Section 6 Parts List
Oven And Cabinet Part Listing
NOTE: Parts marked "*" may cause undue microwave exposure.
Parts marked "∆" are used in voltage more than 250V.
NO.
DESCRIPTION
ELECTRIC PARTS
1
High voltage rectifier
2
High voltage capacitor (interchangable)
3
Turntable motor (interchangable)
4
Stirrer motor (interchangable)
5
Thermal cut-out 60°C (Hood Fan)
6
Power transformer (Interchangeable)
7
Magnetron
*∆
8
Pri. Interlock, Stop and Thrid door switches
(interchangable)
9
Monitor swtch (V- 5220Q) &
C/T fuse assembly (20A 150°C) or
Monitor swtch (D3V - 1G -2C25) &
C/T fuse assembly (20A 150°C interchangable)
10
Power supply cord
11
Oven lamp socket
12
Hood fan motor
13
Fan motor
14
Oven lamp (interchangable)
15
Thermal cut-out 145ºC (Cavity) (Interchangeable)
16
AH sensor (Humidity sensor)
118
Ferrite clamp
CABINET PARTS
18
Hood exhaust louver
19
Right base plate
20
Rear stay
21
Outer case cabinet
22
Schematic diagram
23
Hood lamp glass assembly
24
Hood lamp glass angle
25
Hood lamp glass
26
Base cover
27
Cushion
28
Rubber cushion
29
Mag cushion
OVEN PARTS
36
Exhaust damper assemply
37
Turntable support assembly
38
Turntable tray
6-2
NO.
DESCRIPTION
39
Capacitor holder
40
Stirrer cover assembly
41
Stirrer fan assembly
42
Noise filter unit
43
Turntable motor packing
44
Latch hook
*
45
Unit mounting plate
46
Fan blade
47
Cord bushing
48
Oven lamp cover
49
Hood intake duct R
50
Hood intake duct cushion
51
Lamp filter
52
Chassis support left
53
Chassis support right
54
Hood duct
55
Rack Holder
61
Left rack holder
62
Right rack holder
91
Monitor caution lael
92
Charcoal filter
93
Grease filter
94
Canoe clip
108
Cushion
115
Deflector
117
Menu label
119
HWC caution
121
Ground catuion label
122
Installation caution
SCREWS, NUTS, WASHERS AND MISC.
83
Screw : 4mm x 8mm
96
Sensor grd wire
97
Screw : 4mm x 8mm
98
Screw : 4mm x 12mm
99
Screw : 4mm x 8mm
100
Special screw
101
Special screw
102
Screw : 3mm x 6mm
104
Screw : 4mm x 12mm
105
Screw : 4mm x 8mm
106
DHHS caution
116
Screw : 3mm x 8mm
123
Screw : 4mm x 10mm
