: Menu Registration Note  3.11.3.1 VoIP Gatekeeper Gatekeeper ID Gatekeeper IP Address Gatekeeper IP Address 5 VoIP Gatekeeper Figure 185: Menu VoIP Gatekeeper (Protocol H323)
  • Page 169 Gatekeeper ID Proxy Proxy 2 5 VoIP Gatekeeper Figure 186: Menu VoIP Gatekeeper (Protocols SIP/TSIP/SIPS) Note  Note  3.11.3.2 Options...
  • Page 170 • • • • • • • • • • • • • • • • • • • • • • • • • • • Tones: europe-pbx 5 Options Figure 187: Menu Options 3.11.4 Reset Configuration reset configuration Administration...
  • Page 171 Reset Configuration Do you want to reset the device to the factory defaults? No......Yes......+ Reset Configuration Figure 188: Menu Reset Configuration Caution Are you sure? No......Yes......+ Reset Configuration Figure 189: Menu Security Request Reset Configuration...
  • Page 172 3.11.5 Tuning menu Tuning TCP keepalive TCP miss alive RAS time to live: RAS retry count : RAS request t.o.: RAS restart t.o.: + Tuning Figure 190: Menu Tuning • •...

  • Page 173: Administration

    Administration 4.1 General 4.1.1 Web-Interface user interface menu > Administration > Network Menu > Administration > Information...
  • Page 174 4.1.2 User Name and Password Configuration > General > Admin 4.1.2.1 User Name and Password ResistTel IP2 / IP152 user name password 4.1.2.2 User Name and Password ExResistTel IP2 / IP154 user name password 4.1.3 General Structure...

