Summary of Contents for Allen-Bradley FLEX I/O SCANport 1203-FB
- Page 2 1–2 FLEX I/O SCANport Base Installation Instructions...
- Page 3 3. Position the terminal base on the 35 x 7.5mm DIN rail A (Allen-Bradley part number 199-DR1; 46277-3; EN 50022) at a slight angle with hook B on the left side of the terminal base hooked into the right side of the unit on the left.
- Page 4 1–4 FLEX I/O SCANport Base Installation Instructions 6. Press the terminal base down onto the DIN rail until flush. The locking lever D snaps into position and locks the terminal base to the DIN rail. 7. If the terminal base does not lock in place, use a screwdriver or similar device to move the locking lever down, press the terminal base flush with the DIN rail, and release the locking lever to lock the base in place.
- Page 5 FLEX I/O SCANport Base Installation Instructions 1–5 To wire the 1203–FB1 base, connect a SCANport cable from the SCANport device to the desired channel. SCANport cables are available in either Male–to–Male or Male–to–Female configurations. You can connect cables of up to 10 meters (33 feet) between a SCANport device and any SCANport peripheral.
-
Page 6: Emc Directive
Programmable Controllers, Part 2 – Equipment Requirements and Tests. For specific information required by EN 61131-2, see the appropriate sections in this publication, as well as the following Allen-Bradley publications: Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Guidelines for Handling Lithium Batteries, publication AG-5.4...
