- Page 1 Wireless e Bluetooth Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router User Manual Model 525831 ( IW-1300AC-AP ) intellinetnetwork.com Important: Read before use. • Importante: Leer antes de usar.
-
Page 2: Table Of Contents
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router CONTENTS Product Introduction ..............................3 Product Overview ................................3 Features ..................................3 Package Contents ................................. 3 Hardware Connection ..............................3 Front Panel ..................................3 Interface panel ................................3 Installation .................................. -
Page 3: Product Introduction
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Product Introduction Thank you for your purchase of the AC1300 Wireless Wave2 High Power Dual Band Gigabit PoE Router. Please read the entire user manual before using the product and save it for future reference. Product Overview This Wireless Router is based on the 802.11ac standard, providing up to 1.3 Gbps wireless data transmission rate. -
Page 4: Installation
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router LAN 1 – 2: two LAN ports to connect networked devices, such as PCs, print servers, remote hard drives, and any other compatible device to put on the network; LED connection-status indicator is on the upper right corner of the port USB: the USB port provided for a 3G USB modem card to connect to the Internet or connect a USB storage device DC: when PoE cannot be supplied, connect this port to the 12 VDC / 1.5 A power supply adapter Installation... - Page 5 Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router 3 Click on “Properties. ” 4 Select “Internet Protocol Version 4 (TCP/IPv4), ” and then click “Properties. ”...
-
Page 6: Logon Screen
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router 5 Choose to obtain an IP address automatically or manually set your IP address using the “use the following IP address” option. Then, choose to automatically assign a DNS server or to set it manually: 6 Use the following IP address: IP address: 192.168.1.XXX: (XXX is a number from 2 –... - Page 7 Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router 2 The username is “root”, password is “admin”. Click on the “Login, ” and the login page follows: 3 Once logged in, click the menu on the left side of the home page to go to the corresponding sub-page.
-
Page 8: Common Interface Buttons And Operations
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Common Interface Buttons and Operations Button Meaning Save and Apply current configuration information Save current configuration information Restore factory settings Reconnect this interface Shutdown this interface Edit this interface Shutdown this interface Delete this interface Synchronize local time with browser time... -
Page 9: Overview
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Overview Click on the “Status>Overview” option for the following interface: This interface shows “System” information (Hostname, Model, Firmware Version, Kernel Version, Local Time, Uptime, Load Average), “Memory” information (Total Available, Free, Cached, Buffered), “Network” information (IPv4 WAN Status, IPv6 WAN Status, Active Connections), “DHCP Leases”... -
Page 10: Kernel Log
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Kernel Log Click on the “Status>Kernel Log” option for the following interface: This interface shows the live system log. Processes Click on the “Status>Processes” option for the following interface: This interface shows system processes and their status. -
Page 11: Status>Realtime Graphs>Load
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Realtime Graphs Click the “Status>Realtime Graphs” option to see Load, Traffic, Wireless and Connections options. Status>Realtime Graphs>Load Click the “Status>Realtime Graphs>Load” option for the following screen: Status>Realtime Graphs>Connections Click the “Status>Realtime Graphs>Connections” option to see Realtime Connections information. -
Page 12: System
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router System Click on “System” to see options for System, Administration, Backup/Flash Firmware, Reboot, and AC Server. System Click the “System>System” option to set System Properties and Time Synchronization. System Properties System Properties are divided into “General Settings, ”... - Page 13 Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Local Time: click “Sync with browser” to synchronize the system time with the time on your computer Hostname: provide a router name Timezone: select the desired time zone from the drop-down list Click on the “Logging”...