  • Page 175: Global Menu

    4.2 Global Menu <Name of Logged in Administrator> 4.3 Main Menu General 4.3.1 Menu Info...
  • Page 176 4.3.2 Menu Admin...
  • Page 179 Leave realm...
  • Page 180 Disable local authentication 4.3.2.1 Delegated Authentication 4.3.2.1.1 Overview 4.3.2.1.2 How it works 4.3.2.1.2.1 Kerberos 4.3.2.1.2.2 Logging in...
  • Page 181 Figure 191: HTTPS Basic Authorisation HTTPS basic authentication Kerberos 4.3.2.1.2.3 Cross Realm Authentication...
  • Page 182 Figure 192: Cross Realm Authentication 4.3.2.1.2.4 HTTPS for Encryption HTTP...
  • Page 183 HTTPS 4.3.2.1.2.5 Authorization 4.3.2.1.2.6 The PBX as a Kerberos Server 4.3.2.1.3 Configuration 4.3.2.1.3.1 Setting up the Kerberos Server...
  • Page 184 4.3.2.1.3.2 Setting up the Client Devices 4.3.2.1.3.3 Setting up Cross-Realm Authentication...
  • Page 185 4.3.2.1.3.4 Determining the RID of a Windows Domain Group whoami /groups /sid [Group 1] = "DOMAIN\Domain-Users" S-1-5-21-854245398-616249376-725345543-513 [Group 2] = "DOMAIN\Admins" S-1-5-21-854245398-616249376-725345543-1180 4.3.2.1.3.5 Prerequisites for Windows Groups 4.3.2.1.4 Using it 4.3.2.1.4.1 Use HTTPS for Kerberos Users 4.3.2.1.4.2 User Names...
  • Page 186 4.3.2.1.5 Security Considerations 4.3.2.1.5.1 Use local Users only for Recovery Purposes 4.3.3 Menu Certificates 4.3.3.1 File Formats • • •...
  • Page 187 4.3.3.2 Certificate Types • 4.3.3.3 Certificate Extensions • • • • • • Note  Validation will fail, if an unsupported extension is marked as critical 4.3.3.4 Signature Algorithms •...
  • Page 188 4.3.3.5 Key Types • 4.3.3.6 Signature Request Types • 4.3.3.7 Certificate File Encryptions • • • • • 4.3.3.8 Certificate Configuration Trust list Remove: Clear: Details:...
  • Page 189 Download: Download all: Upload: Rejected certificates Trust: Clear: Details: Device certificate Trust: Clear: Renew: Details: Download:...
  • Page 190 Create new: Upload: Creating a self-signed-certificate Type: Key: Validity: Other naming options: Signing request Details: Download: Remove: Creating a certificate signing request...
  • Page 191 Type: Key: Common Name: Other naming options: Uploading the response certificate from a CA Application certificates Trust: Remove: Details: Download: Create new:...
  • Page 192 Upload: Creating a self-signed-certificate Type: Key: Validity: Other naming options: Signing request Details: Download: Remove:...
  • Page 193 Creating a certificate signing request Type: Key: Common Name: Other naming options: Uploading the response certificate from a CA 4.4 Main Menu ETH0 4.4.1 Menu Link...
  • Page 194 Table 17: Link Setups 4.4.2 Menu VLAN...
  • Page 195 4.4.3 Menu 802.1X 4.4.4 Menu Statistics...
  • Page 197 4.5 Main Menu IP4...
  • Page 198 4.5.1 Menu General 4.5.1.1 Submenu Settings Note ...
  • Page 199 • • 4.5.1.2 Submenu Routing • • • •...
  • Page 200 • 4.5.2 Menu ETH0 4.5.2.1 Submenu DHCP • • • •...
  • Page 201 • • •...
  • Page 202 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 203 • • • • • • • • • • • • • • • • • • Caution 4.5.2.2 Submenu IP...
  • Page 204 • • •...
  • Page 205 4.5.2.3 Submenu NAT 4.5.2.4 Submenu DHCP Server Common DHCP parameter: Address Ranges:...
