Product Diagram

Robot

WiFi Indicator
Indicator flashes blue quickly: the product enters the reset WIFI connection
mode Indicator flashes blue slowly: the product has paired with phone,
please input WiFi name and password in App Indicator blue long bright:
The product has been successfully connected to the mobile App.
Power Button
Long press to turn on / off the robot, short press to pause and continue to work.
Indicator Light Blue: Cleaning/ Standby Mode/ Full Charging
Indicator Light Blinks Blue: Charging
Indicator Light off: Sleep Mode
Indicator Light or Blinks Red Accompanied with Sound Alarm: Troubleshooting
Auto-Charging Button
After pressing this button, the product automatically enters the recharge mode
and looks for the charging seat for charging.
Indicator Light Orange: Self-Charging and Standby Mode under Low Power.