-
Page 14: Administration
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Enable NTP client: enables the Local Time of the router to be synchronized with the NTP servers Provide NTP server: enables the router to work as an NTP server to provide time parameters to any requesters Administration Click on the “System>Administration”... -
Page 15: Configuration
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Reset to defaults: click the “Perform reset” button to restart the router and restore its settings to the factory default state (Includes: the default user name: root; default password: empty; default IP address: 192.168.1.1; default netmask: 255.255.255.0) Note: back up the configuration before restoring to factory-default settings;... -
Page 16: Ac Server
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router AC Server Click on the “System>AC Server” option for the following interface: AC Server Mode: Change the management mode for controlling the AP device. Network Click “Network” for options on Interfaces, Wifi, DHCP and DNS, and Firewall. Interfaces Click the “Network>Interfaces”... -
Page 17: Network>Interfaces>Lan
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Network>Interfaces>LAN Click the “Network>Interfaces>LAN” option to configure the network interfaces (LAN). Common Configuration The “Common Configuration” screen is as follows: Set the IP address and netmask. You can, then, manage the router via this IP address. Or if not needed, keeps the default values. Protocol: select the protocol type IPv4 address: enter the router’s IP address on the LAN;... -
Page 18: Dhcp Server
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router DHCP Server The DHCP Server setting interface is as follows: Ignore interface: Check this box to disable this DHCP function for the interface. Network>Interfaces>WAN Click the “Network>Interfaces>WAN” option to enter the WAN port settings interface. Selectable options for the Protocol: Static address, DHCP client, PPPoE, Unmanaged, PPP. - Page 19 Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Ipv4 address: the router’s IP address on the WAN; enter the public IP address provided by your ISP Ipv4 netmask: the netmask for the WAN interface; enter the netmask provided by your ISP Ipv4 gateway: fill in the gateway provided by the ISP Use custom DNS server: fill with information provided by your ISP’s Override MAC address: the default value is the MAC address of the WAN interface of this router;...
- Page 20 Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router PPP (Point-to-Point Protocol) is a link-layer protocol. This link provides full-duplex operation and transfers data packets in order. It is designed primarily to establish a point-to-point connection in sending data via dial-up or leased line mode, making it a common solution.
- Page 21 Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router PAP/CHAP username, PAP/CHAP password: enter the ISP username and password Access Concentrator: input connector center terminal, computer or communications device connection point device; leave empty to autodetect Service Name: enter the name of the broadband connection; leave empty to autodetect Use default gateway: check to use default gateway Use gateway metric: for every gateway (e.g., router), the metric is increased by 1 Use DNS servers advertised by peer: check to use DNS server’s address(es) advertised by peer...
-
Page 22: Wi-Fi
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Wi-Fi Click the “Network>Wifi” option for the following screen. The Router supports 2.4- and 5-GHz wireless signals, but its default is the 2.4 GHz band. Complete settings for the 5 GHz band if required in addition. Click on the “Scan”... -
Page 23: Network>Wifi>Wifi0: Master "11N_0007
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router For example, to join any of the wireless networks click, Join Network. 1 Fill in the WPA passphrase (the AP wireless password; the same of the new network). 2 Select “Create/Assign firewall-zone”. You can select one or create one. 3 Click the Submit button. -
Page 24: Device Configuration
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Device Configuration Device Configuration is divided into General Setup and Advance Settings. Click on the “General Setup” subpage for the following interface. Channel: select from the range 1 to 13 Transmit Power: choose the appropriate power to meet network needs. - Page 25 Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router ESSID: create a second or subsequent Mode: select the desired interface mode via the drop-down list Network: choose the network(s) that are desired to be attached to this wireless interface or fill out the “create” field to define a new network Hide ESSID: If checked, Wi-Fi devices can’t search the SSID anymore (to connect the SSID must be input manually) Click on the “Wireless Security”...
-
Page 26: Dhcp And Dns
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router DHCP and DNS Click “Network>DHCP and DNS” for the following interface: Server Settings Dnsmasq for NAT firewall provides an integrated DHCP server and DNS forwarder. Click on “General Settings” tab as shown below: Domain required: don’t forward DNS-Requests without DNS-Name Authoritative: this DHCP is the only one in the local network Local server: the local domain rule, never forwarded and processed, only resolved from the local DHCP or Host’s file name data... - Page 27 Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Click the “Resolv and Hosts Files” tab for the following interface: Use /etc/ethers: enable according to /etc/ethers to configure the DHCP-Server Leasefile: file where given DHCP-leases will be stored Ignore resolve file: if checked, feature is enabled Resolve file: local file where DNS resolutions are stored Ignore Hosts files: if checked, feature is enabled...