  • Page 206 Offer Parameters:...
  • Page 208 • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 209 • • • • • • • • • • • • • • • • • •...
  • Page 210 • • • • • •...
  • Page 211 Note  4.5.2.5 Submenu DHCP Leases • • •...
  • Page 212 • • Reserve 4.5.3 Menu PPP 4.5.3.1 Submenu Config...
  • Page 213 • • •...
  • Page 214 • •...
  • Page 215 • • 4.5.3.2 Submenu State...
  • Page 216 • • • • •...
  • Page 217 4.5.4 Menu NAT 4.5.4.1 Submenu General...
  • Page 218 Note  • • • • 4.5.4.2 Submenu H.323 Note ...
  • Page 219 4.6 Main Menu IP6 Organizationally Unique Device Identifier Identifier (OUI) 0250:C2FF:FE6A:5127...
  • Page 220 Figure 193: Converting IEEE MAC addresses to IPv6 modified EUI-64 Identifiers 4.6.1 Menu General 4.6.1.1 Submenu Routing • • • • • 4.6.2 Menu ETH0 4.6.2.1 Submenü IP6...
  • Page 221 • • • • 4.6.2.2 Submenu Address...
  • Page 222 • • • • • • • • • • • • • • • 4.6.2.3 Submenu Router...
  • Page 224 4.6.3 Menu 6to4 4.6.3.1 Submenu Config • •...
  • Page 225 4.6.3.2 Submenu State • • • • 4.7 Main Menu Phone 4.7.1 Menus User-1 to User-6...
  • Page 226 4.7.1.1 Submenu General Note ...
  • Page 227 Note ...
  • Page 228 Note ...
  • Page 229 Note  • • • • • • •...
  • Page 230 • • • • • • • • • • • • • • • • • • • •...
  • Page 231 • • •...
  • Page 232 • • •...
  • Page 233 • • • • • • •...
  • Page 234 Note ...
  • Page 235 4.7.1.2 Submenu Preferences • • • • • • • • • • • • • • • • • •...
  • Page 236 • • • •...
  • Page 237 • o Reject o Reject, if busy o Micro On o Audible Signal Off o Treat Call Announcement • o Allow:...
  • Page 238 • • • • •...
  • Page 239 • •...
  • Page 240 • • • 4.7.1.3 Submenu Call-Lists...
  • Page 241 4.7.1.4 Submenu Directories • Use TLS • Username: • Password + Retype • Server: • Port: • Username: • Password + Retype: • Search base • Mode: basic, paged results, virtual list views...
  • Page 242 • Object Filter • Sort Results (by 1st LDAP name attribute) • Name Attributes • Number Attributes • H323 ID Attribute • Hold Server Connection (default 5 seconds) • Country Code: • Area Code: • National Line (carrier specific): • International Line (carrier specific): •...
  • Page 243 • • • • • • • • • • • • • • • • • • • • •...
  • Page 244 • • • • • • • • 4.7.1.5.1 Function Keys General...
  • Page 245 • • • •...
  • Page 246 Figure 194: Icons...
  • Page 247 4.7.1.5.2 Delete Function Key (<empty item>) 4.7.1.5.3 Function Key Short Dial...
  • Page 248 Allow Outgoing Phone->User-x->Preferences Reject Incoming for Announcement Calls Phone->User-x- >Preferences 4.7.1.5.4 Function Key Partner...
  • Page 249 Caution Note  • • •...
  • Page 250 • • • 4.7.1.5.5 Function Key Park...
  • Page 251 4.7.1.5.6 Function Key Pickup 4.7.1.5.7 Function Key Message Waiting...
  • Page 252 Broadcast MWI to all registrations on the same gatekeeper. This function is used when the voicebox of other registrations is monitored for MWIs. To monitor the MWI of another registration, you need a second registration for the respective user at the phone. This second registration needs also a MWI - function key.
