Presets

The Mod Rex can store and recall up to 100 presets. Upon powering up, the Mod Rex
will load the last used preset.

LOADING A PRESET

To load a preset, start rotating the PRESET SELECT/STORE knob. As you rotate through,
the preset number shown in the display will blink. To select that preset, press and
release (don't hold down) the PRESET SELECT/STORE knob.
Upon loading a preset, all current parameters will be overwritten by those saved within
that preset. For parameters such as Tempo, Divisions, LFO Shapes, MOD/FILTER type
and R-INV, the digit display/LEDs will automatically display the new setting. For the
seven parameters controlled by physical, fluid knobs (VOL, all four DEPTH controls,
FEEDBACK, and RES), the setting recalled with the preset will overtake the physical
position of the knob. After loading a preset, once you rotate any of those seven knobs
that parameter will jump to the physical position of that knob.
After loading a preset, if any parameter is changed, in PRESET display mode the right-
most decimal place will be lit to signify a parameter is different than in the saved preset.
Any changes made after loading the preset won't be remembered upon reloading that
preset (or powering the unit off and back on) unless that preset is re-saved with the new
settings.

SAVING A PRESET

To save your current setting as a preset, while in PRESET display mode toggle to the
preset number you want to save to. Hold down the PRESET SELECT/STORE knob until
the blue PRESET LED to the left of the display begins to blink. Release the knob and the
current settings are now stored as a preset in that number slot.
As you rotate through preset numbers, the display blinks unless it is displaying the
currently loaded preset number. If when saving a preset you are simply updating the
currently loaded preset (as in, want to save it to the same preset number), while in
PRESET display mode simply hold down the PRESET SELECT/STORE knob until the blue
PRESET LED begins to blink. Release the knob and the preset is updated with your
current settings. If the right-most decimal place was lit signaling a changed parameter,
upon updating the preset it should go off.
NOTE: If while in PRESET display mode you press and release quickly the PRESET SELECT/STORE
knob, that preset number will be re-loaded, and any changes you made since you last recalled that
preset will be lost.