-
Page 28: Active Dhcp Leases
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Click on the “Advanced Settings” tab for the following interface: Filter private: do not forward reverse lookups for local networks Filter useless: do not forward requests that cannot be answered by public name servers Localization queries: localize hostname depending on the requesting subnet if multiple IPs are available Expand hosts: add local domain suffix to names served from hosts files No negative cache: do not cache negative replies (e.g., for not existent domains) -
Page 29: Firewall
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Firewall Click on the “Network>Firewall” option to configure General Settings, Port Forwards, Traffic Rules and Custom Rules. Network>Firewall>General Settings Click on the “Network>Firewall>General Settings” option for the following interface: General Settings Enable SYN-flood protection: SYN Flood is currently the most popular DoS (Denial of Service attack) with one of the DDoS (Distributed Denial of Service attack) approaches, which uses a TCP protocol flaw, sending a large number of forged TCP connection requests, thereby causing the attacker... - Page 30 Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Regional Click the “Add” button for the following interface: For example, to add “lan => wan, ” make the following settings:...
-
Page 31: Regional "Newzone
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Regional “newzone” General Settings Name: lan; the zone or an area of your network Input/Output: drop, reject, accept Forward: refers to specific (one or more) data packets between different subnet Masquerading: IP masquerading is a special kind of SNAT rule;... -
Page 32: Inter-Zone Forwarding
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Inter-Zone Forwarding The figure above shows options for the control area (lan) and forwarding rules for other regions. After the above are set, click the “Save & Apply” button to successfully add a firewall area. Network>Firewall>Port Forwards Click on the “Network>Firewall>Port Forwards”... -
Page 33: Network>Firewall>Traffic Rules
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Network>Firewall>Traffic Rules Click on the “Network>Firewall>Traffic Rules” tab for the following interface: Communication rules define the traffic transmitted between different regions (e.g., items to reject traffic between certain hosts or items to open WAN ports on the router). For example, to add the name of aa traffic rules, follow these steps to configure:... - Page 34 Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Fill in the information according to the map and click the “Add” button to enter the following interface configuration: Name: add a name, such as aa Restrict to address family: IPv4 and IPv6, only IPv4, only IPv6, any for you to choose, according to the traffic rules desired to implement Protocol: select the protocol based on your intranet server Match ICMP type: select the type of ICMP packet;...
-
Page 35: Network>Firewall>Custom Rules
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Network>Firewall>Custom Rules Click on the “Network>Firewall>Custom Rules” option for the following interface: In this interface, define some functions not included in the firewall so that the router can provide additional protection. Logout Click the “Logout”... -
Page 36: Appendix: Technical Specifications
Manageable Wireless AC1300 Dual-Band Gigabit User Manual PoE Indoor Access Point and Router Appendix: Technical Specifications Hardware Specification CPU Frequency 775 MHz RAM capacity 128 MB (DDR2) ROM capacity 16 MB (SPI flash) Standards and 5 GHz: IEEE 802.11ac, IEEE 802.11n, IEEE 802.11a Wireless Protocols 2.4 GHz: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b... -
Page 37: Notes
Manageable Wireless AC1300 Dual-Band Gigabit PoE Indoor Access Point and Router Notes... -
Page 38: Additional Information
DEUTSCHLAND: intellinetnetwork.de ITALIA: intellinetnetwork.it EN MÉXICO: intellinetsolutions.mx | Póliza de Garantía Intellinet — Datos del importador y responsable ante el consumidor IC Intracom México, S.A.P.I. de C.V. • Av. Interceptor Poniente # 73, Col. Parque Industrial La Joya, Cuautitlán Izcalli, Estado de México, C.P. 54730, México. • Tel. (55)1500-4500 La presente garantía cubre los siguientes productos contra cualquier... - Page 39 no cuentan con reparaciones, ni refacciones, ya que su garantía es de cambio físico. 3 La garantía cubre exclusivamente aquellas partes, equipos o sub-ensambles que hayan sido instaladas de fábrica y no incluye en ningún caso el equipo adicional o cualesquiera que hayan sido adicionados al mismo por el usuario o distribuidor.
- Page 40 All trademarks and trade names are the property of their respective owners. © IC Intracom. All rights reserved. Intellinet Network Solutions is a trademark of IC Intracom, registered in the U.S. and other countries. INT_525831_UM_1219_REV_5.01...
