INSTALLATION, OPERATION & MAINTENANCE MANUAL
Specifications
Dimensions (LxWxH) mm
Voltage (V ~)
Frequency (Hz)
Motor Power (w)
Heating Power (kW)
Air Volume (m
3
/h)
Air Speed (m/s)
Settings
External control
Temp Rise (Δt°C)
Noise level (dB)
Weight (Kg)
Insulation Class
Ingress Protection
Approvals
Precautions for Installation
•
Operating conditions for the WEL3000 overdoor heater: Installation below 1000m altitude; Operating temperature is between -10°C
and +40℃; Relative humidity of ≤90%. Indoor use only
This overdoor heater must be mounted in a solid structurally sound location to prevent excessive vibration.
•
This overdoor heater is not suitable for use in locations with high temperatures, high humidity, explosive atmospheres, corrosive
•
substances or any other location where gases or fine powder is present in the air. This may damage internal components or insulation
This heater must not be recessed into ceilings or be built into bulkheads.
•
Do not touch the outlets of the overdoor heater when it is running as they may be hot and could possibly cause burns.
•
Do not obstruct either the inlet or outlet of the overdoor heater.
•
Clean all the dust from the heater every month to ensure smooth operation.
•
ATC OVERDOOR HEATER
Thank you for purchasing this ATC WEL3000 3kw Overdoor Heater.
Please read these instructions carefully before use
High
Low
High
Low
High
Low
Off/Ambient/1500w/3000w
618 x 139 x 221
220-240
50
40
15
3
1.5
240
120
4 (max)
Yes – 5v DC contact
30-50
40±3 db @1.5m
6.8
1
IP20
CE