  • Page 253 4.7.1.5.9 Function Key Join Group 4.7.1.5.10 Function Key Search Directory All subscribers combined from the three next search • criteria. All subscribers stored in your IP telephone. • All subscribers of the telephone system you are registered • with. All subscribers connected on an external database via •...
  • Page 254 4.7.1.5.11 Function Key Enable Registration 4.7.1.5.12 Function Key Activate Registration...
  • Page 255 4.7.1.5.13 Function Key Do not Disturb • • • • • • • • •...
  • Page 256 4.7.1.5.14 Function Key Call Waiting • • • 4.7.1.5.15 Function Key Hide Own Number 4.7.1.5.16 Function Key Transfer...
  • Page 257 4.7.1.5.17 Function Key Redirect Note  4.7.1.5.18 Function Key Lock...
  • Page 258 4.7.1.5.19 Function Key Headset • • • • 4.7.1.5.20 Function Key Hot Desking Attention...
  • Page 259 4.7.1.5.21 Function Key Create Registration Note ...
  • Page 261 Note  • • •...
  • Page 262 • • •...
  • Page 263 • • • • • • • 4.7.1.5.22 Function Key Delete Registration 4.7.1.5.23 Function Key Switch...
  • Page 264 4.7.1.5.24 Function Key Recording...
  • Page 265 4.7.1.5.25 Function Key Boolean Object...
  • Page 266 Note: Toggling works only if a number is configured for the Boolean Object. Note ...
  • Page 267 4.7.1.5.26 Function Key Presence Note  4.7.1.5.27 Function Key Prepare Override...
  • Page 268 • • •...
  • Page 269 4.7.1.5.28 Function Key Toggle State 0 – Number State 1 – Number Toggle on Press and Release...
  • Page 270 4.7.1.5.29 Function Key Message 4.7.1.5.30 Function Key Spare 4.7.1.6 Submenu Recording • • • •...
  • Page 271 Call Data: 4.7.1.7 Submenu Reset 4.7.2 Menu Ring-Tones...
  • Page 272 4.7.3 Menu Direct-Dialing...
  • Page 273 Note  4.7.4 Menu Preferences...
  • Page 275 4.7.5 Menu Protect...
  • Page 276 PHONE_HIDE_ADMIN_INFO_MAC 0x01000000 Hide serial/MAC from admin->info screen PHONE_HIDE_ADMIN_CONFIG 0x10000000 Hide config entries from admin-menu (keep admin-info only) PHONE_HIDE_MM_ADMIN 0x08000000 hide admin entry from main-menu PHONE_HIDE_MM_USER_LIST 0x20000000 hide user-list entry from main-menu PHONE_HIDE_MM_PHONE_SETTINGS 0x40000000 hide phone-settings entry from main-menu PHONE_HIDE_MM_USER_SETTINGS 0x80000000 hide user-settings entry from main-menu PHONE_HIDE_US_PREFERENCES...
  • Page 277 PHONE_LOCK_DIAL_EXT 0x00000001 disable external call if not on white list PHONE_LOCK_DIAL_INT 0x00000002 disable internal call if not on white list PHONE_LOCK_DIAL_QUERY 0x00000004 disable directory search on outbound calls PHONE_LOCK_DIAL_HISTORY 0x00000008 disable outbound call list access PHONE_LOCK_RING_EXT 0x00000010 ignore (but log) inbound external calls PHONE_LOCK_RING_INT...
  • Page 278 PHONE_LOCK_CALL_REDIAL 0x00002000 disable automatic dialling if call completion is not locked at all PHONE_LOCK_MSG_SEND 0x00004000 disable sending messages PHONE_LOCK_MSG_RECV 0x00008000 disable receiving messages PHONE_LOCK_FKEYS 0x00020000 disable function keys PHONE_LOCK_MENU 0x00040000 disable any menu PHONE_LOCK_DND 0x00080000 disable Do Not Disturb via mute key, function key and menu PHONE_LOCK_DIRECTORY...
