EK–DSCPU–IN. A01
KN31x CPU INSTALLATION CARD
Use this card as a quick reference to install a KN31x
CPU module in AlphaServer DS20E / AlphaStation
DS20E systems.
WARNING: CPU modules and memory modules
have parts that operate at high temperatures. Wait 2
minutes after power is removed before touching any
module.
CAUTION: Wear an antistatic wrist strap when
working on this system.
Overview
•
Open the cabinet.
•
Locate the CPU slot.
•
•
Open the Cabinet.
1.
Shut down the operating system and power down
the system.
2.
Unplug the power cord(s).
3.
Remove the cover to gain access to the system
card cage. See Figure 1.
a.
Open the front bezel.
b.
Loosen the captive screw
side panel to the chassis.
c.
Remove the panel with a rearward motion
.
© Compaq Computer Corporation 1999.
All rights reserved.
Figure 1 Opening the Cabinet
2
attaching the
Locate the CPU Slot.
Always place the first CPU in slot 0; use slot 1 when
you are adding a second CPU.
Figure 2 CPU Slot Locations on System
Board
DIMM Slots
1
DIMM Slots
CAT0034A
1
1
3
1
3
0
2
0
2
2
0
2
0
3
1
3
1
CAT0030B
CPU 0
CPU 1
