Safety features of your vehicle
The 2nd row outboard seats (for 7,
8, 9 seats), 3rd row outboard seats
(for 9 seats) and 3rd row right seat
(for 7, 8 seats) are equipped with a
pair of ISOFIX anchorages as well as
a corresponding tether anchorage
on the back side of the rear cush -
ions. The ISOFIX anchorages are
located between seat cushion and
back rest, marked with the ISOFIX
icon.
OYPI039277
1. ISOFIX Anchor Position Indicator
2. ISOFIX Anchor
For installation, child restraint sys -
tem ISOFIX connectors have to
engage with the vehicles ISOFIX
anchorages (listen for a CLICK, check
potential visual indicators on the
child restraint system and cross-
check by pulling).
Child restraint systems with univer -
sal approval to relevant regulation.
need to be fixed additionally with a
top tether strap connected to the
corresponding tether anchorage
point in the back rest.
3 64
Child restraint system (CRS)
The installation and the use of a
child restraint system has to be
done according to the installation
manual, which is provided with the
ISOFIX child restraint system.
For stable and safe installation of
child restraint system, adjust the
seat position (seat-back angle and/
or seat forward and backward) so
that your child can fit in the child
restraint system in a comfortable
manner.
WARNING
When using the vehicle's "ISOFIX"
system to install a child restraint
system in the rear seat, all
unused vehicle rear seat belt
metal latch plates or tabs must be
latched securely in their seat belt
buckles and the seat belt webbing
must be retracted behind the
child restraint system to prevent
the child from reaching and taking
hold of unretracted seat belts.
Unlatched metal latch plates or
tabs may allow the child to reach
the unretracted seat belts which
may result in strangulation and a
serious injury or death to the child
in the child restraint system.
Do not place anything around the
lower anchors. Also make sure
that the seat belt is not caught in
the lower anchors.
