4. AT+GSLP – Enter deep-sleep mode
This command is used to invoke the deep-sleep mode of the module, the type of which is "set". A
minor adjustment has to be made before the module enter this deep sleep mode, i.e., connect
XPD_DCDC with EXT_RSTB
AT+GSLP=<time>
<time>
Response
OK
The time unit of
Parameters
ESP8266 will wake up after deep sleep
5. ATE – AT commands echo
This command ATE is an AT trigger command echo. It means that entered commands can be echoed
back to the sender when ATE command is used. Two parameters are possible. The command returns
"OK" in normal cases and "ERROR" when a parameter other than 0 or 1 was specified.
ATE – AT commands echo
Response OK
ATE0: Switch echo off
Parameters
ATE1: Switch echo on
6. AT+RESTORE – Factory reset
This command is used to reset all parameters saved in flash (according to appendix), restore the
factory default settings of the module. The chip will be restarted when this command is executed.
AT+RESTORE – Factory reset
Response OK
Restore factory default settings.
Notes
The chip will restart.
Espressif Systems
"
via 0 ohm resistor.
<time> is ms.
13 73
<time> ms.
/