  • Page 279 • • • • • config change PHONE USER /lock-mask <mask> /pinlock-mask <mask> /whitelist-e164 <numbers> /external-e164 <prefixes> 0x00000002 0x00000004 0x00000008 0x00000010 0x00000020 0x00000040 0x00000080 0x00000100 0x00000200 0x00000400 0x00000800 0x00001000 0x00002000 0x00004000 0x00008000 0x00010000...
  • Page 280 0x00020000 0x00040000 0x00080000 0x00100000 0x00200000 0x00400000 0x00800000 0x01000000 0x02000000 0x04000000 0x08000000 0x10000000 4.7.6 Menu State 4.7.6.1 Submenu Registrations • up: • disabled: • timeout: • rejected: • unauthorized:...
  • Page 281 • primary: • secondary: 4.7.6.2 Submenu Calls...
  • Page 282 • H323: • SIP: • TSIP: • SIPS: LOCAL EXTERNAL • >>: • <<:...
  • Page 283 • calling: • altering: • ringing: • connected: • closing: • drop: • dial: • accept: • reject: 4.7.6.3 Submenu DHCP-Options Details:...
  • Page 284 System Requirements: Configuration: Supported Options:...
  • Page 285 G729A,40,sec G729A,60/G711A,30 /lang /cc /ac /ntp /itp /col /pbx /cc 49 /ac 208 /ntp 0 /itp 00 /col 0 /pbx 7...
  • Page 286 mask gateway http://192.168.0.10/file.txt /poll 192.168.1.0:255.255.255.0, 192.168.2.0:255.255.255.0 4.8 Main Menu Device 4.8.1 Menu Info free...
  • Page 287 free free 4.8.2 Menu Temperature 4.8.3 Menu LAN-Interface • •...
  • Page 288 4.8.4 Menu Monitoring • • • 4.8.4.1 Submenu Info • • • •...
  • Page 289 Note  • • • • • • •...
  • Page 290 • • • • • Note  4.8.4.2 Submenu Test • •...
  • Page 292 4.8.5 Menu Relays...
  • Page 295 4.8.6 Menu Keypad Note ...
  • Page 296 Caution Å Å...
  • Page 297 4.8.7 Menu Extended-Preferences...
  • Page 298 • • • • • • • 4.9 Main Menu Services 4.9.1 Menu HTTP 4.9.1.1 Submenu Server...
  • Page 299 •...
  • Page 300 • • • • • 4.9.1.2 Submenu Client Note  • • •...
  • Page 301 • • Note  • Note  4.9.2 Menu NTP...
  • Page 302 Configuration: • • • • • • • • • • • • •...
  • Page 303 • Timezone Configuration String StdOffset[Dst[Offset], Date/Time, Date/Time] Offset...
  • Page 304 second Offset Date/Time Example CET-1CEST-2,M3.5.0/2,M10.5.0/3 Display field • • 4.9.3 Menu Update...
  • Page 305 boot prot...
  • Page 306 check scfg Current Update Serials...
  • Page 307 4.9.3.1 Configuration of the Update-Server 4.9.3.1.1 System Requirements • • •...
  • Page 308 4.9.3.1.2 Installation 4.9.3.1.3 Configuration 4.9.3.1.4 Running Maintenance...
  • Page 309 4.9.3.1.5 Maintenance Commands 4.9.3.1.6 Check Command mod cmd UP1 check <final-command> <serial> • ireset • reset • iresetn • resetn • ser 4.9.3.1.7 Times Command mod cmd UP1 times [/allow <hours>] [/initial <minutes>] mod cmd UP1 times /allow 12,22,23,0,1,2,3,4...
  • Page 310 mod cmd UP1 times /allow 12,22,23,0,1,2,3,4 /initial 6 4.9.3.1.8 Prot Command mod cmd UP0 prot <url> <final-command> <build-serial> mod cmd UP0 prot http://192.168.0.10/firm/ip152.bin ireset 04- 5656 mod cmd UP0 prot http://192.168.0.10/firm/ ireset 04-5656...
  • Page 311 4.9.3.1.9 Boot Command mod cmd UP0 boot <url> <final-command> <built-serial> mod cmd UP0 boot http://192.168.0.10/firm/ ireset 205 4.9.3.1.10 BMC Command (only for DECT Devices) mod cmd UP0 bmc <url> <final-command> <build-serial> mod cmd UP0 bmc http://192.168.0.10/firm/ccfp1200.bin ireset PCS04fd...
  • Page 312 4.9.3.1.11 SCFG Command mod cmd UP0 scfg <url> [<final-command> <save-serial> [ /force <hours> ]]...
