12'W x10'H Peak Style Frame Assembly
Please read and understand instructions
completely before assembly.
Layout out frame parts as shown and match up items with quantity to make
sure no parts are missing.
Middle Ribs
End Rib
Wind Brace
Assembly
Mfg.
Reference #
Part #
1
10131
2
10121
3
10132
4
10125
5
10126
6
10127
7
10128
8
10133
9
2030
10
10134
11
2031
Wind Brace
Assembly
Mfg.
Reference #
Part #
10135
12
10110
13
10111
14
10112
15
669
16
17
10210
18
10114
19
10115
20
10113
21
10223
22
800260
Page 2
Top Rail
End Rib
Cover Rails
ATTENTION:
FOR MISSING OR
REPLACEMENT PARTS
OR QUESTIONS,
PLEASE CONTACT
CUSTOMER SERVICE:
1.800.524.9970
CANADA 1.800.559.6175
www.shelterlogic.com
150 Callender Road
Watertown, CT 06795
05-101133-0C 09/04/07
Side Rails
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ShelterLogic 12'W x10'H Peak Style
Summary of Contents for ShelterLogic 12'W x10'H Peak Style
- Page 1 12'W x10'H Peak Style Frame Assembly Please read and understand instructions completely before assembly. Layout out frame parts as shown and match up items with quantity to make sure no parts are missing. Top Rail End Rib Middle Ribs End Rib...
- Page 2 Basic Frame Assembly NOTE: FRAME EXTENSION KIT 12'x20'x10' is the base frame dimension. Your model may have more middle ribs than shown in the illustration on pg.2. You will receive one extra rib for every extra 4 ft. of building length that you purchase. The basic frame assembly will remain the same. The cover will be the correct size for the length of the building.
- Page 3 11102 STEP 4: INSTALL SIDE RAILS AND SHELTERLOCK™ STABILIZER BLOCKS Fig. 4 11102 With help move the first end rib into the desired staked area. Place the ShelterLock on the upright as shown in Fig. 4. From the outside of the rib insert the bolt through the upright and then through the ShelterLock.
- Page 4 STEP 7: SECURE BASE FEET Fig. 7 Depending on the model you have purchased, your base feet will either fit onto the outside of the leg pole or slide into the bottom of the leg pole. After installing the base feet line up the holes in the leg to the holes in the feet and secure with the hardware indicated in Fig.
- Page 5 STEP 10: INSTALLING THE COVER ON THE FRAME: Fig. 10A, 10B, 10C & 10D Lay the cover on the ground next to the frame with the inside of the cover (the side with the pipe pockets) facing down and the webbing on the front and rear of the corner of the building.
- Page 6 NOTE: ShelterLogic logo should line up on the left front and right rear corners near the top rail. If it is not legible and positioned as shown above as “incorrect”, the cover has not been put on the frame correctly.
- Page 7 3. Proper anchoring is the RESPONSIBILITY OF THE OWNER. Any shelter that is not anchored securely and properly has the potential to blow away in high winds. ShelterLogic cannot be held responsible for any shelter that blows away. NOTE: Your shelter’s cover can be quickly removed and stored prior to severe weather conditions.