  • Page 313 mod cmd UP0 scfg http://192.168.0.10/configs/saved/#h#b5.txt no-op WEEKLY /force 168 4.9.3.1.12 CFG command mod cmd UP0 cfg <url> <final-command> <serial> 4.9.3.1.13 Common Problems http:172.31.2.3/drive/cf0/update/update-all.txt...
  • Page 314 4.9.4 Menu Logging Log Server: • • • •...
  • Page 315 • • • • • •...
  • Page 316 Alarm and Event Forward Server: • • • • •...
  • Page 317 Local Alarm and Event Queues: 4.9.5 Menu SNMP SNMP...
  • Page 318 4.9.6 Menu Telnet 4.9.7 Menu DNS 4.9.7.1 Supported DNS Resource Records Types...
  • Page 319 4.9.7.2 Submenu Hosts Local Resource Records New Resource Record • •...
  • Page 320 • • •...
  • Page 321 4.9.7.3 Submenu Query • • • • •...
  • Page 322 • • • • • • •...
  • Page 323 4.10 Main Menu Maintenance 4.10.1 Menu Diagnostics 4.10.1.1 Submenu Logging • • • • • • • • • 4.10.1.2 Submenu Tracing...
  • Page 324 • • • • • • • • • • •...
  • Page 325 4.10.1.3 Submenu Alarms...
  • Page 327 4.10.1.4 Submenu Events • • • • • • • •...
  • Page 328 Clear Save • • • • • • • •...
  • Page 329 • • • •...
  • Page 347 4.10.1.5 Submenu Counters 4.10.1.6 Submenu Config-Show 4.10.1.7 Submenu Ping ping 4.10.1.8 Submenu Traceroute...
  • Page 348 4.10.2 Menu Upload 4.10.2.1 Submenu Config Note  • 4.10.2.2 Submenu Firmware • • • •...
  • Page 349 4.10.2.3 Submenu Bootcode • • • 4.10.2.4 Submenu Directory...
  • Page 350 4.10.2.5 Submenu DRAM 4.10.3 Menu Download 4.10.3.1 Submenu Config saving the current configuration IP152-6a-5e-f7 download download with standard password...
  • Page 351 download download with standard password Note  4.10.3.2 Submenu Directory the complete directory Download 4.10.3.3 Submenu Firmware download firmware (ip152.bin) download firmware (IP152-6a-5e-f7-ip152.bin) 4.10.3.4 Submenu Bootcode download bootcode (boot152.bin) download bootcode (IP152-6a-5e-f7-boot152.bin)
  • Page 352 4.10.4 Menu Reset 4.10.4.1 Submenu Idle-Reset 4.10.4.2 Submenu Reset 4.10.4.3 Submenu TFTP Caution 4.10.4.4 Submenu Bootcode 4.10.5 Menu Tuning Menu Tuning 4.10.5.1 Submenu Tuning • •...
  • Page 353 4.10.6 Menu Debug Menu Debug 4.10.6.1 Submenu Leaks 4.10.6.2 Submenu Tracing • •...
  • Page 354 • • • • 4.11 Special Configuration 4.11.1 General...
  • Page 355 4.11.1.1 Changing the Configuration using a PC with an Editor • • 4.11.1.2 Changing the Configuration using the Address Line of a Browser 4.11.1.3 Changing the Configuration using Telnet...
  • Page 356 4.11.1.4 Commands config show config add /option <parameter> config change <existing configuration line> /option <parameter> config change <new complete configuration line> config write config activate 4.11.2 Additional Configuration Menus •...
  • Page 357 • 4.11.3 Configuration for Direct Dialling of IP Addresses  4.11.3.1 Backup for Failure of the Gatekeeper •...
  • Page 358 • • • • 4.11.3.2 Test Operation without a Gatekeeper • •...
  • Page 359 4.11.4 Protocol Options 'Faststart', 'H.245 Tunneling' and 'Extended Fastconnect' • • • 4.11.5 Protocol Option 'SIP-Hold'...
  • Page 360 4.11.6 Protocol Option 'Local MoH off' 4.11.7 Protocol Option 'No Dial Tone' 4.11.8 Protocol Option 'Recording without Remote Party Info' 4.11.9 Protocol Option 'Local Call Forward' •...
  • Page 361 • • 4.11.10 Protocol Option 'Show IP' 4.11.11 Protocol Option 'Do not Prefer E164-Number' 4.11.12 Protocol Option 'Do not Propagate Name Identification' 4.11.13 Protocol Option 'Keep Alive'...
  • Page 362 4.11.14 Protocol Option 'Gatekeeper Port'...
  • Page 363 4.11.15 SIP / TSIP / SIPS Protocol Parameter 'Name-ID' • vars create PHONE/USER-REG/0000<n> p • %3creg+prot=’ +coder=’ +name-id=’Text’ vars create PHONE/USER-REG/00001 p %3creg+prot=’SIP’+enblock= ’2’+gk-addr=’10.10.10.1’+alt-gk=’10.10.10.201’+name-id= ’Mustermann,Maximilian’+coder=G729,60+lcoder=’G729A,30’+e164= ’7004’+/%3e 4.11.16 SIP / TSIP / SIPS Protocol Option 'Force Silence Compression'...
  • Page 364 4.11.17 SIP / TSIP / SIPS Protocol Option Get CDPM (Called Party Number) from Request-URI 4.11.18 SIP / TSIP / SIPS Protocol Option 'Remote Domain in From' 4.11.19 SIP / TSIP / SIPS Protocol Option 'No T38 in Initial Offer'...
  • Page 365 4.11.20 SIP / TSIP / SIPS Protocol Option 'Take Sendonly as Inactive' 4.11.21 SIP / TSIP / SIPS Protocol Option 'Hold Notify as Inactive' 4.11.22 SIP / TSIP / SIPS Protocol Option 'No Receive only' 4.11.23 SIP / TSIP / SIPS Protocol Option 'Registration Redirect Support'...
  • Page 366 4.11.24 SIP / TSIP / SIPS Protocol Option 'No HR Notify' 4.11.25 SIP / TSIP / SIPS Protocol Option 'Prefer Tel URI' 4.11.26 SIP / TSIP / SIPS Protocol Option 'Prefer 'PAI' 4.11.27 SIP / TSIP / SIPS Protocol Option 'Prefer PAI2' 4.11.28 SIP / TSIP / SIPS Protocol Option 'Force PAI'...
  • Page 367 4.11.29 SIP / TSIP / SIPS Protocol Option 'Force PPI' 4.11.30 SIP / TSIP / SIPS Protocol Option 'Share Local Port' 4.11.31 SIP / TSIP / SIPS Protocol Option 'No Diverting Name' 4.11.32 SIP / TSIP / SIPS Protocol Option 'No User Parameter in From'...
  • Page 368 4.11.33 SIP / TSIP / SIPS Protocol Option 'No User Parameter in To' 4.11.34 SIP / TSIP / SIPS Protocol Option 'Anonymize Host' 4.11.35 SIP / TSIP / SIPS Protocol Option 'Cause 21 to 403' 4.11.36 SIP / TSIP / SIPS Protocol Option No Application Rerouting...
  • Page 369 4.11.37 SIP TSIP SIPS Protocol Option Alert Information' 4.11.38 SIP / TSIP / SIPS Protocol Option 'No MS Acceptedby' 4.11.39 SIP / TSIP / SIPS Protocol Option 'Keep Active Endpoints' 4.11.40 SIP / TSIP / SIPS Protocol Option 'Take Zero Address for Hold'...
  • Page 370 4.11.41 SIP / TSIP / SIPS Protocol Option 'Remove Calling Number Capability' 4.11.42 SIP / TSIP / SIPS Protocol Option 'Send Confidential Access Level Header' 4.11.43 SIP / TSIP / SIPS Protocol Option 'Fixed Contact Address' 4.11.44 SIP / TSIP / SIPS Protocol Option 'Product ID Format'...
  • Page 371 ResistTel IP2 ResistTelIP2 9.00 dvl 9.061019 9061019 9061019 example (ResistTel IP2/9.00 dvl [9.061019/9061019/101]) ResistTelIP2x9061019x101 4.11.45 TSIP SIPS Protocol Option 'Separate Encryption'...
  • Page 372 4.11.46 SIPS Protocol Option 'No Certificate Check' 4.11.47 SIPS Protocol Option 'TLS Unchecked' 4.11.48 Directory Items...
  • Page 373 4.11.49 RTTTL...
  • Page 374 • • • 4.12 Resetting of the Configuration in Case of Emergency...

  • Page 376: Appendix

    Appendix 5.1 Safety Instructions 5.1.1 Power Supply 5.1.2 Installation and Connection 5.1.3 Cleaning 5.1.4 Maintenance 5.1.5 Malfunctions...

  • Page 377: Menu Structure Of The Voip Telephones

    5.1.6 Disposal 5.1.7 Environmental Sustainability 5.1.8 Warranty 5.2 Menu Structure of the VoIP Telephones Menu | - Call Lists... | - Calls (combined)..| - Calls (inbound)..| - Calls (outbound)..| - Active Recalls..| - Directories..| - Directory Input..| - Subscriber: | - Number: | - Name...
  • Page 378 | - Search (combined)... | - Messages.... | - New Message..| - For: | - Messages(incoming)... | - Messages(outgoing)... | - User Setup... | - Call Diversion..| - Unconditional: Off(On) | - Busy: Off(On) | - No reply: Off(On) | - Presence..
  • Page 379 | - Speed: | - Function Keys | - 1 ....| - Type: Undefined | - Type:Destination No. | - Text: | - Icon: | - Number: | - Announcement: Off(On) | - Prepare: Off(On) | - Type: Partner | - Text: | - Icon: | - Number:...
  • Page 380 | - Icon: | - LED: Off(On, Blink,Flicker) | - Call Diversion | - Unconditional Off(On) | - Busy Off(On) | - No Reply Off(On) | - Type: Call group | - State: 1(2) | - Text: | - Icon: | - LED: Off(On, Blink,Flicker)
  • Page 381 | - Icon: | - LED: Off(On, Blink,Flicker) | - Type:Number Present. | - State: 1(2) | - Text: | - Icon: | - LED: Off(On, Blink,Flicker) | - Type: Transfer | - Text: | - Icon: | - Type: Redirect | - Text: | - Icon:...
  • Page 382 | - Type: Recording | - State: 1(2) | - Text: | - Icon: | - LED: Off(On, Blink,Flicker) | - Type: Bool Obj. | - State: 1(2,3,4) | - Text: | - Icon: | - LED: Off(On, Blink,Flicker) | - Number: | - Toggle: Off(On) | - Type:...
  • Page 383 | - 14 ....| - 15 ....| - 16 ....| - 17 ....| - 18 ....| - 19 ....| - 20 ....| - 2 <Name>..<Number> <+*> | - 3 <Name>..<Number> <+*> | - 4 <Name>..<Number> <+*> | - 5 <Name>..<Number>...

  • Page 384: Declarations And Approvals

    | - Yes....| - Tuning | - TCP keepalive | - TCP miss alive | - TCP time to live: | - TCP retry count : | - TCP request t.o.: | - TCP restart t.o.: 5.3 Declarations and Approvals 5.3.1 Declaration Conformity...
  • Page 385 5.3.2 Type Examination Certificate ExResistTel IP2 / IP154...
  • Page 388 5.3.3 IECEx Certificate of Conformity ExResistTel IP2 / IP154...
  • Page 389 5.3.4 Declaration of Conformity ExResistTel IP2 / IP154...

  • Page 391: Abbreviations

    Abbreviations...

  • Page 399: Overview

    Overview 7.1 Tables 7.2 Figures...

  • Page 405: Index

    Index —8— —D— —A— —B— —C— —E— —F—...
  • Page 406 —G— —H— —I— —N— —O— —P— —K— —L— —M—...
  • Page 407 —R— —T— —U— —S— —V— —W— —Z—...

  • Page 408: Technical Data

    Technical Data 9.1 Weatherproof Telephones • • • •...

  • Page 409: Explosion Proof Telephones

    9.2 Explosion Proof Telephones...
  • Page 410 • • • •...
  • Page 411 • • • • • • • • • • • •...
  • Page 412 Subject to alterations or errors FHF Funke + Huster Fernsig GmbH Gewerbeallee 15-19 · D-45478 Mülheim an der Ruhr Phone +49 / 208 / 82 68-0 · Fax +49 / 208 / 82 68-286 http://www.fhf.de · e-mail: info@fhf.de...

This manual is also suitable for:

Exresisttel ip2/ip154

Table of Contents

Save PDF
